Inconel 601 tube

Inconel 601 tube

It is a popular superalloy comprising nickel, chromium, iron, and aluminium. An Inconel 601 tube delivers excellent resistance against heat and corrosion. Plus, it exhibits high strength and workability. It gets hardened via cold working.
The addition of aluminium makes it a better fit for extreme temperatures up to 2200° Fahrenheit. An oxide scale gets formed on the surface, helping Inconel 601 display superior oxidation resistance. An alloy 601 tube also boasts metallurgical stability and carburization resistance. You will frequently see it employed in heat exchanger tube, radiant tube, and catalyst support grids. UNS 6601 superheater tube are also regular in chemical processing, power generation, and aerospace.

Verified Supplier

Verified stockists and wholesalers

available 7 cars

Inconel 601 seamless tube suppliers in UAE

Nickel alloy 601 exhaust tubing specifications


Inconel 601 Tube Specification

For special sizes, get in touch with one of the authorised Inconel 601 tube suppliers in the UAE listed above.

Nicr23fe tubing wall thickness OD Alloy 601 seamless tube schedule
  • 0.8mm to 6mm
  • 6mm to 101.6mm
  • SCH10
  • STD
  • SCH80
  • SCH5
  • SCH160
  • SCH40
DIN 2.4851 tubes ASTM Standard UNS N06601 welded tube tensile strength Nickel alloy 601 annealed tube yield Strength
  • ASTM B163 UNS N06601
  • ASME SB 163 UNS N06601
80.00-110.00 25.00-55.00
2.4851 Inconel 601 tubes manufacturing types Inconel 601 seamless tube manufacturing technique DIN 2.4851 square tubing finish
  • Seamless
  • Electric Resistance Welded (ERW)
  • Fabricated
  • LSAW
  • Redrawn
  • Welded
  • Hot drawn
  • Solid solution
  • Bright annealed
  • Hot extruding
  • Cold drawn
  • Mechanical Polish
  • Polished
  • Annealing
  • Cold Finish
  • Bright
  • Pickling
  • custom
  • Mill finish
  • Electro Polish
Nickel 601 square tubing melting point UNS 6601 redrawn tube density EN 2.4851 exhaust tubing temperature range
1320 – 1370 C 8.1 g/cm 540 to 760°C
nicr23fe heat exchanger tube length Werkstoff NR. 2.4851 condenser tubes services Supply WNR 2.4851 tube in following brand
  • Single
  • Cut Length
  • Standard
  • Double Random
  • cut-to-length services
  • machining
  • tube manipulation
  • welding
  • laser cutting
  • Beveling
  • plasma profiling
  • threading

Use chat or email to get in direct contact with mentioned Inconel 601 tube stockists, stockholder, and distributors for these services.

  • Kobe Special Tube, Japan
  • Esab
  • Lincoln
  • Metrode
  • Special Metals USA
  • Schoeller Bleckmann, Austria
  • Nippon Steel Corporation, Japan
  • Seah Steel Corporation, Korea
  • Sanyo Special Steel, Japan
  • BOHLER
  • Tubacex Tubos Inoxidables S.A., Spain
  • Sumitomo Metals, Japan
Nickel 601 boiler tube maximum operating temperature Inconel alloy 601 tubing common trade names Hardness range of nickel alloy 601 cold drawn tube
540°C
  • Pyromet 601
  • Ferrochronin 601
  • Inconel 601
  • Alloy 601
  • Nicrofer 601
  • Nickelvac 601
  • Nickel 601
70.00-95.00
Type of nickel 601tube for chemical Industry Nickel 601 tubes form Manufacturing methods of nickel alloy 601 tubing
  • Werkstoff NR. 2.4851 capillary tubing
  • Instrumentation tube
  • WNR 2.4851 gas tube
  • nickel 601 condenser tube
  • Heater tube
  • Inconel 601 seamless tube
  • Inconel alloy 601 welded tube
  • Mechanical tubing
  • U-bent tubing
  • Alloy 601 annealed tube
  • Extruded tube
  • nickel alloy 601 exhaust tubing
  • precision tubes
  • 2.4851 Inconel 601 condenser tubes
  • nickel 601 boiler tube
  • Superheater tubes
  • UNS 6601 cold drawn tube
  • Bright annealed tube
  • Internally finned tubing
  • EN 2.4851 coiled tubing
  • Cold redrawn reboiler tubes
  • nicr23fe high pressure tube
  • hydraulic tubing
  • DIN 2.4851 heat exchanger tube
  • Redrawn tube
  • UNS N06601 square tubing
  • polish tube
  • Evaporator tubes

Compare our price and response time to other Inconel 601 tube
stockists.

