410ht stainless steel sheet

410Ht stainless steel sheet

Verified Supplier

Verified stockists and suppliers

Contact to reliable EN 2.4660 heat treated plate suppliers for custom sizes

410ht stainless steel sheet specification

410Ht stainless steel sheet specification

The top 10 suppliers in the United Arab Emirates of 410ht stainless steel sheet may provide according to custom drawings
Size range of Heat treated 410HT plate and sheet 410HT SS sheet thickness ASTM A240 Grade 410HT plate thickness
  • Width: 914mm to 1524mm
  • Length: 300mm to 6000mm
Thickness: 0.4mm to 6.0mm Thickness: 3.0mm to 100mm
SA 240 Type 410HT sheets surface treatment Alloy 410HT plates ASTM standard/American standards SA 240 Grade 410HT plate and sheet density
  • PVC Coated
  • Film Coated
  • Coated
  • Color Coated
  • Galvanised
  • ASTM A240/ A240M Type 410ht
  • ASTM A412/ A412M Type 410ht
  • ASTM A480/ A480M – SS 410ht flat rolled sheet
  • ASTM A263/ A263M – SS 410ht Clad Plate
  • ASTM A666/ A666M – SS 410ht Annealed/ cold worked sheet
  • ASTM A177/ A177M – SS 410ht high strength plate
  • ASTM A895/ A895M – SS 410ht free machining plate
7.65 Mg/m3
Stainless steel 410HT sheet maximum operating temperature INOX 410HT sheet and plate melting point Heat treated 410HT plates bending method
1292°F (700°C) 2700–2790° F (1480 – 1530°C)
  • Press braking
  • Roll bending
  • Rotary bending
European standard Hardness range of 410 HT stainless steel plate ASTM A240 SS 410HT plates and sheets lifespan
  • EN 10088 -2 (Technical delivery conditions)
96 HB Upto 25 years
EN 2.4660 410HT sheet edges Most popular SA 240 Type 410HT plates types Manufacturing methods of 410HT ferritic stainless steel plates
  • round
  • rolled
  • deburred
  • slit
  • square
  • broken corner
  • v edge
  • custom
  • EN 2.4660 Sheet
  • AISI 410HT Plate
  • 410HT SS Perforated Sheet
  • Alloy 410 HT Foils
  • 410 HT stainless steel Coils
  • SUS 410HT Plain Sheet
  • INOX 410HT Strip
  • Steel 2.4660 Shim Sheet
  • ASME SA 240 SS 410HT Chequered Plate

In contrast to other 410ht stainless steel sheet suppliers, compare our price and response time.

  • Cold Rolled INOX 410HT plate
  • Hot Rolled ASTM A240 Type 410HT sheet
SA 240 Gr 410HT sheets processing SS 410HT plates and sheets origin Supply SUS 410HT sheet in following brand
  • Temper pass with mill edge
  • Pickling with mill edge
  • Temper pass with cut edge
  • Pickling with cut edge
  • Pickling outside with mill edge
  • Thailand
  • Indian
  • Korea
  • European
  • US
  • Taiwan
  • Japanese
  • Nippon Metal
  • Baosteel
  • TISCO
  • POSCO
  • Aperam
  • Jindal Stainless
  • VDM
  • Outokumpu
  • Thyssenkrup
  • DKC Korea
  • Arcelor Mittal
410HT stainless steel sheets and plates marking AISI 410HT plates finish Alloy 410 HT sheet applications
  • Sizes
  • ASTM/ ASME standard
  • Manufacturer logo / name
  • Manufacturing date
  • Material grade
  • Origin of material
  • 8K
  • Mirror Finish
  • Checkered
  • 2B
  • 2D
  • BA
  • NO.1
  • hair line
  • sand blast
  • Brush
  • etching
  • Brushed finish
  • NO.4
  • NO.8
  • Embossed
  • Kitchen utensils
  • Chemical industry
  • Petroleum industry

Buy from the top zero-rejection 410ht stainless steel sheet suppliers in South Africa, Middle East, Egypt, US, Oman, and Saudi Arabia.

