Class 150 Weld Neck Flange Highlights
| Flange Manufacturing Type | Class 150 Weld Neck Flange |
|---|---|
| Designed For | High Pressure |
| Size | 1/2″ to 24″ |
| Applications and Uses | HVAC Systems |
| Manufacturing Specification | ASME B16.5 |
Check ANSI B16.5 150# WNRF Flanges Dimensions and 150LB Weld Neck Flange Thickness Chart
Class 150 Weld Neck Flange Dimensions
150LB WN Flange in Large Diameter, Check ASME B16.5 Class 150 WNRF Flanges Dimensions, Weight & Specification
Weight Chart of 150 LB Weld Neck Flange
| Nominal Pipe Size | Weld Neck Flange (LB) |
|---|---|
| 1/2 | 2 |
| 1 | 3 |
| 3/4 | 2 |
| 1¼ | 3 |
| 2 | 6 |
| 1½ | 4 |
| 2½ | 10 |
| 3½ | 12 |
| 3 | 11.5 |
| 4 | 16.5 |
| 6 | 26 |
| 5 | 21 |
| 8 | 42 |
| 12 | 88 |
| 10 | 54 |
| 14 | 114 |
| 18 | 165 |
| 16 | 140 |
| 20 | 197 |
| 24 | 268 |
| 22 | 225 |
Class 150 Weld Neck Flange Specification
Dimensions: Class 150 Weld Neck Flange
Size Range: NPS: 1/2″ to 24″
Pressure Rating: Class 150
Manufacturing Standard: ASME B16.5
Marking: B16.5 + Manufacturer Name + Size + Material
Flange Facings: Ring Joint (RTJ), Raised Face (RF), Flat Face (FF)
Get Quote Directly from Class 150 Weld Neck Flange Suppliers
100% Tested Class 150 WNRF Flange with MTC EN 10204/3.1
Check 150 LB Weld Neck Flange Dimensions and Thickness Chart, and Buy ANSI B16.5 Class 150 Welding Neck Flanges From Verified Suppliers in the Middle East and Africa
Bolt Chart of Class 150 WNRF Flange
| NPS (inches) | Class 150 | ||||
|---|---|---|---|---|---|
| Dia.of Flange (inches) |
Dia. of Bolts (inches) |
No. of Bolts |
Bolt Circle (inches) |
Dia. of Bolt Holes (inches) |
|
| 1/4 | 3-3/8 | 1/2 | 4 | 2-1/4 | 0.62 |
| 3/4 | 3-7/8 | 1/2 | 4 | 2-3/4 | 0.62 |
| 1/2 | 3-1/2 | 1/2 | 4 | 2-3/8 | 0.62 |
| 1 | 4-1/4 | 1/2 | 4 | 3-1/8 | 0.62 |
| 1-1/2 | 5 | 1/2 | 4 | 3-7/8 | 0.62 |
| 1-1/4 | 4-5/8 | 1/2 | 4 | 3-1/2 | 0.62 |
| 2 | 6 | 5/8 | 4 | 4-3/4 | 0.75 |
| 3 | 7-1/2 | 5/8 | 4 | 6 | 0.75 |
| 2-1/2 | 7 | 5/8 | 4 | 5-1/2 | 0.75 |
| 3-1/2 | 8-1/2 | 5/8 | 8 | 7 | 0.75 |
| 5 | 10 | 3/4 | 8 | 8-1/2 | 0.88 |
| 4 | 9 | 5/8 | 8 | 7-1/2 | 0.75 |
| 6 | 11 | 3/4 | 8 | 9-1/2 | 0.88 |
| 10 | 16 | 7/8 | 12 | 14-1/4 | 1 |
| 8 | 13-1/2 | 3/4 | 8 | 11-3/4 | 0.88 |
| 12 | 19 | 7/8 | 12 | 17 | 1 |
| 16 | 23-1/2 | 1 | 16 | 21-1/4 | 1.12 |
| 14 | 21 | 1 | 12 | 18-3/4 | 1.12 |
| 18 | 25 | 1-1/8 | 16 | 22-3/4 | 1.25 |
| 24 | 32 | 1-1/4 | 20 | 29-1/2 | 1.38 |
| 20 | 27-1/2 | 1-1/8 | 20 | 25 | 1.25 |
