ASME B16.47 Series B Class 300 Blind Flange Quick Overview
| Flange Manufacturing Type | ASME B16.47 Series B Class 300 Blind Flange |
|---|---|
| B16.47B Blind Flange Physical Attribute | Smaller, Light Diameter Bolting |
| Size | 26″ To 60″ |
| Applications and Uses | Offshore Applications |
| Manufacturing Specification | API 605 |
Check sr b cl300 BLRF flange sizes and ANSI b16.47 series b 300# blank flange dimension
ASME B16.47 Series B Class 300 Blind Flange Dimensions Chart
| Nominal Sizes (Inch) | Thck. (T) (min.) | Outside Diameter (O) (O.D.) | Bolt Circle (C) | Raised Face Diameter (R) | Diameter of Holes | Approx. Weight (lbs) | Number of Holes |
|---|---|---|---|---|---|---|---|
| 60 | 6.56 | 73.94 | 69.44 | 65 | 2.38 | 7980 | 40 |
| 58 | 6.38 | 71.94 | 67.44 | 62.75 | 2.38 | 7347 | 40 |
| 56 | 6.18 | 69.50 | 65 | 60.50 | 2.38 | 6642 | 36 |
| 54 | 5.88 | 65.88 | 62.12 | 58.25 | 2 | 5679 | 48 |
| 52 | 5.68 | 63.50 | 59.75 | 56.25 | 2 | 5096 | 48 |
| 50 | 5.50 | 61.50 | 57.75 | 54.25 | 2 | 4629 | 44 |
| 48 | 5.31 | 59.50 | 55.75 | 52.25 | 2 | 4183 | 40 |
| 46 | 5.12 | 57.50 | 53.75 | 50 | 2 | 3766 | 36 |
| 44 | 5 | 54.50 | 51 | 48 | 1.88 | 3305 | 40 |
| 42 | 4.69 | 52.50 | 49 | 46 | 1.88 | 2875 | 36 |
| 40 | 4.56 | 50.12 | 46.88 | 43.88 | 1.75 | 2550 | 40 |
| 38 | 4.38 | 48.12 | 44.88 | 41.75 | 1.75 | 2257 | 36 |
| 36 | 4.06 | 46.12 | 42.88 | 39.75 | 1.75 | 1920 | 32 |
| 34 | 4.06 | 43.62 | 40.62 | 37.50 | 1.62 | 1719 | 36 |
| 32 | 4.06 | 41.50 | 38.50 | 33.50 | 1.62 | 1556 | 32 |
| 30 | 3.69 | 39 | 36.25 | 33.25 | 1.50 | 1250 | 36 |
| 28 | 3.50 | 36.25 | 33.75 | 31 | 1.38 | 1023 | 36 |
| 26 | 3.50 | 34.12 | 31.62 | 29 | 1.38 | 905 | 32 |
What is a life expectancy of B16.47 300# Series B BLRF Flange ?
- The life expectancy of B16.47 300# Series B BLRF Flange is Approximately About 10 Yrs.
ASME B16.47 Series B Class 300 Blind Flange Specification
Dimensions: ASME B16.47 Series B
Size Range: NPS: 26″ to 60″
Pressure Rating : Class 300 (26″ – 60″)
Manufacturing Standard: API 605
Marking: API 605 + Manufacturer Name + Size + Material
Flange Facings: Raised Face (RF), Ring Joint (RTJ), Flat Face (FF)
Get Quote Directly from ASME B16.47 Series B Class 300 Blind Flange Suppliers
100% Tested ASME B16.47 300# Blind Flange with MTC EN 10204/3.1
Bolt Chart for B16.47 Series B cl300 Blind Flanges
| Nominal Sizes (Inch) | Outside Diameter (O.D.) | Bolt Circle | Hole Diameter | Number of Holes |
|---|---|---|---|---|
| 60 | 73.94 | 69.44 | 2.38 | 40 |
| 58 | 71.94 | 67.44 | 2.38 | 40 |
| 56 | 69.50 | 65 | 2.38 | 36 |
| 54 | 65.88 | 62.12 | 2 | 48 |
| 52 | 63.50 | 59.75 | 2 | 48 |
| 50 | 61.50 | 57.75 | 2 | 44 |
| 48 | 59.50 | 55.75 | 2 | 40 |
| 46 | 57.50 | 53.75 | 2 | 36 |
| 44 | 54.50 | 51 | 1.88 | 40 |
| 42 | 52.50 | 49 | 1.88 | 36 |
| 40 | 50.12 | 46.88 | 1.75 | 40 |
| 38 | 48.12 | 44.88 | 1.75 | 36 |
| 36 | 46.12 | 42.88 | 1.75 | 32 |
| 34 | 43.62 | 40.62 | 1.62 | 36 |
| 32 | 41.50 | 38.50 | 1.62 | 32 |
| 30 | 39 | 36.25 | 1.50 | 36 |
| 28 | 36.25 | 33.75 | 1.38 | 36 |
| 26 | 34.12 | 31.62 | 1.38 | 32 |
Buy ASME b16 47 300lb series b BLRF flange in various materials, get a fast quote now and compare prices of different suppliers in the middle east
ASME B16.47 Series B Class 300 Blind Flange Material
Machining Equipment of ANSI B16.47 Series B Class 300 Flanges
- Press
- Pushing
- Electric Bevell
- Bending
- Sand Blasting
Without a middleman your direct purchasing of b16.47 series b cl 300 blank flanges can save you 30%-40% cost in UAE
ASME B16.47 Series B Class 300 Blind Flange Common Types
ASME B16.47 Series B Class 300 Blind Flange
Class 300 B16.47 Sr B Blind Flange
ASME B16 47 Serie B Class 300 Blind Flange
ANSI B16.47 Serie B 300# Blind Flange
300 Lbs B16.47 Serie B Blind Flange
Serie B B16.47 Cl 300 Blind Flange
Material Inspection Facilities in the Following Countries
| Country | Cities |
|---|---|
| Netherlands | The Hague |
