AISI 4150 Flat Bar Aspects
| Sizes in Ready Stock | 3 – 18 m |
|---|---|
| International Standards | ASTM A29, ASTM A322, UNS G41500, WNR 1.7228 |
| Available Forms | Flat Bar |
| Raw Material Origin | Japanese, American, Indian, Korean, European |
| Surface | Hot Rolled, Pickled, Polished, Hairline |
| Brands | Yakin, Outokumpu, Mukund, ATI, Ratnaveer |
| Verified Outokumpu Dealers and Distributors of AISI 4150 Flat Bar in UAE |
|
| Fillers | ER80S-D2, ER70S-6 |
| Approvals | ADNOC, Q CHEM, EIL, MA’ADEN, KNPC, BAPCO, SABIC, KOC, Saudi Aramco, RINA, KPI |
| Quality Test | Hardness Test, Bending Test, Hydrostatic Test |
| Welding Electrode | AWS E7018, E8018 |
| Test Certificates |
|
| Tolerances | H13, H10, H12, K10, K9, H8, K12, K11, H11, H9 |
| Technique | Hot and Cold Rolled |
| Shipping Time | Burundi : 30 – 60 Days | Ghana : 20 – 45 Days | Namibia : 25 – 45 Days |
| MTC | EN 10204 3.1 |
| What’s New? | Pipingmaterial.ae is a must-visit B2B platform developed by Explore Middle East FZE, a UAE-registered company with over 26 years of hands-on experience in the piping and industrial metals industry. |
| Services | Heat Treatment, Shearing, Cutting |
SAE 4150 Chrome Moly Steel Flats Suppliers in UAE
SAE 4150 Chrome Moly Steel Flats Specification
AISI 4150 Flat Bar: 3 to 18 m (thickness), 5 to 500 mm (width)
Standard: ASTM A29, ASTM A322
Suitable Temperatures: 400°F to 1200°F
Heat Treatment: Age Hardened, Solution Annealed and Cold Worked
MTR: NDT, Ultrasonic, PMI, Eddy Current Test Reports
Supply State: PH, H & T, ANN
Obtain Quote Directly From AISI 4150 Flat Bar Suppliers in UAE With Data Sheet
Process: Forged and Rolled
Request Free Quotes From AISI 4150 Steel Flat Bar Suppliers, Manufacturers, and Exporters in the Middle East
Technical Consultant are Placed in Below Locations to Resolve All Technical Query
| Region | Country | City |
|---|---|---|
| Middle East | United Arab Emirates | Dubai |
| Africa | Nigeria | Lagos |
| Middle East | United Arab Emirates | Abu Dhabi |
| Middle East | Saudi Arabia | Dammam |
| MENA | Morocco | Casablanca |
| Middle East | Saudi Arabia | Riyadh |
| Middle East | Kuwait | Kuwait City |
| MENA | Egypt | Cairo |
| Africa | South Africa | Johannesburg |
| Africa | South Africa | Cape Town |
| Middle East | Saudi Arabia | Jeddah |
| Middle East | Qatar | Doha |
| Africa | Nigeria | Abuja |
Advantages of Grade UNS G41500 Flats
- High Strength-to-Weight Ratio
- Ductility
- Wear Resistance
- Excellent Toughness
- Weldability
Cutting Speeds Recommendations of AISI 4150 Steel Flat Bar
| Application | Vc (m/min) | Vc (SFM) |
|---|---|---|
| Turning | 225-310 | 740-1020 |
| Grooving | 125-170 | 410-560 |
| Parting | 110-150 | 360-490 |
| Milling | 140-190 | 460-620 |
| Drilling | 90-125 | 300-410 |
Key Factors to Consider When Selecting 4150 Steel Flat Bar
Obtain a Quote for the Fabrication and Assembly of SAE 4150 Alloy Steel Flat Rod
Heat Treatment of SAE 4150 Alloy Steel Flat Rod
| Heat Treatment Process | Temperature Range (°C/°F) |
|---|---|
| Annealing | 700 – 800 / 1292 – 1472 |
| Quenching | 850 – 900 / 1562 – 1652 |
| Tempering | 400 – 600 / 752 – 1112 |
Material Inspection Facility in Following Locations
| MENA | Egypt, Morocco, Algeria, Tunisia, Libya, Israel, Palestine |
|---|---|
| Middle East Countries | UAE, Saudi, Qatar, Kuwait, Bahrain, Oman, Iraq, Iran, Jordan, Lebanon, Syria, Yemen |
| Africa | Nigeria, South Africa, Kenya, Morocco, Egypt, Tunisia, Algeria |
Get Annealed High-Strength Alloy Structural Steel For DIN 1.7228 Alloy Steel Flats At 899°C (1650°F) in Dubai
Annealing Temperature of DIN 1.7228 Alloy Steel Flats
| Product | Annealing Temperature |
|---|---|
| DIN 1.7228 Alloy Steel Flats | 800°C – 840°C |
Explore Nearby Locations for the Quickest Delivery Options
| Sharjah | Umm Al Quwain | Fujairah | Doha |
|---|---|---|---|
| Saudi Arabia | Abu Dhabi | Al Jubail | Ajman |
| Muscat | Dubai | Riyadh | Ras Al Khaimah |
AISI 4150 Steel Flat Bar Technical Details
| Size | AISI 4150 flat bar length | Thickenss |
|---|---|---|
|
|
|
| Specification | Tolerance | Mechanical properties |
|
|
|
| Delivery terms | Surface roughness | Temperature range |
|
|
|
| Equivalent | Certifications | Packing |
|
|
|
| Hardness | Testing methods | Machining |
|
|
|
| Shapes | Types | Manufacturing Technique |
|
|
|
| Heat Treatment | Condition | Forging Temperature |
|
|
|
Which Testing Methods Are Mandatory For SAE 4150 Alloy Steel Flat Rod?
