SA 333 Gr 6 Material and A333 Seamless Pipe manufacturers in UAE

ASTM A333 Grade 6 Pipe

What is ASTM A333 Grade 6 Pipe?

The ASTM A333 Grade 6 pipe covers nominal wall welded seamless carbon alloy steel pipes that are intended to work in lower temperature conditions. The ASTM A333 grade 6 is designed with a chemical composition of carbon, manganese, phosphorus, sulfur, and silicon. This gives the A333 Grade 6 pipe good corrosion and oxidation resistance in harsh environments.

A333 pipe material of grade 6 is designed with excellent mechanical properties. The material has a minimum tensile strength of 415mpa. The A333 Gr 6 material exhibits a minimum yield strength of 240mpa and can be elongated by 30 percent in the system.

The SA333 gr6 pipes are designed in nominal sizes of 1/2 NB to 36 NB and range in thickness between 3 to 12mm. LTCS ASTM A333 Gr 6 pipes are designed in schedules of SCH 40 to SCH 160 and XXS. The pipes are designed in the form of round and hydraulic shapes. The grade 6 of A333 pipe is available in lengths up to 18 meters or customizable

Verified Supplier

Verified Stockists (Contact directly for instant quote)

available 7 cars
Supplier 48
1
Mumbai, India
Superior Steel
  • marketing@superiorsteel.in
  • +91 9819618303
Supplier 108
1
Mumbai, India
Anil Metal Corporation
  • info@anilmetaldesigns.com
  • +91 9757470194
Supplier 89
1
Mumbai, India
Metal Tubular Products
  • sales@metaltubulars.com
  • +91 9987358891
Supplier 92
1
Mumbai, India
Sagar Steel Corporation
  • sales@sagarsteel.co.in
  • +91 9820137788
Supplier 82
1
Mumbai, India
Hitech Metal
  • export@hitechoverseas.com
  • +91 9819580099
Supplier 78
1
Mumbai, India
Neelcon Steel
  • info@neelconsteel.com
  • +91 9819591024
Aesteiron Steels LLP
1
Mumbai, India
Aesteiron Steels LLP
  • info@aesteiron.com
  • +91 9820032977

Piping Material

Table of Content

ASTM A333 Grade 6 Pipe

A333 Gr 6 Specification

  • Sizes: 1/8” – 24”
  • Pipe ASTM A333 Grade 6 for low temperature applications at greater than -45 °C.
  • Schedules: SCH 20, SCH 10, SCH STD, SCH 40, SCH XS to SCH 160, SCH 80, SCH XXS
  • Length: Double Random Length, Single Random Length, 40 ft, 20 ft
  • Coatings: 3LPE/3PE, Galvanized, FBE, CRA,Varnished or stainless lined and clad
  • Ends Types: Beveled, Plain
  • Manufacturing Type: Seamless, Welded, ERW



What are Heat Treatment, Hot & Cold Working processes used by ASTM A333 Grade 6 manufacturers?

The A333 Gr 6 manufacturer’s supply material is in a normalized condition of 1500 degrees f and is air cooled later. The material can be quenched or tempered to give it specific qualities. The material can also be forged, hot or cold worked. The A333 material can also be annealed at 1600 degrees F and air cooled. The grade usually hardens after the hot and cold working process.



Find trusted and audited A333 Grade 6 Pipe suppliers in Middle East and buy LTCS Pipe and SA333 Gr 6 Material 10% to 40% cheaper price



What is LTCS Pipe? Under which temperature range A333 gr 6 can sustain?

An LTCS pipe is a low temperature carbon steel pipe designed to work in cryogenic temperature conditions. The grade 6 A333 low temp pipe can work in temperatures of -45℃.



Price list of ASTM A333 Grade 6 Pipe

ASTM A333 Seamless Pipe Price
SIZE” SIZE NB USD/ Ton
1/2 15  1,550.00
3/4 20  1,310.00
1 25  1,060.00
1.25 32  1,010.00
1.5 40     995.00
2 50     880.00
2.5 65     880.00
3 80     880.00
3.5 90     880.00
4 100     880.00
5 125     880.00
6 150     880.00
8 200     880.00

Notes:

  1. Above Price USD/Ton
  2. PE ends : Below 2″ diameter pipe
  3. BE ends: up to 2″ diameter pipe



LTCS Pipe Grades

This standard is divided into 9 grades: Grades 3, 1, 6, 4, 8, 7, 10, 9, and 11.

