ASME B16.47 Series A Class 150 Weld Neck Flange Quick Overview

Flange Manufacturing Type	ASME B16.47 Series A Class 150 Weld Neck Flange
B16.47 150# Weld Neck Flange Physical Attribute	Thicker, Heavier, Stronger & Larger Diameter Bolting
Size	26″ To 60″
Applications and Uses	Pipe Connection
Manufacturing Specification	MSS SP44

Table of Content

ASME B16.47 Series A Class 150 Weld Neck Flange Dimensions Chart
What Is The ASME B16.47 Series A Cl 150 Rf Weld Neck Flange Temperature Range ?
ASME B16.47 Series A Class 150 Weld Neck Flange Specification
Bolt Chart Series A Class 150 Wnrf Flange
ANSI B16.47 Series A Class 150 Welding Neck Material
Common Types of B16.47 Series A Class 150 Weld Neck Flange
B16.47 Series A Class 150 Weld Neck Flange Pressure Ratings
What Are The Benefits of Series A 150 Lb Wn Flange ?
ASME B16.47 Series A Class 150 Weld Neck Flange Weight Chart
How Much Pressure Can A ASME B16.47 Series A Class 150 Weld Neck Flange Take ?
ASME B16.47 Series A Class 150 Weld Neck Flange Thickness Chart
Surface Treatment for B16.47 Series A Class 150 Weld Neck Flange
ASME B16.47 Series A Class 150 Weld Neck Flange Melting Point
Which Testing Required To Check Strength Of Series A Wnrf Flange ?
Isometric Symbol for ASME B16.47 Series A 150# Weld Neck Flange
Where Are Series A Class 150 Wnrf Flange Used ?
ASME B16.47 Series A Class 150 Raised Face Weld Neck Flange Major Advantages

Check Series A WNRF flange dimension and ANSI b16.47 Sr A welding neck flange weight chart

ASME B16.47 Series A Class 150 Weld Neck Flange Dimensions Chart

Nominal Sizes (Inch)	Thickness (Min.) (T)	Outside Diameter (O.D.) (O)	Hub Diameter (X)	Raised Face Diameter (R)	Top of Hub (A)	Diameter of Holes	Bolt Circle (C)	Length Thru Hub (Y)	Minimum Fillet Radius (r)	Approximate Weight (lbs)	Number of Holes
60	5.19	73	61.38	66	60	1.88	69.25	9.44	0.50	2045	52
58	5.06	71	59.38	64	58	1.88	67.25	9.25	0.50	1915	48
56	4.88	68.75	57.38	62	56	1.88	65	9	0.50	1760	48
54	4.75	66.25	55.25	59.50	54	1.88	62.75	8.50	0.50	1585	44
52	4.56	64	53.25	57.50	52	1.88	60.50	8.25	0.50	1410	44
50	4.38	61.75	51.25	55.50	50	1.88	58.25	8	0.50	1270	44
48	4.25	59.50	49.12	53.50	48	1.62	56	7.56	0.50	1185	44
46	4.06	57.25	47.12	51	46	1.62	53.75	7.31	0.50	1060	40
44	4	55.25	45	49	44	1.62	51.75	7	0.50	990	40
42	3.81	53	43	47	42	1.62	49.50	6.75	0.50	890	36
40	3.56	50.75	41	44.25	40	1.62	47.25	6.44	0.50	775	36
38	3.44	48.75	39	42.25	38	1.62	45.25	6.19	0.50	720	32
36	3.56	46	36.75	40.25	36	1.62	42.75	6.19	0.50	640	32
34	3.25	43.75	34.75	38	34	1.62	40.50	5.88	0.50	540	32
32	3.19	41.75	32.75	36	32	1.62	38.50	5.69	0.44	505	28
30	2.94	38.75	30.75	33.75	30	1.38	36	5.38	0.44	400	28
28	2.81	36.50	28.62	31.50	28	1.38	34	4.94	0.44	345	28
26	2.69	34.25	26.62	29.50	26	1.38	31.75	4.75	0.38	300	24

What Is The ASME B16.47 Series A Cl 150 Rf Weld Neck Flange Temperature Range ?

The Temperature Range for Series A 150 Lbs Weld Neck Pipe Flanges is Upto -19°C To 800°F (-7°C To 426°C).

ASME B16.47 Series A Class 150 Weld Neck Flange Specification

Dimensions: ASME B16.47 Series A

Size Range: NPS: 26″ – 60″

Pressure Rating : Class 150 (26″ – 60″)

Manufacturing Standard: MSS SP44

Marking: MSS SP-44 + Manufacturer Name + Size + Material

Flange Facings: Ring Joint (RTJ), Raised Face (RF), Flat Face (FF)
