ASME b16.36 Class 600 Orifice Flange Highlights
| Flange Manufacturing Type | ASME B16.36 Class 600 Orifice Flange |
|---|---|
| B16.36 Orifice Flange Gaskets Type | Spiral Wound Gasket |
| Size | 1″ To 24″ |
| Applications and Uses | Petrochemicals Industries |
| Manufacturing Specification | ANSI B16.36 |
ANSI B16.36 CL600 Raised Face Orifice Flange and 600LB RF Jack Screw Flanges Suppliers in UAE
ASME B16.36 Class 600 Orifice Flange Dimensions
Buy B16.36 Class 600 Orifice Slip on Flange At A Genuine Price in GCC Countries, Get A Quick Quote From Leading Manufacturers And Exporters
Weight Chart of ASME B16.36 600 RF Orifice Flanges
| Size (Inch) | Size (mm) | Weight (kg) |
|---|---|---|
| 24 | 600 | 365 |
| 20 | 500 | 295 |
| 18 | 450 | 240 |
| 16 | 400 | 190 |
| 14 | 350 | 150 |
| 12 | 300 | 102 |
| 10 | 250 | 86 |
| 8 | 200 | 53 |
| 6 | 150 | 37 |
| 4 | 100 | 19 |
| 3 | 80 | 12.6 |
| 2 1/2 | 65 | 10.8 |
| 2 | 50 | 8.3 |
| 1 1/2 | 40 | 7.8 |
| 1 | 25 | 5.5 |
View ASME B16.36 600lb Orifice Flanges and 600LB Raised Face Jack Screw Flange Standard Sizes, Specification, Equivalent, And Price in Dubai
ASME B16.36 Class 600 Orifice Flange Specification
Dimensions: ASME B16.36
Size Range: NPS: 1″ To 24″
Pressure rating: Class 600
Manufacturing Standard: ANSI B16.36
Marking: B16.36 + Manufacturer Name + Size + Material
Flange Facings: Raised Faces (RF), RTJ (Ring Type Joint) Facings
Get Quote Directly from ASME B16.36 Class 600 Orifice Flange Suppliers
100% Tested ASME B16.36 Class 600 Orifice Flange with MTC EN 10204/3.1
Select The Most Reliable ASME B16.36 600# Weld Neck Orifice Flange Manufacturers in Dubai, And Buy ANSI B16 36 Class 600 Jack Screw Flange At The Best Price in The United Arab Emirates
ANSI B16 36 Class 600 Jack Screw Flange Bolt Chart
| Stud Bolt Length | Bolt Circle | No of Bolts | Hole Diameters | Diameter of Stud Bolt |
|---|---|---|---|---|
| 260 | 603.2 | 20 | 1 5/8 | 1 1/2 |
| 280 | 654.0 | 20 | 1 3/4 | 1 5/8 |
| 300 | 723.9 | 24 | 1 3/4 | 1 5/8 |
| 125 | 88.9 | 4 | 11/16 | 5/8 |
| 195 | 349.2 | 12 | 1 1/4 | 1 1/8 |
| 220 | 431.8 | 16 | 1 3/8 | 1 1/4 |
| 230 | 489.0 | 20 | 1 3/8 | 1 1/4 |
| 240 | 527.0 | 20 | 1 1/2 | 1 3/8 |
| 335 | 838.2 | 24 | 2 | 1 7/8 |
| 135 | 114.3 | 4 | 13/16 | 3/4 |
| 125 | 127.0 | 8 | 11/16 | 5/8 |
| 135 | 149.2 | 8 | 13/16 | 3/4 |
| 135 | 168.3 | 8 | 13/16 | 3/4 |
| 150 | 215.9 | 8 | 1 | 7/8 |
| 180 | 292.1 | 12 | 1 1/8 | 1 |
Explore Nearby Locations for the Quickest Delivery Options
| City | Region | Country |
|---|---|---|