LTCS Pipe Grades



Difference between A333 gr 1, SA 333 gr 3 and SA333 gr6

The SA333 pipe is a low carbon grade steel. These pipes are designed in three different grades, namely gr 1, 3, and 6.

  • The A333 gr 1 has a chemical composition of carbon, manganese, phosphorous, and sulfur. The grade has a minimum tensile strength of 380mpa with a minimum yield strength of 205mpa.
  • The SA 333 gr 3 has a chemical content of silicon, nickel, carbon, phosphorous, sulfur, and manganese. The grade has a minimum tensile strength of 240mpa with a minimum tensile strength of 450mpa.
  • The SA 333 Gr 6 has a chemical composition consisting of silicon, carbon, phosphorous, sulfur, and manganese. It has a minimum tensile strength of 415mpa with a minimum yield strength of 240mpa.



Most Popular Types of A333 low temp pipe

A333 low temp pipe

A333 low temp pipe

ASTM A333 Grade 6 Pipe

ASTM A333 Grade 6 Pipe

LTCS Pipe

LTCS Pipe

SA 333 Gr 6 Pipe

SA 333 Gr 6 Pipe

A333 Seamless Pipe

A333 Seamless Pipe

SA333 Pipe

SA333 Pipe

SA 333 gr 3 Pipe

SA 333 gr 3 Pipe

A333 gr 1 Pipe =

A333 gr 1 Pipe

A333 Steel Pipe

A333 Steel Pipe



Types of A333 Pipe Coating

Types of A333 Pipe Coating

  • Epoxy Coated
  • 3LPE Coated
  • FBE Coated
  • LPE Coating And Lining
  • Black Paint Coated
  • Galvanizing Coated
  • Varnish Coated
  • 3LPP Coated
  • Dual Layer FEB
  • Anti-Corrosion Paint



Does A333 Seamless Pipe epoxy coating prevent corrosion?

The A333 seamless pipe of gr 6 epoxy coated pipe is lined with a protective coat. The thick coat of epoxy acts as a barrier between oxidizing material in the environment. The A333 Grade 6 seamless pipe is thereby highly reliable against corrosive affluents in different conditions.



A333 Pipe Material in Sch-80, Sch-40, Sch-5, Sch-10, and STD suitable for seawater, sewage/ drain, fire water & flare system



SA 333 Gr 6 Pipe Schedule

NB Size OD 5S 40S 10S S20 S10 S40 XS/80S S60 S100 S80 S120 S160 S140 XXS
mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm
1/4” 13.72 1.7 2.24 3.02
1/8” 10.29 1.2 1.73 2.41
3/8” 17.15 1.7 2.31 3.2
20 3/4” 26.67 1.7 2.9 2.1 2.87 3.91 3.91 5.56 7.82
15 1/2” 21.34 1.7 2.8 2.1 2.77 3.73 3.73 4.78 7.47
25 1” 33.4 1.7 3.4 2.8 3.38 4.55 4.55 6.35 9.09
40 1 1/2” 48.26 1.7 3.7 2.8 3.68 5.08 5.08 7.14 10.2
32 1 1/4” 42.16 1.7 3.6 2.8 3.56 4.85 4.85 6.35 9.7
50 2” 60.33 1.7 3.9 2.8 3.91 5.54 5.54 9.74 11.1
80 3” 88.9 2.1 5.5 3.1 5.49 7.62 7.62 11.1 15.2
65 2 1/2” 73.03 2.1 5.2 3.1 5.16 7.01 7.01 9.53 14
350 14” 355.6 4 9.5 4.8 7.9 6.4 11.1 12.7 15.1 23.8 19.1 27.8 35.7 31.8
90 3 1/2” 101.6 2.1 5.7 3.1 5.74 8.08 8.08
125 5” 141.3 2.8 6.6 3.4 6.55 9.53 9.53 12.7 15.9 19.1
300 12” 323.9 4 9.5 4.6 6.4 10.3 12.7 14.3 21.4 17.5 25.4 33.3 28.6 25.4
100 4” 114.3 2.1 6 3.1 6.02 8.56 8.56 11.1 13.5 17.1
150 6” 168.3 2.8 7.1 3.4 7.11 10.97 11 14.3 18.3 22
250 10” 273.1 3.4 9.3 4.2 6.4 9.27 12.7 12.7 19.3 15.1 21.4 28.6 25.4 25.4
200 8” 219.1 2.8 8.2 3.8 6.4 8.18 12.7 10.3 15.1 12.7 19.3 23 20.6 22.2
400 16” 406.4 4.2 9.5 4.8 7.9 6.4 12.7 12.7 16.7 26.2 21.4 31 40.5 36.5



