ASME B16 47 Series A Class 600 Weld Neck Flange Unique Features
| Flange Manufacturing Type | ASME B16.47 Series A Class 600 Weld Neck Flange |
|---|---|
| ASME B16.47 Class 600 Weld Neck Flange Physical Attribute | Heavier, Thicker, Larger & Stronger Diameter Bolting |
| Size | 26″ To 60″ |
| Applications and Uses | Connection on Pipe Lines |
| Manufacturing Specification | MSS SP44 |
Check Sr A 600# WNRF flange and ANSI b16.47 series a class 600 welding neck flange dimension in mm
ASME B16.47 Series A Class 600 Weld Neck Flange Dimensions Chart
| Nominal Size (Inch) | Outside Diameter (O) | Raised Face Diameter (R) | Minimum Fillet Radius (r) | Length Thru Hub (Y) | Min Thickness (T) | Hub Diameter (X) | Top of Hub (A) | Bolt Circle (C) | Diameter of Holes | Approximate Weight (lbs) | Number of Holes | Bore (B) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 60 | 78.50 | 65.25 | 0.69 | 15.31 | 9.19 | 63.38 | 60 | 71.75 | 3.62 | 5000 | 28 | Specified by Purchaser |
| 58 | 75 | 63 | 0.62 | 14.56 | 8.75 | 61.12 | 58 | 68.75 | 3.38 | 4640 | 32 | Specified by Purchaser |
| 56 | 73 | 60.75 | 0.62 | 14.25 | 8.56 | 59.12 | 56 | 66.75 | 3.38 | 4280 | 32 | Specified by Purchaser |
| 54 | 70 | 58.75 | 0.56 | 13.75 | 8.25 | 57 | 54 | 64.25 | 3.12 | 3920 | 32 | Specified by Purchaser |
| 52 | 67.75 | 56.50 | 0.56 | 13.25 | 8 | 54.88 | 52 | 62 | 3.12 | 3560 | 32 | Specified by Purchaser |
| 50 | 65.75 | 54.50 | 0.56 | 12.94 | 7.75 | 52.88 | 50 | 60 | 3.12 | 3330 | 28 | Specified by Purchaser |
| 48 | 62.75 | 52.50 | 0.56 | 12.44 | 7.44 | 50.75 | 48 | 57.50 | 2.88 | 2855 | 32 | Specified by Purchaser |
| 46 | 59.50 | 50.25 | 0.56 | 11.81 | 7.06 | 48.62 | 46 | 54.75 | 2.62 | 2410 | 32 | Specified by Purchaser |
| 44 | 57.25 | 48.25 | 0.56 | 11.38 | 6.81 | 46.50 | 44 | 52.50 | 2.62 | 2160 | 32 | Specified by Purchaser |
| 42 | 55.25 | 46 | 0.56 | 11 | 6.62 | 44.38 | 42 | 50.50 | 2.62 | 2030 | 28 | Specified by Purchaser |
| 40 | 52 | 43.75 | 0.56 | 10.38 | 6.25 | 42.25 | 40 | 47.75 | 2.38 | 1630 | 32 | Specified by Purchaser |
| 38 | 50 | 41.50 | 0.56 | 10 | 6 | 40.25 | 38 | 45.75 | 2.38 | 1470 | 28 | Specified by Purchaser |
| 36 | 51.75 | 40.25 | 0.56 | 11.12 | 4.88 | 40.62 | 36 | 47 | 2.62 | 1705 | 28 | Specified by Purchaser |
| 34 | 49 | 38 | 0.56 | 10.62 | 4.75 | 38.31 | 34 | 44.50 | 2.38 | 1540 | 28 | Specified by Purchaser |
| 32 | 47 | 36 | 0.50 | 10.25 | 4.62 | 36.12 | 32 | 42.50 | 2.38 | 1375 | 28 | Specified by Purchaser |
| 30 | 44.50 | 33.75 | 0.50 | 9.75 | 4.50 | 33.94 | 30 | 40.25 | 2.12 | 1210 | 28 | Specified by Purchaser |
| 28 | 42.25 | 31.50 | 0.50 | 9.25 | 4.38 | 31.62 | 28 | 38 | 2.12 | 1060 | 28 | Specified by Purchaser |
| 26 | 40 | 29.50 | 0.50 | 8.75 | 4.25 | 29.44 | 26 | 36 | 2 | 940 | 28 | Specified by Purchaser |
What Can Cause Series A 600 Lb Wn Flange To Rust ?
- Condition of Corrosive Environment
- Improper Cleanliness of Material
- Damaged Surface Treatment
- Exposure through out Moisture
- Higher Oxidation
ASME B16.47 Series A Class 600 Weld Neck Flange Specification
Size Range: NPS: 26″ to 60″
Dimensions: ASME B16.47 Series A
Pressure Rating : Class 600 (26″ – 60″)
Manufacturing Standard: MSS SP 44
Marking: MSS SP-25 + Manufacturer Name + Size + Material
Flange Facings: Flat Face (FF), Raised Face (RF), Ring Joint (RTJ)
Get Quote Directly from ASME B16.47 Series A Class 600 Weld Neck Flange
Suppliers
100% Tested ASME B16.47 600# Weld Neck Flange Flange with MTC EN 10204/3.1
Bolt Chart for Series A 600 Lbs Weld Neck Pipe Flanges