| Dubai | Middle East | United Arab Emirates |
| Abu Dhabi | Middle East | United Arab Emirates |
| Dammam | Middle East | Saudi Arabia |
| Riyadh | Middle East | Saudi Arabia |
| Doha | Middle East | Qatar |
| Abuja | Africa | Nigeria |
| Kuwait City | Middle East | Kuwait |
| Jeddah | Middle East | Saudi Arabia |
| Cairo | MENA | Egypt |
| Casablanca | MENA | Morocco |
| Johannesburg | Africa | South Africa |
| Cape Town | Africa | South Africa |
| Lagos | Africa | Nigeria |
Now No Need To Pay More, Meet B16.36 Cl 600 Orifice Blind Flange Manufacturers in Sharjah And Enjoy Factory Prices in The Middle East And Africa
Material of ASME B16.36 Cl 600 Raised Face Orifice Flange
| Duplex Steel ANSI B16.36 Cl 600 Orifice Blind Flange | Duplex 2205, UNS S31803 (DIN 1.4462), UNS S32205, Super Duplex 2507, UNS S32750 (DIN 1.4410), UNS S32760, ASTM A182 Grade F51, F52, F53, F54, F55, F57, F59, F60, F61, SMO 254, AL6xn, 6Mo, UNS S31254, DIN 1.4547 |
|---|---|
| Nickel Alloy ASME B16.36 600 Rf Orifice Flanges | ASTM B564 / ASME SB 564M, Nickel 200, Alloy 201, Nickel 205LC, Nickel 205 |
| Inconel Class 600 ANSI B16.36 Orifice Plate Flanges |
ASME SB 564 UNS N06600 (Alloy 600) W.Nr. 2.4816, UNS N06601 (Alloy 601) W.Nr. 2.4851, UNS N06617 (Alloy 617) W.Nr. 2.4663a, ASTM B564 UNS N06625 (Alloy 625) W.Nr. 2.4856, UNS N06626 (Alloy 625LCF) W.Nr. 2.4856, UNS N06686 (Alloy 686) W.Nr. 2.4606, UNS N06690 (Alloy 690) W.Nr. 2.4642, UNS N06693 (Alloy 693), UNS N09706 (Alloy 706), UNS N07718 (Alloy 718) W.Nr. 2.4668, UNS N07719 (Alloy 718SPF), UNS N07725 (Alloy 725), UNS N07740 (Alloy 740H), UNS N07750 (Alloy X-750) W.Nr. 2.4669, UNS N07751 (Alloy 751), UNS N07754 (Alloy MA754), UNS R30783 (Alloy 783) |
| Incoloy ASME B16.36 600 Lb Orifice Flange | ASTM B564 UNS N08825, UNS N09925 |
| Incoloy Alloy 20 ANSI B16 36 Class 600 Jack Screw Flange | ASTM B462 UNS N08020 |
| Hastelloy ANSI B16.36 Cl 600 Orifice Blind Flange | ASTM B564 UNS N10276 (Hastelloy C276), UNS N06022 (Hastelloy C22), UNS N06200 (C2000), UNS N06002 (X), UNS N10001 (B), UNS N10665 (B2), UNS N10675 (B3), UNS N06035 (G35), UNS N06985 (G3), UNS N06030 (G30), UNS N06455 (C4), UNS N07022 (C-22HS), UNS N10003 (N), UNS N06635 (S) |
| Monel ASME B16.36 Cl 600 Raised Face Orifice Flange | ASTM B564 UNS N04400, UNS N05500 |
| SS 904L ANSI B16.36 600# Weld Neck Orifice Flange | UNS N08904 |
| Stainless Steel ASME B16.36 600 Rf Orifice Flanges | ASTM A182 Gr 304, 304L, 316, 316L, 310, 310S, 317L, 316Ti, 321, 347, 347H, UNS S66286 |