Industrial Application of A333 Seamless Pipe

Industrial Application of A333 Seamless Pipe

  • Natural Gas Transmission
  • Refineries
  • Boiler Industry
  • Pump Oil or Gas
  • Compressor Stations
  • Generator Plants
  • Steam Conduction



Can SA 333 Gr 6 be used in nuclear power plants? Other uses and applications of A333 Gr 6 material

The SA 333 gr 6 grade is a reliable choice for nuclear power plants. The high thermal conductivity and thermal expansion allow them to work in heavy water cooled gas reactors. The grades are also seen in petrochemical, marine, food processing, and in oil and gas industries.



Check A333 Grade 6 Seamless Pipe & SA 333 gr 6 chemical composition and price per kg in Dubai



LTCS ASTM A333 Gr 6 Pipe Weight Chart

Size Other Diameter WT Pipe I.D. Gallon Standard to XXHY Section Modulus Weight Schedule
Pipe #
3/4 1.05 0.113 0.824 .0277 STD .0705 1.13 40
0.219 0.612 .0153 .1006 1.95 160
0.154 0.742 .0225 XHY .0853 1.48 80
1/2 0.84 0.109 0.622 .0158 STD .0407 0.85 40
0.188 0.464 .0088 .0528 1.31 160
0.147 0.546 .0122 XHY .0478 1.09 80
1 1/4 1.66 0.140 1.380 .0777 STD .2346 2.27 40
0.250 1.160 .0549 .3421 3.77 160
0.191 1.278 .0666 XHY .2913 3.00 80
1 1.315 0.133 1.049 .0449 STD .1328 1.68 40
0.250 0.815 .0271 .1904 2.85 160
0.179 0.957 .0374 XHY .1606 2.17 80
2 2.375 0.109 2.157 .1898 .4205 2.64 10
0.154 2.067 .1743 STD .5606 3.66 40
0.344 1.687 .1161 .9806 7.47 160
0.281 1.813 .1344 .8666 6.29
0.218 1.939 .1534 XHY .7309 5.03 80
0.250 1.875 .1434 .8045 5.68
1 1/2 1.90 0.145 1.610 .1058 STD .3262 2.72 40
0.281 1.338 .0730 .5079 4.86 160
0.200 1.500 .0918 XHY .4118 3.63 80
3 3.50 0.120 3.260 .4336 1.0411 4.34
0.156 3.188 .4147 1.3122 5.58
0.188 3.124 .3984 1.5342 6.66
0.438 2.624 .2811 2.8774 14.34 160
0.172 3.156 .4064 1.4265 6.12
0.300 2.900 .3431 XHY 2.2253 10.26 80
0.216 3.068 .3840 STD. 1.7241 7.58 40
0.250 3.000 .3672 1.9372 8.69
0.281 2.938 .3521 2.1207 9.67
2 1/2 2.875 0.120 2.635 .2833 .6870 3.53 10
0.250 2.375 .2301 1.2468 7.02
0.203 2.469 .2487 STD. 1.0640 5.80 40
0.216 2.443 .2435 1.1169 6.14
0.276 2.323 .2202 XHY 1.3386 7.67 80
0.375 2.125 .1842 1.6371 10.02 160
3 1/2 4.0 0.120 3.760 .5768 1.3776 4.98 10
0.318 3.364 .4617 XHY 3.1400 12.52 80
0.226 3.548 .5136 STD. 2.3939 9.12 140
0.250 3.500 .4998 2.6001 10.02
0.281 3.438 .4821 2.8562 11.17



Astm A333 Chemical Composition

A333 Gr.6 Ni Mn C S P Si
– 0.29-1.06 0.3 0.025 0.025 ≥0.10



A333 low temp pipe with Inspection /Certification EN 10204 – 3.1B, check A333 Gr 6 Material price per kg in UAE



Why is the ASTM A333 also called a Low Temperature Pipe?

