17-4 PH Round Bar Snapshot
| Size | 4 – 500 mm |
|---|---|
| International Standards | ASTM A276, ASME SA276, UNS S17400, WNR 1.4542, ASTM A479 |
| Available Forms | Ingot, Billet, Square, Hex, Rectangular, Round, Flat Bar |
| Raw Material Origin | Japanese, American, Korean, European, Indian |
| Surface | Hot Rolled, Pickled, Hairline, Polished |
| Brand | Outokumpu, Yakin, ATI, Ratnaveer, Mukund |
| Fillers | ER630 |
| Quality Test | Hardness Test, Hydrostatic Test, Bending Test |
| Welding Electrode | AWS ER630 or AWS E630 |
| Tolerances | H13, H10, H12, K10, K9, H8, K12, K11, H11, H9 |
| Technique | Hot and Cold Rolled |
| Delivery Time | Mayanmar : 25 Days | South Korea : 7 Days |
| MTC | EN 10204 3.1 |
| Services | Cutting, Heat Treatment, Shearing |
17 4 PH Bar and 17 4 PH Stainless Steel Bar Suppliers in UAE
Stainless Steel 17-4 PH Round Bars: 1/16″ to 26″ mm Dia, 3 – 6 m (length)
SS 17-4 PH Cold Finished Bars: 3 to 150 mm (Size), 1 to 6.0 m (length)
AMS 5643 17-4 PH Bars: 3 to 350 mm (thickness), 2 to 500 mm (width)
UNS S17400 Hex Bar: 2 to 100 mm (Size), 1 – 6 m (Length)
17 4 PH Stainless Steel Bar: 3 to 600 mm (Thickness), 2 to 200 mm (Width)
Standard: ASTM A276 | ASME SA 276 | SA479
Suitable Temperatures: 572°F
Heat Treatment: Age Hardened, Solution Annealed and Cold Worked
MTR: NDT, Ultrasonic, PMI, Eddy Current Test Reports
Supply State: PH, H & T, ANN
Obtain Quote Directly from 17-4 PH Round Bar Suppliers in UAE With Data Sheet
Process: Forged and Rolled
Readily Available Stock of 17 4 PH Stainless Steel Bar
Get 17-4 PH Round Bar Suppliers in UAE offering extensive ready stock
- Shape: Round
- Workmanship: Cold Drawing
- Color: Silver
- Shear Modulus: 77 GPa
- Packaging: Wooden Boxes, Wooden Pallets
- Poisson’s Ratio: 0.27
- Annealing Temperature: 1038°C
- Latent Heat of Fusion: 280 J/g
- Specific Gravity: 7.8
- Fatigue Strength: 670 MPa
- Processing Service: Bending, Decoiling, Punching
- Magnetic: Ferromagnetic
- PREN: 16
- Thermal Diffusivity: 4.5 mm2/s
- Condition: Soft Annealed
- Impact Strength: 86 J
Find Authorised Dealers and Distributors of 17-4 PH Round Bar in Sharjah
- TechnoPower Generators, Sharjah
- Ultra Power Generators FZC, Sharjah
- Hamriyah Power Station, Sharjah
- PowerGas Oil Field Equipment LLC, Sharjah
Want to Approach a New Supplier? Connect Directly With Verified 17-4 PH Stainless Steel Round Rod Suppliers and Stockist in the Middle East
Associate Traders and Importers available in Below Locations For Quick Deliveries
| Region | Country | City |
|---|---|---|
| Middle East | United Arab Emirates | Dubai |
| Middle East | United Arab Emirates | Abu Dhabi |
| Middle East | Saudi Arabia | Dammam |
| Africa | South Africa | Cape Town |
| Middle East | Saudi Arabia | Riyadh |
| Middle East | Saudi Arabia | Jeddah |
| MENA | Morocco | Casablanca |
| Africa | South Africa | Johannesburg |
| Middle East | Kuwait | Kuwait City |