  • Straight
  • ‘U’ bent
  • Square
  • Hydraulic
  • Rectangular
  • Round
  • Coil
  • Cold drawn
  • Precision Rolled
  • Hot formed
  • Cold Formed
Certification of nickel 601 bright annealed tube Origin standards of alloy 601 superheater tubes Nickel alloy 601 coiled tubing features
  • DFARS compliant
  • Moisture testing report
  • Heat Treatment Charts
  • Surface roughness measurement
  • HS Code Commercial Invoice
  • Laboratory Test Certificate from Govt. Approved Lab
  • Form A for Generalized System of Preferences (GSP)
  • EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
  • Fumigation Certificates
  • Raw Materials Certificate
  • Third Party Inspection Report
  • American
  • Janpanese
  • European/ German
  • Korean
Resistance to high- temperature oxidation
Nickel 601 polish tube benefits Nickel alloy 601 precision tubes marking nicr23fe tubing applications
Resistance to high- temperature oxidation
  • Specification
  • Method of Manufacturing (Seamless / Welded)
  • Heat Number
  • Manufacturer’s Name or Custom Logo – on request
  • Material Grade
  • Nominal Size
  • Schedule or Wall Thickness
  • Radiant tubes
  • Power generation
  • Chemical processing
  • Catalyst support grids
  • Aerospace
  • Heat treatments

The top ten trustworthy suppliers of Inconel 601 tube have supplied nickel alloy 601 exhaust tubing to Tunisia, Mauritius, Eswatini, Senegal and Kenya

Get Inconel alloy 601 high pressure tube suppliers with below approval Nickel alloy 601 cold redrawn reboiler tubes SWG Nickel 601 hydraulic tubing welding method
  • SABIC
  • Qatar Petroleum
  • NPDC
  • PETRONAS
  • EGPC
  • Aramco
  • ALBA
  • KOC
  • ADNCO
  • ORPIC
  • QAFCO
  • MAADEN
  • KNPC
  • 10 Swg.
  • 16 Swg.
  • 18 Swg.
  • 20 Swg.
  • 12 Swg.
  • 14 Swg.
  • FCAW
  • submerged arc welding
  • TIG
  • SMAW
  • GMAW including both MIG and MAG
Werkstoff NR. 2.4851 gas tube documentation offered WNR 2.4851 heater tube equipment 2.4851 Inconel 601 condenser tube delivery time
  • Country of Origin Certificate (Original)
  • Bill of Lading.
  • Copy of Invoice
  • Manufacturer’s Mill Test Certificate certifying, Heat No, finish, Chemical Composition, Grade etc.,
  • Copy of Packing List indicating details of Sizes, quantity, weight, thickness etc.
  • Press machine
  • electric bevelling machine
  • Sand-blasting machine
  • Bending machine
  • Pushing Machine
  • 15-20 days if its not in stock
  • Generally it is 7-10 days if its in stock
  • 5-7 days in Saudi Arabia, Oman, and Qatar
Nickel Nickel alloy 601 exhaust tubing inspection methods DIN 2.4851 capillary tubing packaging Inconel 601 mechanical tubing end type
  • Chemical test
  • Mechanical test
  • pmi test
  • Visual inspection test
  • Third party inspection test
  • Nabl approved lab test
  • Flaring Test
  • Destructive test
  • Non destructive test

Clear and concise communication on the mentioned test with the distributors, dealers, and Inconel 601 tube stockists specified above

  • Wooden Boxes
  • Wrapped in plastic or standard seaworthy export packing
  • custom
  • Crates (steel/wooden)
  • Special crates for with each radius separated
  • PE Fabric Bundles
  • Bundles (hexagonal)
  • POE: Plain One End
  • TE: Thread End
  • TBE: Thread Both Ends
  • TLE: Thread Large End
  • TOE: Thread One End
  • TSE: Thread Small End
  • BBE: Bevel Both Ends
  • BLE: Bevel Large End
  • BOE: Bevel One End
  • BSE: Bevel Small End
  • BW: Buttweld End
  • PE: Plain End
  • Plain Ends (PE)
  • Threaded Ends (TE)
  • Bevelled Ends (BW)
  • Grooved Ends
  • BE: Bevel End
  • PBE: Plain Both Ends

Find verified alloy 601 tube & DIN 2.4851 square tubing suppliers to get more options and lower prices in Middle East countries

Alloy 601 welded tube gauge thickness

Gauge Thickness range(inch) Typical value (inch)
8 0.157 – 0.167 0.165
7 0.175 – 0.185 0.18
20 0.031 – 0.035 0.035
19 0.038 – 0.042 0.042
18 0.044 – 0.049 0.049
17 0.053 – 0.058 0.058
16 0.060 – 0.065 0.065
15 0.066 – 0.074 0.072
22 0.025 – 0.029 0.028
11 0.112 – 0.122 0.12
10 0.126 – 0.136 0.134
9 0.140 – 0.150 0.148
14 0.075 – 0.085 0.083
13 0.087 – 0.097 0.095
12 0.101 – 0.111 0.109