The A333 steel is an alloy steel plate that is designed to work in lower temperatures. The versatile steel grade of ASTM A333 pipe can handle temperatures below 40 degrees C, giving them an edge in the industry.



Inspection and Test Certificate of A333 Pipe Material

Inspection and Test Certificate of A333 Pipe Material

  • IBR Certificate
  • ISO 14001:2015 Certificate
  • NDE Reports
  • ISO 9001:2005 Certificate
  • EIL Reports
  • EN 10204 3.1 Certificate
  • Radiographic Testing (RT),
  • Ultrasonic Testing (UT) Reports
  • PED Certificate



SA333 Pipe Dimensions

Size NPS Gallon Capacity Per Linear Foot Wall Thickness Pipe O.D. Pipe I.D. Schedule
Pipe #		 Standard to XXHY Section Modulus
3/4 .0277 0.113 1.05 0.824 40 STD .0705
.0153 0.219 0.612 160 .1006
.0225 0.154 0.742 80 XHY .0853
.0077 0.308 0.434 XXHY .1103
1/2 .0158 0.109 0.84 0.622 40 STD .0407
.0088 0.188 0.464 160 .0528
.0122 0.147 0.546 80 XHY .0478
.0026 0.294 0.252 XXHY .0577
1 1/4 .0777 0.140 1.66 1.380 40 STD .2346
.0549 0.250 1.160 160 .3421
.0666 0.191 1.278 80 XHY .2913
.0328 0.382 0.896 .4110
2 .1898 0.109 2.375 2.157 10 .4205
.1534 0.218 1.939 80 XHY .7309
.1344 0.281 1.813 .8666
.1743 0.154 2.067 40 STD .5606
.1434 0.250 1.875 .8045
.1161 0.344 1.687 160 .9806
.0922 0.436 1.503 XXHY 1.1043
1 .0449 0.133 1.315 1.049 40 STD .1328
.0271 0.250 0.815 160 .1904
.0374 0.179 0.957 80 XHY .1606
.0146 0.358 0.599 XXHY .2136
2 1/2 .2833 0.120 2.875 2.635 10 .6870
1 1/2 .1058 0.145 1.90 1.610 40 STD .3262
.0730 0.281 1.338 160 .5079
.0918 0.200 1.500 80 XHY .4118
.0494 0.400 1.100 .5977



What are Standards of A333 Grade 6 Seamless Pipe

  • ASTM A370
  • ASTM A671
  • ASTM A999/ A999M
  • E23
  • E165
  • E709



A333 Material Equivalent

Former New
Standard Execution Standard Material Material
ASTM A333 Seamless EN 10216-4 GRADE 6 P265NL

Mechanical Properties of SA 333 Gr 6 Material

Grade Tensile strength, min, psi (MPa) Yield strength, min, psi (MPa) Elongation (%)
A333 Gr.6 60 000 (415) 35 000 (240) 30 min



What is the CVN Impact (Charpy) Test performed for A333 Grade 6 Seamless Pipe?

The Charpy test on the SA 333 Gr 6 material is performed as a hammer is hit on the material. The amount of pressure absorbed by the robust SA333 Gr 6 material will determine its toughness.



What is Impact Test Temperature and Value of A333 Steel Pipe ?

Impact Test Temperature

Grade Minimum Impact Test Temperature Minimum Impact Test Temperature
Grade 10 -60 ℃ -75 ℉
Grade 3 -100 ℃ -150 ℉
Grade 1 -45 ℃ -50 ℉
Grade 6 -45 ℃ -50 ℉
Grade 4 -100 ℃ -150 ℉
Grade 8 -195 ℃ -320 ℉
Grade 7 -75 ℃ -100 ℉
Grade 9 -75 ℃ -100 ℉
Grade 11 -195 ℃ -320℉



Impact Test Value

Minimum Average Impact Value for Three Specimens Speciman Size, mm Minimum Impact value for One Specimen
5 ft/lbf 7 J 10 by 3.33 3 ft/lbf 4 J
10 ft/lbf 14 J 10 by 7.5 8 ft/lbf 11 J
13 ft/lbf 18 J 10 by 10 10 ft/lbf 14 J
7 ft/lbf 9 J 10 by 5 5 ft/lbf 7 J
9 ft/lbf 12 J 10 by 6.75 7 ft/lbf 9 J
4 ft/lbf 5 J 10 by 2.5 3 ft/lbf 4 J