| MENA | Egypt | Cairo |
| Africa | Nigeria | Lagos |
| Middle East | Qatar | Doha |
| Africa | Nigeria | Abuja |
Cutting Methods of AMS 5643 17-4 PH Bars
Find 17-4 PH Round Bar Suppliers in UAE offering numerous cutting methods
- Saw Cutting
- Plasma Cutting
- Shear Cutting
- Waterjet Cutting
Well Known Types of 17-4 PH Round Bar
Check 17-4 PH Round Bar Suppliers in UAE offering a wide range of types
17 4 PH Round Bar
17 4 PH Bar
174 PH Stainless Rod
17-4 PH Bar
17-4 PH Round Bar
17-4 PH Stainless Steel Bar
UNS S17400 Hex Bar
AMS 5643 17-4 PH Bars
17-4PH SS Flat Bar
17 4 PH Stainless Steel Round Bar and SS17-4PH Flat Bar With MTC BS EN 10204 3.1B
Documentation of SS 17-4 PH Cold Finished Bars
- Fumigation Certificates
- Material Traceability Records
- Certificate of Origin
- Raw Material Test Reports
Weekly Shipment to Below Locations
| Middle East Countries | UAE, Saudi, Qatar, Kuwait, Bahrain, Oman, Iraq, Iran, Jordan, Lebanon, Syria, Yemen |
|---|---|
| Africa | Nigeria, South Africa, Kenya, Morocco, Egypt, Tunisia, Algeria |
| MENA | Egypt, Morocco, Algeria, Tunisia, Libya, Israel, Palestine |
Heat Treatment of 17 4 PH Stainless Steel Bar
| Condition | Hardening Temp, ± 9 °C (± 15 °F) | Hardening Time (hours) |
|---|---|---|
| H 1025 | 552 °C (1025 °F) | 4 |
| H 1100 | 593 °C (1100 °F) | 4 |
| H 900 | 482 °C (900 °F) | 1 |
| H 1075 | 579 °C (1075 °F) | 4 |
| H 1150 | 621 °C (1150 °F) | 4 |
| H 925 | 496 °C (925 °F) | 4 |
AMS 5643 Steel 17-4 PH Bright Bar and UNS S17400 Hex Bar Stock Available in Annealed Finish
Surface Finish of AMS 5643 Steel 17-4 PH Bright Bar
- Bright
- Pickling
- Black
- Polished
Storage Sites of Partner Suppliers
| Muscat | Ras Al Khaimah | Dubai | Riyadh |
|---|---|---|---|
| Sharjah | Doha | Umm Al Quwain | Fujairah |
| Saudi Arabia | Ajman | Abu Dhabi | Al Jubail |
Testing Methods of Stainless Steel 17-4 PH Round Bars
- Pitting Protection Test
- Hydrostatic Analysis
- PMI Testing
- Mechanical Testing
Cutting Speed Recommendations of 17 4 PH Bar
| Application | Vc (m/min) | Vc (SFM) |
|---|---|---|
| Turning | 160-215 | 520-710 |
| Grooving | 95-130 | 310-430 |
| Milling | 100-135 | 330-440 |
| Parting | 65-85 | 210-280 |
| Drilling | 80-105 | 260-340 |
Chemical Composition of 17-4 PH Stainless Rod
| Grade | Mo | Mn | C | Si | S | P | Cr |
|---|---|---|---|---|---|---|---|
| SS 17-4PH | 0.05 | 1.0 max | 0.07 max | 1.0 max | 0.03 max | 0.07 max | 15.0-17.5 |
Mechanical Properties of AMS 5643 17-4 PH Bars
| Yield Strength (psi) | Rockwell Hardness | Ultimate Tensile Strength (psi) | Elongation |
|---|---|---|---|
| 145,000 | C35 | 160,000 | 5% |
Equivalent of 17 4 PH Stainless Steel Bar
| Grade | UNS | WERKSTOFF NR. | JIS | EN | AFNOR |
|---|---|---|---|---|---|
| SS 17-4PH | S17400 | 1.4542 | SUS 630 | X5CrNiCuNb16.4 | Z6CNU17-04 |
Factors to Consider When Purchasing 17 4 PH Bar
- Material
- Technical Specifications
- Size
- Quality Standards