| Belgium | Meeuwen-Gruitrode |
| Netherlands | Amsterdam |
| Belgium | Antwerp |
| Netherlands | Haarlem |
| Belgium | Brussels |
| Belgium | Seraing |
| Belgium | Ghent |
| Belgium | Leuven |
| Netherlands | Eindhoven |
| Belgium | Westerlo |
| Netherlands | Rotterdam |
ASME B16 47 Class 300 Series B Blrf Flange Weight Chart
| Flange Sizes (Inch) | Outside Diameter (O.D.) | Weight in Lbs |
|---|---|---|
| 60 | 73.94 | 7980 |
| 58 | 71.94 | 7347 |
| 56 | 69.50 | 6642 |
| 54 | 65.88 | 5679 |
| 52 | 63.50 | 5096 |
| 50 | 61.50 | 4629 |
| 48 | 59.50 | 4183 |
| 46 | 57.50 | 3766 |
| 44 | 54.50 | 3305 |
| 42 | 52.50 | 2875 |
| 40 | 50.12 | 2550 |
| 38 | 48.12 | 2257 |
| 36 | 46.12 | 1920 |
| 34 | 43.62 | 1719 |
| 32 | 41.50 | 1556 |
| 30 | 39 | 1250 |
| 28 | 36.25 | 1023 |
| 26 | 34.12 | 905 |
Check ANSI b16.47 sr b 300 blind flange dimension in mm, size & pressure rating
What are the uses and applications of Series B 300 Lbs BLRF Flange ?
Professional ASME B16.47 Series B Class 300 Blind Flange Supplier in UAE providing custom flange which are manufactured by superior material science.
4 Major Advantages of using ASME B16.47 Cl 300 SR B Blank flange
- Higher Strength Material
- Seal Integrity is Enhanced
- Durable
- Easeier To Installation
ANSI B16.47 Series B Class 300 Blind Flanges Pressure Rating Chart
| Temperature in °C | Class Pressure Rating |
|---|---|
| 538 | 5.9 |
| 500 | 11.6 |
| 475 | 17.1 |
| 450 | 23.0 |
| 400 | 34.7 |
| 425 | 28.8 |
| 375 | 37.8 |
| 350 | 40.0 |
| 325 | 41.4 |
| 300 | 42.9 |
| 250 | 46.3 |
| 200 | 48.6 |
| 150 | 50.2 |
| 100 | 51.5 |
| 50 | 51.7 |
| -29 – 38 | 51.7 |
View the list of very few but verified suppliers and get the perfect series b 300 lbs BLRF flange at the best price in Dubai
How to find out the right ASME B16 47 Class 300 Series B Blrf Flange dimensions ?
To Find Out The Right ASME B16 47 Class 300 Series B BLRF Flange Dimensions :
- Identification of Material Size
- Check The Correct Class Pressure Rating
- Refering to Class 300 Flange Standard
- Check the Series whether it is “A” or “B”
- Compatibility of Material
Explore Nearby Locations for the Quickest Delivery Options
| City | Region | Country |
|---|---|---|
| Dubai | Middle East | United Arab Emirates |
| Abu Dhabi | Middle East | United Arab Emirates |
| Dammam | Middle East | Saudi Arabia |
| Riyadh | Middle East | Saudi Arabia |
| Doha | Middle East | Qatar |
| Abuja | Africa | Nigeria |
| Kuwait City | Middle East | Kuwait |
| Jeddah | Middle East | Saudi Arabia |
| Cairo | MENA | Egypt |
| Casablanca | MENA | Morocco |
| Johannesburg | Africa | South Africa |
| Cape Town | Africa | South Africa |
| Lagos | Africa | Nigeria |
Which Are The Bolt Types are Most used with ANSI B16.47 Series B Class 300 Blind Flange ?
Technical Consultants Are Stationed in the Locations Listed Below to Address All Technical Inquiries
| Muscat | Riyadh | Dubai | Ras Al Khaimah |
|---|---|---|---|
| Sharjah | Fujairah | Umm Al Quwain | Doha |
| Saudi Arabia | Al Jubail | Abu Dhabi | Ajman |
ASME B16.47 Series B Class 300 Blind Flange Soft Gaskets Chart
| Nominal Sizes (Inch) | Inside Daimeter (I.D.) | Outside Diameter (O.D.) |
|---|---|---|
| 60 | 1524 | 1705 |
| 58 | 1473 | 1656 |
| 56 | 1422 | 1594 |
| 54 | 1372 | 1530 |
| 52 | 1321 | 1470 |
| 50 | 1270 | 1419 |
| 48 | 1219 | 1368 |
| 46 | 1168 | 1318 |
| 44 | 1118 | 1251 |
| 42 | 1067 | 1200 |
| 40 | 1016 | 1149 |
| 38 | 965 | 1099 |
| 36 | 914 | 1048 |
| 34 | 864 | 994 |
| 32 | 813 | 940 |
| 30 | 762 | 886 |
| 28 | 711 | 826 |
| 26 | 660 | 772 |
3 Main Gaskets Types are Mostly Used While The Connection of Series B B16.47 300# Blind Flange
Looking for top-quality ASME B16.47 Series B Class 300 Blind Flange ? We stock materials sourced from Sharjah and Umm Al Quwain.
How much does it cost to replace Sr B Cl300 BLRF Flange ?
- The cost to replace Sr B Cl300 BLRF Flange is Upto 220.35 AED to 257.07 AED per piece.