Nickel alloy 601 capillary tube size chart

Gauge Outside Diameter Tolerance mm Regular Wall (RW) mm Thin Wall (TW) mm Extra Thin Wall (XTW) mm Ultra Thin Wall (UTW) mm
30 0.304 – 0.317 0.064 – 0.089
29 o.330 – 0.342 0.064 – 0.089
28 0.355 – 0.368 0.076 – 0.102
13 2.387 – 2.438 0.267 – 0.343 0.191 – 0.267
12 2.743 – 2.749 0.267 – 0.321
11 3.023 – 3.073 0.293 – 0.368 0.216 – 0.292
10 3.378 – 3.429 0.318 – 0.394 0.216 – 0.292
27 0.406 – 0.419 0.089 – 0.115 0.064 – 0.089
26 0.457 – 0.469 0.089 – 0.114
25 0.508 – 0.520 0.115 – 0.140 0.089 – 0.114
20 0.901 – 0.914 0.108 – 0.165 0.108 – 0.134
19 1.054 – 1.079 0.166 – 0.216 0.102 – 0.140 0.070 – 0.108
18 1.257 – 1.282 0.191 – 0.241 0.127 – 0.165 0.083 – 0.121 0.051 – 0.102
17 1.460 – 1.485 0.177 – 0.229 0.115 – 0.152 0.083 – 0.127 0.057 – 0.102
16 1.638 – 1.663 0.204 – 0.254 0.127 – 0.165 0.096 – 0.133 0.070 – 0.121
15 1.816 – 1.841 0.204 – 0.254 0.127 – 0.165 0.096 – 0.134 0.070 – 0.121
14 2.082 – 2.133 0.216 – 0.292 0.165 – 0.229 0.114 – 0.165 0.076 – 0.134
24 0.558 – 0.571 0.114 – 0.140 0.089 – 0.114 0.051 – 0.102
23 0.635 – 0.647 0.140 – 0.165 0.089 – 0.114 0.051 – 0.102
22 0.711 – 0.723 0.140 – 0.165 0.096 – 0.121 0.077 – 0.102 0.051 – 0.102
21 0.812 – 0.825 0.140 – 0.165 0.102 – 0.127 0.051 – 0.102

Types of Inconel alloy 601 redrawn tube

Nickel alloy 601 exhaust tubing

Nickel alloy 601 exhaust tubing

Inconel 601 seamless tube

Inconel 601 seamless tube

DIN 2.4851 square tubing

DIN 2.4851 square tubing

Nicr23fe coiled tubing

Nicr23fe coiled tubing

Alloy 601 welded tube

Alloy 601 welded tube

Inconel alloy 601 heater tube

Inconel alloy 601 heater tube

2.4851 Inconel 601 boiler tube size chart

Types Out diameter Length Wall thickness
Inconel 601 Welded tube (available + as per need) 5.00 milimeter ~ 1219.02 milimeter Upto 6 Meters 1.00 ~ 15.00 milimeter
NB Sizes (available) 1/8” ~ 8” SCH 40 /SCH 10 /SCH 160/ SCH 5 / SCH 80
Inconel 601 Seamless tube  (as per need) 5.00 milimeter ~ 203.02 milimeter as per need

Welding products of nickel 601 heat exchanger tube

Service Conditions Shielded Metal Arc Welding Gas Tungsten Arc Welding Gas Metal Arc Welding Submerged Arc Welding
Above 2100°F (1150°C) Not recommended INCONEL Filler
Metal 601
Not Recommended Not Recommended
Exposure to H2S or SO2 at all temperatures Not recommended INCONEL Filler Metal 601 Not Recommended Not Recommended
Up to 1800°F (980°C) INCO-WELD A Welding Electrode or INCONEL Welding Electrode 117 INCONEL Filler Metal 82, 601, or 617 INCONEL Filler Metal 82 or 617 INCONEL Filler Metal 82 and INCOFLUX 4
1800°F (980°C) to 2100°F (1150°C) INCONEL Welding Electrode 117 INCONEL Filler Metal 601 or 617 INCONEL Filler Metal 617 Not Recommended

UNS 6601 superheater tubes tolerances

O.D. Inches Wall Thickness Inches O.D. +/- INCHES
3-1/2″ to 5″ incl. .083 to .165 0.02
Over .165 to .220 0.025
2-1/2″ to 3-1/2″ incl. .032 to .165 0.014
Over .165 to .220 0.02
1 to 1-1/2″ incl. .025 to .065 0.008
Over .065 to .134 0.01
1/2″ to 1″ incl. .025 to .065 0.005
Over .065 to .134 0.01
2″ to 2-1/2″ incl. .032 to .065 0.012
Over .065 to .109 0.013
Over .109 to .165 0.014
1-1/2″ to 2″ incl. .025 to .049 0.01
Over .049 to .083 0.011
Over .083 to .148 0.012