- Delivery Time
SS 17-4 PH Cold Finished Bars and Square Bar From 20 mm to 150 mm Width in Various Thickness in 6 mtrs Length
Dimension Chart of SS 17-4 PH Cold Finished Bars
| Diameter or Width (mm) | Weight per meter | Sectional Area | Perimeter | |||
|---|---|---|---|---|---|---|
| – | Square (kg) |
Round (kg) |
Square (cm²) |
Round (cm²) |
Square (cm) |
Round (cm) |
| 5.0 | 0.20 | 0.15 | 0.25 | 0.20 | 2.0 | 1.57 |
| 6.0 | 0.28 | 0.22 | 0.36 | 0.28 | 2.4 | 1.88 |
| 8.0 | 0.50 | 0.39 | 0.64 | 0.50 | 3.2 | 2.51 |
| 9.0 | 0.64 | 0.50 | 0.81 | 0.64 | 3.6 | 2.83 |
| 18 | 2.54 | 2.00 | 3.24 | 2.54 | 7.2 | 5.65 |
| 10 | 0.73 | 0.63 | 1.00 | 0.79 | 4.0 | 3.14 |
| 5.5 | 0.24 | 0.19 | 0.30 | 0.24 | 2.2 | 1.78 |
| 11 | 0.95 | 0.75 | 1.21 | 0.95 | 4.4 | 3.46 |
| 12 | 1.13 | 0.89 | 1.44 | 1.13 | 4.8 | 3.77 |
| 32 | 8.04 | 6.31 | 10.24 | 8.04 | 12.8 | 10.05 |
| 14 | 1.54 | 1.21 | 1.96 | 1.54 | 5.6 | 4.40 |
| 16 | 2.01 | 1.58 | 2.56 | 2.01 | 6.4 | 5.03 |
| 7.0 | 0.38 | 0.30 | 0.49 | 0.38 | 2.8 | 2.20 |
| 20 | 3.14 | 2.47 | 4.00 | 3.14 | 8.0 | 6.28 |
| 63 | 31.16 | 24.47 | 36.69 | 31.17 | 25.2 | 19.79 |
| 25 | 4.91 | 3.85 | 6.25 | 4.91 | 10.0 | 7.85 |
| 28 | 6.15 | 4.83 | 7.84 | 6.16 | 11.2 | 8.80 |
| 36 | 10.17 | 7.99 | 12.96 | 10.18 | 14.4 | 11.31 |
| 40 | 12.56 | 9.86 | 16.00 | 12.57 | 16.0 | 12.57 |
| 56 | 24.62 | 19.34 | 31.36 | 24.63 | 22.4 | 17.59 |
| 22 | 3.80 | 2.98 | 4.84 | 3.80 | 8.8 | 6.91 |
| 45 | 15.90 | 12.49 | 20.25 | 15.90 | 18.0 | 14.14 |
| 50 | 19.62 | 15.41 | 25.00 | 19.64 | 20.0 | 15.71 |
| 71 | 39.57 | 31.08 | 50.41 | 39.59 | 28.4 | 22.31 |
| 80 | 50.24 | 39.46 | 64.00 | 50.27 | 32.0 | 25.13 |
Weight Chart of AMS 5643 Steel 17-4 PH Bright Bar
| Size (mm) | Weight (Kg/mtr) | Weight (kg/ft) |
|---|---|---|
| 21 * 6 | 1 | 0.3 |
| 28 * 6 | 1.3 | 0.4 |
| 30 * 5 | 1.2 | 0.4 |
| 200 * 20 | 31.4 | 9.6 |
| 38 * 5 | 1.5 | 0.5 |
| 200 * 6 | 9.4 | 2.9 |
| 45 * 12 | 4.2 | 1.3 |
| 200 * 12 | 18.8 | 5.7 |
| 60 * 6 | 2.8 | 0.9 |
| 250 * 20 | 29.2 | 12 |
| 65 * 12 | 6.1 | 1.9 |
| 300 * 6 | 14.1 | 4.3 |
| 65 * 16 | 8.2 | 2.5 |
| 300 * 10 | 23.6 | 7.2 |
| 75 * 32 | 18.9 | 4.5 |
| 200 * 10 | 15.7 | 4.8 |
| 30 * 6 | 1.4 | 0.4 |
| 250 * 6 | 11.8 | 3.6 |
| 300 * 16 | 37.7 | 11.5 |
Applications of UNS S17400 Hex Bar
- Aircraft Parts
- Power Generation
- Oil & Gas Industry
- Gears
- Fittings and Pump Shafts
Insert Cutting Edge Geometry of 17-4 PH Round Bar
| Honing Size: | 0.03-0.05 mm / 0.001-0.002″ |
|---|---|
| Rake Angle: | 9°-11° |
| Land Angle: | Positive |
| Land Width: | 0.20-0.30 mm / 0.008-0.012″ |
Material Inspection Facilities in the Following Countries
| Country | Cities |
|---|---|
| Netherlands | Amsterdam |
| Belgium | Brussels |
| Belgium | Ghent |
| Netherlands | The Hague |
| Belgium | Westerlo |
| Netherlands | Rotterdam |
| Belgium | Leuven |
| Belgium | Seraing |
| Netherlands | Haarlem |
| Belgium | Meeuwen-Gruitrode |
| Netherlands | Eindhoven |
| Belgium | Antwerp |