ASTM A240 Gr 410HT plates and sheet standard SUS 410HT sheets certification Services of Stainless steel grade 410HT plates
  • ASTM A167
  • EN10088-2-2005
  • GB/T3280-2007
  • ASTM A240
  • ASME SA240
  • JIS4304-2005
  • 100% Radiography Test Report
  • Third Party Inspection Report
  • EN 10204/3.1B,
  • Raw Materials Certificate
  • Certificate of Origin legalized
  • Plate Leveling
  • Forging
  • Bending
  • Polish
  • Annealing
  • Shearing
  • Forming
  • Pickling
  • Heat Treatment
  • grinding
  • Cutting
  • Minor Fabrication
  • Rolling
  • Welding
  • Machining
  • Beveling

Chat or email are the best ways to get in touch with mentioned 410ht stainless steel sheet stockists, stockholders, and distributors for these services.

Packaging of ASTM A240 UNS S41000 HT sheet SS 410HT plates testing requirements SA 240 TP 410HT sheets welding method
  • Industrial packing techniques
  • Wooden boxes/ crates/ pallets
  • Big rolls with spools
  • Bundles with plastic wrapping
  • Hardness Testing
  • UT testing
  • Packing Condition
  • Dimension Verification
  • Witnessed Chemical Analysis
  • PMI testing
  • Visual Inspection
  • MIG welding
  • TIG welding
  • Resistance welding
Compare AISI 410HT plate, sheet & coil 410 HT stainless steel clad plate surface Benefits of ASTM A240 Type 410HT plates and sheets
  • Sheet thickness: from 0.5 mm up to 6 mm
  • Foil thickness:less than 0.2 mm
  • Plate thickness: at around 6 mm or thick
  • Polished SA 240 Type 410HT sheet: Very Bright finish & precision size; No turning scar
  • Black Surface
  • Machining for plate: Precision & bright ; Little turning scar
  • Turned/ Peeled material: Precision & bright; Little turning scar
  • Grounded: Bright sheet but rough ; Not precision
  • Excellent wear resistance
  • Good heat resistance
  • High strength and hardness
INOX 410HT plate method of cutting 410HT SS sheet documentation provided Delivery schedule of ASTM A240 TP410HT plate
  • Waterjet cutting
  • Oxy-propane flame cutting
  • Plasma cutting
  • Laser cutting

Direct contact with the above-mentioned 410ht stainless steel sheet distributors, dealers, and stockists for those specific cuts

  • Country of Origin Certificate (Original)
  • Copy of Invoice
  • Manufacturer’s Mill Test Certificate certifying, Heat No, finish, Chemical Composition, Grade etc.,
  • Copy of Packing List indicating details of Sizes, quantity, weight, thickness etc.
  • Bill of Lading.
  • Generally it is 7-10 days if its in stock
  • 15-20 days if its not in stock
AISI 410HT flat sheet smelting Forming of ASTM A240 SS 410HT plate Stainless steel 410HT coil heat treatment
  • EAF+ESR: Electro Slag Remelting
  • EAF+LF+VD: Refined-smelting and vacuum degassing
  • VIM+PESR: Vacuum induction melting
  • EAF: Electric Arc Furnace
  • EAF+PESR: protective atmosphere Electro Slag Remelting
  • Hot rolling process
  • Hot Forging
  • +N: Normalized
  • +NT: Normalized and tempered
  • +P: Precipitation hardened
  • +A: Annealed (soft/ full/ spheroidizing)
  • +AT: Solution annealed
  • +QT: Quenched and tempered (oil/ water)

Cold-rolled finish is done for light gauge stainless steel 410HT coil, Buy AISI 410HT flat sheet from certified exporters

AISI 410HT plate types

Alloy 410 HT sheet

Alloy 410 HT sheet

ASTM A240 Type 410HT plate

ASTM A240 Type 410HT plate

EN 2.4660 slitting coil

EN 2.4660 slitting coil

SA 240 Grade 410HT perforated sheet

SA 240 Grade 410HT perforated sheet

410 HT stainless steel foils

410 HT stainless steel foils

AISI 410HT coils

AISI 410HT coils

410HT ferritic stainless steel thin strips

410HT ferritic stainless steel thin strips

Alloy 410HT plain sheet

Alloy 410HT plain sheet

SS 410HT rolling plate

SS 410HT rolling plate

Heat treated 410HT strip

Heat treated 410HT strip

SUS 410HT shim sheet

SUS 410HT shim sheet

INOX 410HT chequered plate

INOX 410HT chequered plate

EN 2.4660 foil chemical composition

C Mn Si P S Cr Ni
0.15 max 1.00 max 1.00 max 0.04 max 0.03 max min: 11.5
max: 13.5
0.50 max

