AISI 1040 Round Bar Core Characteristics
| Sizes in Ready Stock | 3 mm – 800 mm |
|---|---|
| International Standards | ASTM A29, ASTM A510, ASTM A513, UNS G10400, WNR 1.1186 |
| Available Forms | Square, Hex, Rectangular, Round Bar, Ingot, Billet |
| Raw Material Origin | Japanese, American, Indian, Korean, European |
| Surface | Hot Rolled, Pickled, Polished, Hairline |
| Brand | Mukund, ATI, Ratnaveer, Yakin, Outokumpu |
| Fillers | ER70S-2, ER70S-6 |
| Approvals | ADNOC, Q CHEM, EIL, MA’ADEN, KNPC, BAPCO, SABIC, KOC, RINA, KPI, Saudi Aramco |
| Quality Test | Hardness Test, Bending Test, Hydrostatic Test |
| Welding Electrode | AWS E7018, E9018, E11018 |
| Test Certificates |
|
| Tolerances | H13, H10, H12, K10, K9, H8, K12, K11, H11, H9 |
| Technique | Hot and Cold Rolled |
| Shipping Time | Australia : 14 – 20 Days | Nigeria : 35 Days | Panama : 45 – 60 Days |
| MTC | EN 10204 3.1 |
| What’s New? | With 26 Years of Expertise in Oil and Gas Piping Materials, Exploring Middle East FZE Has Introduced a New B2B Platform. |
| Services | Heat Treatment, Shearing, Cutting |
SAE 1040 Hot Rolled Steel Rod Suppliers in UAE
SAE 1040 Hot Rolled Steel Rod Specification
AISI 1040 Round Bar: 3 to 800 mm Dia, 6.1 to 6.4 m (length)
SAE 1040 Square Bar: 4 mm – 100 mm (Size), 2 to 6 m (length)
ASTM A513 1040 Steel Bar: 3 to 100 mm (Size), 3 – 6 m (Length)
Grade 1040 Carbon Steel Bar: 10 to 400 mm (Thickness), 4 to 40 mm (Width)
Standard: ASTM A29, ASTM A510, ASTM A513
Suitable Temperatures: 400°C
Heat Treatment: Age Hardened, Solution Annealed and Cold Worked
MTR: NDT, PMI, Ultrasonic, Eddy Current Test reports
Supply State: PH, H & T, ANN
Obtain Quote Directly From AISI 1040 Round Bar Suppliers in UAE With Data Sheet
Process: Forged and Rolled
Check Grade 1040 Carbon Steel Bar and AISI 1040 Steel Bright Bar Stock Sizes, Weight and Tolerances As Per Customer Requirements
Size Chart of ASTM A513 1040 Steel Bar
| Finish | Size chart (mm) | Size chart (Inch) | ISO Tolerance Chart |
|---|---|---|---|
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8 – 3.00 | h8-h9-h10-h11 |
| Peeled and Ground | 20.00 – 50.00 | 3/4 – 2.00 | h9-h10-h11 |
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6 – 2.50 | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50 – 6.00 | h11, h11-DIN 1013 |
Weight Chart of CS S40C Polished Bar
| Size Chart (Milimeter) | Weight Chart (Kg/meter) | Size Chart (Milimeter) | Weight Chart (Kg/meter) | Size Chart (Milimeter) | Weight Chart (Kg/meter) |
|---|---|---|---|---|---|
| 7 x 7 | 0.337 | 19 x 19 | 2.479 | 38 x 38 | 9.916 |
| 15 x 15 | 1.545 | 30 x 30 | 6.181 | 60 x 60 | 24.723 |
| 9 x 9 | 0.556 | 21 x 21 | 3.029 | 42 x 42 | 12.114 |
| 10 x 10 | 0.687 | 22 x 22 | 3.324 | 45 x 45 | 13.906 |
| 17 x 17 | 1.985 | 34 x 34 | 7.939 | 70 x 70 | 33.65 |
| 11 x 11 | 0.831 | 24 x 24 | 3.956 | 48 x 48 | 15.822 |
| 12 x 12 | 0.989 | 25 x 25 | 4.292 | 50 x 50 | 17.168 |
| 8 x 8 | 0.44 | 20 x 20 | 2.747 | 40 x 40 | 10.988 |
| 13 x 13 | 1.161 | 26 x 26 | 4.642 | 53 x 53 | 19.29 |
| 14 x 14 | 1.346 | 28 x 28 | 5.384 | 55 x 55 | 20.774 |
| 16 x 16 | 1.758 | 32 x 32 | 7.032 | 65 x 65 | 29.015 |
| 18 x 18 | 2.225 | 36 x 36 | 8.9 | 75 x 75 | 38.629 |
Tolerance Chart of Carbon Steel UNS G10400 Cold Drawn Round Bar
| Size Range (mm) | H8 | H12 | H9 | H13 | H10 | H11 |
|---|---|---|---|---|---|---|
| >3-6 | 0 / -0.018 | 0 / -0.12 | 0 / -0.030 | 0 / -0.18 | 0 / -0.048 | 0 / -0.075 |
| 18-30 | 0 / -0.033 | 0 / -0.21 | 0 / -0.052 | 0 / -0.33 | 0 / -0.084 | 0 / -0.130 |
| 6-10 | 0 / -0.022 | 0 / -0.15 | 0 / -0.036 | 0 / -0.22 | 0 / -0.058 | 0 / -0.090 |
| 30-50 | 0 / -0.039 | 0 / -0.25 | 0 / -0.062 | 0 / -0.39 | 0 / -0.100 | 0 / -0.160 |
| 10-18 | 0 / -0.027 | 0 / -0.18 | 0 / -0.043 | 0 / -0.27 | 0 / -0.070 | 0 / -0.110 |
| 50-80 | 0 / -0.046 | 0 / -0.30 | 0 / -0.074 | 0 / -0.46 | 0 / -0.120 | 0 / -0.190 |
Warehouse Locations of Partner Suppliers
| Africa | Nigeria, South Africa, Kenya, Morocco, Egypt, Tunisia, Algeria |
|---|---|
| Middle East Countries | UAE, Saudi, Qatar, Kuwait, Bahrain, Oman, Iraq, Iran, Jordan, Lebanon, Syria, Yemen |
| MENA | Egypt, Morocco, Algeria, Tunisia, Libya, Israel, Palestine |
What Are the Features of Grade 1040 Carbon Steel Bar?