| Carbon Steel ASME B16.36 600 Rf Orifice Flanges | ASTM A105, A105N, A350 LF2 (LTCS), LF3, AISI 4130, AISI 4140, AISI 4340, AISI 4145 |
| Carbon Steel ASTM A694 ASME B16.36 Class 600 Orifice Pipe Flange | A694 F42, F46, F52, F60, F65, F706 |
| Alloy Steel ASME B16.36 Cl 600 Orifice Slip On Flange | ASTM A182 F5, F9, F11, F22, F91 |
| Cupro Nickel ASME B16.36 Cl 600 Orifice Slip On Flange | Copper Nickel 90/10 and Cuni 70/30 |
| Titanium ASME B16.36 Class 600 Weld Neck Orifice Flanges | Titanium Gr 2, Gr 5 |
Types of ASME B16.36 Class 600 Orifice Flange
ASME B16.36 600 LB Orifice Plate Flanges
ASME B16.36 Cl 600 Weld Neck Orifice Flanges
ANSI B16.36 600# Raised Face Orifice Flange
Class 600 ANSI B16.36 Orifice Slip On Flange
ASME B16.36 600 RF Jack Screw Orifice Flange
ASME B16.36 Class 600 Orifice Pipe Flange
Technical Consultants Are Stationed in the Locations Listed Below to Address All Technical Inquiries
| Muscat | Riyadh | Dubai | Ras Al Khaimah |
|---|---|---|---|
| Sharjah | Fujairah | Umm Al Quwain | Doha |
| Saudi Arabia | Al Jubail | Abu Dhabi | Ajman |
How to Order 600LB RF Jack Screw Flanges in a Custom Sizes?
| NPS | O.D | Flange Height |
|---|---|---|
| 24 | 940 | 203 |
| 20 | 815 | 190 |
| 18 | 745 | 184 |
| 16 | 685 | 178 |
| 14 | 605 | 165 |
| 12 | 560 | 156 |
| 10 | 510 | 152 |
| 8 | 420 | 133 |
| 6 | 355 | 117 |
| 4 | 275 | 102 |
| 3 | 210 | 87 |
| 2½ | 190 | 87 |
| 2 | 165 | 84 |
| 1 | 125 | 81 |
| 1½ | 155 | 84 |
Pressure Rating of ASME B16.36 Class 600 Orifice Flange
| Size in (mm) | Class 600 |
|---|---|
| 600 | 24 |
| 500 | 24 |
| 450 | 20 |
| 400 | 20 |
| 350 | 20 |
| 300 | 20 |
| 250 | 16 |
| 200 | 12 |
| 150 | 12 |
| 100 | 8 |
| 80 | 8 |
| 65 | 8 |
| 50 | 8 |
| 40 | 4 |
| 25 | 4 |
Locate Available Material from Stock
| Middle East countries | Qatar, Lebanon, Bahrain, Saudi, Kuwait, UAE, Jordan, Iraq, Syria, Iran, Yemen |
|---|---|
| Africa | Nigeria, South Africa, Kenya, Morocco, Egypt, Tunisia, Algeria |
| MENA | Morocco, Libya, Algeria, Tunisia, Egypt, Israel, Palestine |
ANSI B16 36 Class 600 Jack Screw Flange Gasket Chart
| NPS | Gasket O.D. Class 600 | Gasket I.D |
|---|---|---|
| 12 | 18 | 12.75 |
| 10 | 15.75 | 10.75 |
| 8 | 12.625 | 8.62 |
| 6 | 10.5 | 6.62 |
| 5 | 9.5 | 5.56 |
| 4 | 7.625 | 4.5 |
| 3 | 5.875 | 3.5 |
| 2 1/2 | 5.125 | 2.88 |
| 2 | 4.375 | 2.38 |
| 1 1/4 | 3.25 | 1.66 |
| 1/2 | 2.125 | 0.84 |
| 1 | 2.875 | 1.31 |
| 1 1/2 | 3.75 | 1.91 |
| 3/4 | 2.625 | 1.06 |
ASME B16.36 Cl 600 Raised Face Orifice Flange Thickness Chart