SA 240 Grade 410HT slitting coil mechanical properties

SA 240 Gr 410HT hot rolled plate has high strength and hardness, You can order EN 2.4660 foil in cut to size as per your requirement

Grade Tensile Strength ksi (MPa) min Elongation (% in 50mm) min Yield Strength 0.2% offset ksi (MPa) min Hardness (Rockwell B) MAX Hardness (Brinell) MAX
410HT 65 (450) 20 30 (205) 96 217

Physical properties of 410HT ferritic stainless steel rolling sheet

Density
lbm/in^3
Electrical
Resistivity
(in x 10^-6)
Thermal Conductivity
(BTU/h ft. °F)
Coefficient of
Thermal Expansion
(in/in)/
°F x 10^-6
Modulus of
Elasticity
(psi x 10^6
Melting
Range
(°F)
Specific Heat
(BTU/lb/
°F)
at 68°F: 0.276 56 at 68°F 14.4 at 212°F 5.90 at 68 – 392°F 29 2700 to 2790 0.11 at 68°F to 212°F

Drilling of SA 240 Gr 410HT material

Thickness of SUS 410HT polished plate between 5 to 10 mm, SA 240 Grade 410HT slitting coil are cut with Oxy-Acetylene torch by welders
HSS (Cobalt) Drills Drills with 2 indexable carbide inserts grade GC1020 Solid carbide & carbide tipped drills grades GC1020 & P20
Drill Diameter (inches) ALGOMA 100
surface speed (40 ft./min.)
ALGOMA 130
surface speed (30 ft./min.)
AlgoTuf 400F surface speed (25 ft./min.) AlgoTuf 450F surface speed (15 ft./min.) AlgoTuf 500 surface speed (120* ft./min.) AlgoTuf 500 surface speed (90* ft./min.)
feed (in./rev.) rpm feed (in./rev.) rpm feed (in./rev.) rpm feed (in./rev.) rpm feed (in./rev.) rpm feed (in./rev.) rpm
1/4 0.004 611 0.003 458 0.003 382 0.002 229 0.004 1375
3/8 0.005 407 0.004 306 0.003 255 0.002 153 0.004 917
1/2 0.007 306 0.005 229 0.004 191 0.003 115 0.003 907 0.004 687
5/8 0.007 244 0.006 183 0.004 153 0.003 92 0.003 733 0.005 550
3/4 0.008 204 0.007 153 0.004 127 0.004 76 0.004 611 0.005 458
7/8 0.009 175 0.008 131 0.004 109 0.004 66 0.004 524 0.005 393
1 0.010 153 0.009 115 0.004 96 0.004 57 0.004 458 0.005 344
1 1/8 0.010 136 0.009 102 0.004 85 0.004 51 0.004 407 0.005 306
1 1/4 0.011 122 0.009 92 0.004 76 0.004 46 0.005 367
1 3/8 0.011 111 0.010 83 0.004 70 0.004 42 0.005 333
1 1/2 0.012 102 0.010 76 0.004 64 0.004 38 0.005 306
1 5/8 0.012 94 0.010 71 0.004 59 0.004 35 0.005 282
1 3/4 0.013 87 0.010 66 0.004 55 0.004 33 0.005 262
1 7/8 0.013 82 0.011 61 0.004 51 0.004 31 0.005 244
2 0.014 76 0.011 57 0.004 48 0.004 29 0.005 229

Heat treatment methods for Stainless steel 410HT coil

ASTM A240 UNS S41000 HT rolling sheets has a minimum tensile strength of 70 KSI, Buy from a trusted INOX 410HT shim stock stockists
  • Aging
  • Carburization
  • Carbonitriding
  • Hardening
  • Tempering
  • Normalization
  • Annealing
  • Case Hardening
  • Stress Relieving

Annealing temperature of ASTM A240 Gr 410HT strip

GB 4237 AISI JIS-G 4303 Annealing °C
00Cr12 410L SUS 410L 700-820
1Cr13 410 SUS 410 750-900
0Cr13 410S SUS 410S 750-900