- High Strength
- Versatile
- Cost-Effective
- Excellent Machinability
- High Malleability
Look At the Current Price For SAE 1040 Square Bar And 1040 Cold Rolled Steel Rod in Dubai.
Call Now for Free Sample Which Can Be Arranged From Locations Mentioned Below
| Umm Al Quwain | Sharjah | Doha | Fujairah |
|---|---|---|---|
| Dubai | Muscat | Ras Al Khaimah | Riyadh |
| Abu Dhabi | Saudi Arabia | Ajman | Al Jubail |
Well Known Types of AISI 1040 Round Bar
ASTM A513 1040 Steel Bar
SAE 1040 Square Bar
Grade 1040 Carbon Steel Bar
AISI 1040 CD Steel Round Bar
Steel G10400 Black Bar
CS S40C Polished Bar
Weldability of Steel G10400 Black Bar
| Welding Process | Recommended Filler Metal |
|---|---|
| MIG | ER70S-6 |
| Stick | E7018 |
| TIG | ER70S-2 |
How to Overcome the Machining Challenges of SAE 1040 Hot Rolled Steel Rod?
- Proper Tool Selection
- OptimizeCutting Parameters
- Apply Lubricant
- Employ Chip Control
Buy AISI 1040 CD Steel Round Bar With a Variety of Operations, Including Cold Drawing, Peeling, and Turning Conditions to Ensure That There Are No Cracks or Scales
Surface Conditions of AISI 1040 CD Steel Round Bar
| CD | Cold drawn | P | Polished |
|---|---|---|---|
| P&T | Peeled and turned | RT | Rough turned/peeled |
| ST | Smooth turned | PR | Peeled and reeled |
| CG | Centreless ground | HF | Hot finished |
| BD | Bright drawn | SRE | Slit rolled edge |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
Testing Methods of ASTM A513 1040 Steel Bar
- Visual Inspection
- Hardness Testing
- UT Testing
- PMI Testing
- Radiography Testing
Partner Traders and Importers Are Available in the Regions Mentioned Below for Swift Deliveries
| Country | Cities |
|---|---|
| Netherlands | Eindhoven |
| Belgium | Brussels |
| Belgium | Seraing |
| Netherlands | Haarlem |
| Belgium | Meeuwen-Gruitrode |
| Belgium | Westerlo |
| Netherlands | Rotterdam |
| Belgium | Leuven |
| Netherlands | Amsterdam |
| Belgium | Ghent |
| Netherlands | The Hague |
| Belgium | Antwerp |
What is the Manufacturing Process of CS S40C Polished Bar?
Contact Us If You Need Any AISI 1040 HR Steel Bar and SAE 1040 Steel Rod Quantity Requirements in Dubai
Sales Representatives Across Various Continents
| Region | City | Country |
|---|---|---|
| Middle East | Dubai | United Arab Emirates |
| Africa | Lagos | Nigeria |
| Middle East | Abu Dhabi | United Arab Emirates |
| Africa | Abuja | Nigeria |
| Middle East | Dammam | Saudi Arabia |
| MENA | Casablanca | Morocco |
| Middle East | Riyadh | Saudi Arabia |
| Middle East | Jeddah | Saudi Arabia |
| Africa | Johannesburg | South Africa |
| Middle East | Kuwait City | Kuwait |
| MENA | Cairo | Egypt |
| Middle East | Doha | Qatar |
| Africa | Cape Town | South Africa |
Chemical Composition of SAE 1040 Hot Rolled Steel Rod
| Grade | Mn | S | C | Si | P |
|---|---|---|---|---|---|
| 1040 | 0.60 – 1.00 | 0.06 | 0.35 – 0.45 | 0.05 – 0.35 | 0.06 |
Mechanical Properties of Steel G10400 Black Bar
| Grade | Yield Strength (MPa) | Elongation (%) | Tensile Strength (MPa) | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| 1040 | 210 | 25 | 380 | 50 | 111 HB |
Physical Properties of Carbon Steel UNS G10400 Cold Drawn Round Bar
| Properties | Metric | Imperial |
|---|---|---|
| Density | 7.85 g/cm3 | 0.284 lb/in³ |
Equivalent of Grade 1040 Carbon Steel Bar
| Grade | BS | WNR | EN | UNS |
|---|---|---|---|---|
| 1040 | 080M40 | 1.1186 | EN8 | G10400 |
Industrial Applications of Steel G10400 Black Bar
- Pipelines
- Military
- Construction
- Ships
- Metallurgy