| Normal Pipe Sizes | Schedule 160 | Schedule 140 | Schedule 100 | Schedule 60 | Schedule 30 | Schedule 120 | Schedule 40 | Schedule 20 | Schedule 80 | Schedule 10 |
|---|---|---|---|---|---|---|---|---|---|---|
| 24 | 2.344 | 2.062 | 1.531 | 0.969 | 0.562 | 1.812 | 0.688 | 0.375 | 1.219 | 0.25 |
| 20 | 1.969 | 1.75 | 1.281 | 0.812 | 0.5 | 1.5 | 0.594 | 0.375 | 1.031 | 0.25 |
| 18 | 1.781 | 1.562 | 1.156 | 0.75 | 0.438 | 1.375 | 0.562 | 0.312 | 0.938 | 0.25 |
| 16 | 1.594 | 1.438 | 1.031 | 0.656 | 0.375 | 1.219 | 0.5 | 0.312 | 0.844 | 0.25 |
| 14 | 1.406 | 1.25 | 0.938 | 0.594 | 0.375 | 1.094 | 0.438 | 0.312 | 0.75 | 0.25 |
| 12 | 1.312 | 1.125 | 0.844 | 0.562 | 0.33 | 1 | 0.406 | 0.25 | 0.688 | 0.18 |
| 10 | 1.125 | 1 | 0.719 | 0.5 | 0.307 | 0.844 | 0.365 | 0.25 | 0.594 | 0.165 |
| 8 | 0.906 | 0.812 | 0.594 | 0.406 | 0.277 | 0.719 | 0.322 | 0.25 | 0.5 | 0.148 |
| 6 | 0.719 | – | – | – | – | 0.562 | 0.28 | – | 0.432 | 0.134 |
| 5 | 0.625 | – | – | – | – | 0.5 | 0.258 | – | 0.375 | 0.134 |
| 2 ½ | 0.375 | – | – | – | – | – | 0.203 | – | 0.276 | 0.12 |
| 3 | 0.438 | – | – | – | – | – | 0.216 | – | 0.3 | 0.12 |
| 3 ½ | – | – | – | – | – | – | 0.226 | – | 0.318 | 0.12 |
| 2 | 0.344 | – | – | – | – | – | 0.154 | – | 0.218 | 0.109 |
| 4 | 0.531 | – | – | – | – | 0.438 | 0.237 | – | 0.337 | 0.12 |
| ½ | 0.188 | – | – | – | – | – | 0.109 | – | 0.147 | 0.083 |
| 1 | 0.25 | – | – | – | – | – | 0.133 | – | 0.179 | 0.109 |
ANSI B16.36 600# Weld Neck Orifice Flange Temperature Wise Pressure Rating
| Temp (°C) | Class 600 |
|---|---|
| 538 | 11.8 |
| 500 | 23.2 |
| 475 | 34.2 |
| 450 | 46 |
| 425 | 57.5 |
| 400 | 69.4 |
| 350 | 80 |
| 375 | 75.7 |
| 325 | 82.6 |
| 300 | 85.7 |
| 200 | 97.2 |
| 250 | 92.7 |
| 150 | 100.3 |
| 100 | 103 |
| 50 | 103.4 |
| -29 – 38 | 103.4 |
Supporting Material for ASME B16.36 Class 600 Orifice Pipe Flange
- Stud and Bolts
- Flanges
- Orifice Plate
- Gaskets
Material Inspection Facilities in the Following Countries
| Country | Cities |
|---|---|
| Netherlands | The Hague |
| Belgium | Meeuwen-Gruitrode |
| Netherlands | Amsterdam |
| Belgium | Antwerp |
| Netherlands | Haarlem |
| Belgium | Brussels |
| Belgium | Seraing |
| Belgium | Ghent |
| Belgium | Leuven |
| Netherlands | Eindhoven |
| Belgium | Westerlo |
| Netherlands | Rotterdam |
What is the ASME B16.36 600# Weld Neck Orifice Flange Inspection and Test Plan?
- Hydro test
- Hardness test
- Pressure test
- PMI test
- Tensile test
What is the Maximum Pressure ASME B16.36 600LB Orifice Flanges Hold?
The ASME B16.36 600LB orifice flanges can hold upto pressure 1481 PSI