- Ultrasonic Test
- Micro Test
- Hardness Test
- Flattening Test
- Macro Test
Grade UNS G41500 Flats in a Variety of Shapes and Sizes Ranging from 7/8″ to 15″
Different Types of AISI 4150 Flat Bar
Alloy Steel 4150 Flat Rod
DIN 1.7228 Alloy Steel Flats
4150 Steel Flat Bar
Grade UNS G41500 Flats
AISI 4150 Steel Flat Bar
SAE 4150 Chrome Moly Steel Flats
Size Chart of Grade UNS G41500 Flats
| Dimensions (mm) | Weight per Metre (kg/m) |
|---|---|
| 20 x 10 | 1.57 |
| 25 x 6 | 1.18 |
| 50 x 12 | 4.71 |
| 25 x 8 | 1.57 |
| 25 x 10 | 1.96 |
| 50 x 6 | 2.36 |
| 25 x 12 | 2.36 |
| 32 x 6 | 1.51 |
| 32 x 8 | 2.01 |
| 40 x 16 | 5.02 |
| 32 x 10 | 2.51 |
| 40 x 5 | 1.57 |
| 40 x 6 | 1.88 |
| 50 x 20 | 7.85 |
| 40 x 8 | 2.51 |
| 32 x 5 | 1.26 |
| 40 x 10 | 3.14 |
| 40 x 12 | 3.77 |
| 25 x 5 | 0.981 |
| 40 x 20 | 6.28 |
| 32 x 12 | 3.01 |
| 50 x 5 | 1.96 |
| 50 x 8 | 3.14 |
| 50 x 10 | 3.93 |
| 50 x 16 | 6.28 |
| 50 x 25 | 9.81 |
Does Your Stockist Carry Stock of DIN 1.7228 Alloy Steel Flats with EN 10204 3.1 MTC?
Chemical Composition of SAE 4150 Alloy Steel Flat Rod
| Grade | Cr | S | P | Mo | C | Si | Mn |
|---|---|---|---|---|---|---|---|
| 4150 | 0.80 – 1.10 | 0.04 | 0.035 | 0.15 – 0.35 | 0.10 | 0.15 – 0.35 | 0.75 – 1.00 |
Mechanical Properties of Grade UNS G41500 Flats
| Properties | Metric | Imperial |
|---|---|---|
| Tensile Strength | 731 MPa | 106000 psi |
| Bulk Modulus | 140 GPa | 20300 ksi |
| Hardness, Knoop | 219 | 219 |
| Shear Modulus | 80 GPa | 11600 ksi |
| Poisson’s Ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at Break (In 50 mm) | 20.20% | 20.20% |
| Yield Strength | 380 MPa | 55100 psi |
| Reduction of Area | 40% | 40% |
| Hardness, Brinell | 197 | 197 |
| Izod Impact | 24 J | 17.7 ft-lb |
| Hardness, Rockwell B | 92 | 92 |
| Elastic Modulus | 190-210 GPa | 27557-30458 ksi |
| Machinability | 55 | 55 |
Equivalent of Alloy Steel 4150 Flat Rod
| ASTM/AISI/SAE | UNS | WNR | GB | BS | DIN | AS/NZ1444 |
|---|---|---|---|---|---|---|
| 4150 | G41500 | 1.7228 | 50CrMo | 708M50 | 1.7228 | AS 4150 |
Applications of 4150 Steel Flat Bar
- Drill Collars
- Shafts
- Forged Gears
- Sprockets
- Aircraft Parts
Storage Sites of Partner Suppliers
| Country | Cities |
|---|---|
| Belgium | Brussels |
| Netherlands | Amsterdam |
| Belgium | Westerlo |
| Belgium | Ghent |
| Netherlands | The Hague |
| Belgium | Seraing |
| Netherlands | Rotterdam |
| Belgium | Leuven |
| Netherlands | Haarlem |
| Belgium | Meeuwen-Gruitrode |
| Netherlands | Eindhoven |
| Belgium | Antwerp |
