What Is Ductile Iron Push On Fittings?
DI push on fittings are universal grade of fitting. The Ductile Iron Push On Fittings can be installed without requiring any special tools. The fittings are easy to use and can be installed by pushing it into the ring-end until it stops. The internal click claws automatically clamp around the hose of the Push-on Ductile Iron Fittings. The fitting are removable and later reusable. These fitting are very versatile and are available in a variety of sizes. The Di Push-on Fittings allows for frequent changes of lines at lower costs.
The fittings are available in the form of elbows, tees, couplings, adaptors, cross, etc. The Ductile Iron Push On Elbow is a common fitting that changes the direction of the flow in the system. The elbows are designed in 45, 90, and 180 degree specifications.
Verified manufacturers and stockists
Can Push On Ductile Iron Fittings Be Threaded?
The push on ductile iron fittings allows for transition from threads. The ductile iron pipe push in fittings can be threaded in NPT, NPTF, BSP, BSPT, and compression type threads.
Are Push-on Joint Socketed Fittings Good?
A push-on joint socketed fitting is good if you are looking for a speedy and fast connection. The Push-on Joint Socketed Fittings can be easily installed without any solder or weld and later dismantled. This makes it a good choice for emergency work. The Di Push-on Joint Socket Welding Fitting is available in a range of sizes that give it an edge in the industry.
Push On Ductile Iron Fittings Specification
- Specification : Ductile Iron Push On Fittings
- Available in sizes : 3 inch through 24 inch
- Connection : Socket
- Certified : ISO Certified
- Connection Type : Push On Type
- Technics : Casting
- Internall coatings : Fusion bonded epoxy and Cement mortar lining
- Color : Blue and Black
- Certification : ASME, JIS, BS, ANSI, DIN
- Thickness : SCH 40s
- Surface : Powder Coating and Acid Pickling
Purchase ductile iron push-on elbow from audited manufacturers in Dubai, before ordering, compare di push on fittings price
Push-on Joint Socketed Fittings Price List In USD
DN 600mm, Connection: Flange, Pushs On Joint Elbow
DN 80 mm, Pushs On Joint Elbow, PN 10, IS:9523
DN 1200 mm, Pushs On Joint Elbow, PN 16, Black Coating
DN 600mm, Connection: Flange, Pushs On Joint Elbow
DN 76 MM, Ductile Iron Pushs On Collar, Connection: Male
DN 40 MM, Pushs On Tee, Surface: Color Coated
Push On Ductile Iron Fittings
Push-on Joint Socketed Fittings
Di Push On Fitting
Ductile Iron Pipe Push On Fitting
Ductile Iron Push Joint Fittings
Di Push-on Joint Socket Welding Fitting
Ductile Iron Pushs on Connect Fittings
Ductile Iron Pushs Elbow
Ductile Iron Pushs Joint Collar Pipe Fitting
Pushs-on Ductile Iron Double Socket Bend
Di Pushs Joint Socket Tee
Ductile Iron Pushs Pipe Fittings
Check how to fix leaking ductile iron pipe push on fittings?, buy custom size ductile iron push-on connect fittings at 10% to 30% cheaper price ex middle east
How To Fix Leaking Ductile Iron Pipe Push On Fittings?
The ductile iron pipe push on fittings is reusable; however, fixing them if they are leaking is difficult. The fitting should not be used permanent harsh conditions.
View maximum deflection angle of di push on fittings, trustworthy importer of push on ductile iron fittings in sharjah
Allowable Deflection Of Ductile Iron Pipe Push On Fittings
| Size (inches) |
Lok-Ring Deflection Angle (Degree) |
|---|---|
| 54 | 0.5 |
| 60 | 0.5 |
| 64 | 0.5 |
Maximum Deflection Angle Of Di Push On Fittings
The maximum deflection angle of DI push on fittings is 15° per joint up to 24 inches and larger. However, the deflection of the ductile iron push joint fittings is 12° to 15°.
Push On Ductile Iron Double Socket Bend Dimensions
| DN (Inches) | Dimensions L | Wall Thickness (E) | Weight In LBS |
| 3.1 | 85 | 7.0 | 13.2 |
| 3.9 | 100 | 7.2 | 19.8 |
| 5.9 | 130 | 7.8 | 33.0 |
| 7.8 | 160 | 8.4 | 50.7 |
| 9.8 | 240 | 9.0 | 90.3 |
| 11.8 | 280 | 9.6 | 132.2 |
| 13.7 | 370 | 10.2 | 174.1 |
| 15.7 | 420 | 10.8 | 238.0 |
| 17.7 | 470 | 11.4 | 304.2 |
| 19.6 | 520 | 12.0 | 390.2 |
| 23.6 | 620 | 13.2 | 628.3 |
| 27.5 | 720 | 14.4 | 959.0 |
| 31.4 | 820 | 15.6 | 1410.9 |
| 35.4 | 920 | 16.8 | 1803.3 |
| 39.3 | 1020 | 18.0 | 2409.6 |
Di Push-on Joint Socket Tee Dimensions
| DN (Inches) | Dimensions | Weight In (LBS) | |
| L | H | ||
| 3.1 | 175 | 85 | 24.2 |
| 3.9 | 165 | 90 | 28.6 |
| 3.9 | 195 | 100 | 31.9 |
| 5.9 | 180 | 120 | 39.6 |
| 5.9 | 200 | 125 | 44.0 |
| 5.9 | 260 | 130 | 59.5 |
| 7.8 | 180 | 145 | 57.3 |
| 7.8 | 7.8 | 150 | 59.5 |
| 7.8 | 260 | 155 | 70.5 |
| 7.8 | 320 | 160 | 83.7 |
| 9.8 | 185 | 185 | 79.3 |
| 9.8 | 205 | 190 | 80.4 |
| 9.8 | 265 | 190 | 99.2 |
| 9.8 | 320 | 190 | 105.8 |
| 9.8 | 380 | 190 | 121.2 |
| 11.8 | 220 | 235 | 105.8 |
| 11.8 | 210 | 220 | 108.0 |
| 11.8 | 265 | 220 | 132.2 |
| 11.8 | 325 | 220 | 136.6 |
| 11.8 | 380 | 220 | 169.7 |
| 11.8 | 440 | 220 | 180.7 |
Find complete information about the advantages of ductile iron push-on pipe joints fittings
What Is The Biggest Advantage Of Ductile Iron Push On Connect Fittings?
The ductile iron push on connects fitting come with a quick release system that allows for easy installation. The Ductile Iron Push-On Connect Fittings acts as an excellent emergency tool. The fitting can be easily connected and later disconnected. Further, these fittings are available at low prices.