Impact strength of EN 2.4851 condenser tubes

Inconel alloy 601
Condition Diameter Charpy V-Notch Impact Strength Tensile Strength Yield Strength (0.2% Offset) Elongation, %
in. mm ft-lb J ksi MPa ksi MPa
Annealed 0.75 19 99 134 115 793 65.5 452 41
Annealed 0.625 16 103 140 112 772 66 455 41
Solution-Treated 0.75 19 136 184 102 703 35.9 248 49
Solution-Treated 0.625 16 130 176 102 703 34.6 239 50

Alloy 601 tube chemical composition

Ni% Al% C% Cr% Mn% Fe% Si% Cu%
58.0-63.0 1.0-1.7 Max 0.10 21.0-25.0 Max 1.5 Bal. Max 0.5 Max 1.0

Thermal properties of Inconel 601 tubing

Temperature Electrical Resistivity Thermal Conductivity a Coefficient of Expansion Specific Heat
°F ohm-circ mil/ft Btu-in./ft2-hr-°F 10-6 in./in./°F Btu/lb-°F
1400 751 165 9.19 0.155
1600 754 178 9.51 0.162
400 727 100 8.01 0.119
600 735 113 8.11 0.126
800 741 126 8.3 0.133
1000 747 139 8.5 0.14
1800 758 190 9.82 0.169
2000 763 203 10.18 0.176
70 710 78 0.107
200 716 87 7.6 0.112
1200 751 153 8.87 0.147
°C mW-m W/m-°C mm/m/°C J/kg-°C
900 1.259 26.1 17.24 686
1000 1.262 27.8 17.82 712
200 1.207 14.3 14.36 498
700 1.249 22.8 16.11 632
800 1.249 24.4 16.67 657
500 1.239 19.5 15.19 578
300 1.22 16 14.58 523
400 1.229 17.7 14.83 548
20 1.18 11.2 448
100 1.192 12.7 13.75 469
600 1.247 21 15.62 603

UNS N06601 Tubes mechanical properties

Ultimate Tensile Yield Strength (0.2% OS) Elong. in 2 in., or 50mm or 4D, min., %
Cold Worked/ Annealed tubes (Alloy 601)
Min 550 MPa 205 MPa
Min 80 KSi 30 KSi 30
Hot Worked/ Annealed tubes (Alloy 601)
Min 550 MPa 205 MPa
Min 80 KSi 30 KSi 30

DIN 2.4851 tubing equivalent

Standards Country Inconel 601 tube
UNS North America N06601
WNR Russia 2.4851
ASTM America ASTM B163
ASME Australia SB163
EN Europe NiCr23Fe
JIS Japan NCF 601
BS United Kingdom NA 49
GOST Russia XH60BT
AFNOR France NC23FeA

Inconel 601 Tube Properties

Physical properties of Inconel 601 tubing

Grade Density Melting Point
Inconel 601 8.1 g/cm3 1320°C-1411°C

Typical tensile properties of nickel 601 heat exchanger tube

Form Tensile Strength Yield Strength (0.2% Offset) Rb, Hardness Elongation, %
ksi MPa ksi MPa
Cold-Drawn / Annealed Tube 80-110 550-760 30-60 205-415 70-95 65-35

Delivery time and location for EN 2.4851 condenser tubes

Export to Variations in price Expected delivery
Indonesia 5 % extra 9 days
South Africa 5 % extra 25 to 30 days
Malaysia 5 % extra| 10 days
UAE 5 % extra| 5 Days
Saudi Arabia 5 % extra 7 days
Italy 5 % extra 30 days
Philippines 5 % extra 14 days
USA 5 % extra 40 to 60 days
Qatar 5 % extra 7 days
France 5 % extra 30 days
Uk 5 % extra| 30 days
Oman 5 % extra 5 days

Yes, welding Inconel alloys can be tricky because the welds are prone to cracking.
The weld pool gets ill-defined as Inconel leaves a dirty film on the surface. However, some alloys of Inconel are better suited to welding than others as they use tungsten gas. For instance, a 2.4851 Inconel 601 boiler tube can use the TIG method. It can be a dicey process to master, but it can achieve excellent corrosion resistance when implemented.
Another approach to avoid cracking in DIN 2.4851 square tube is automated technology like plasma arc welding or pulsed micro laser welding. While welding Alloy 601 can be challenging, you can produce a strong weld if you follow the process carefully.

Annealing refers to softening the material to achieve the required chemical properties. During annealing, an Inconel 601 seamless tube gets heated to a critical temperature and cooled slowly. Slow cooling is usually conducted in an oven to produce a refined microstructure. The result of annealing is a softer, more machinable material – hence, it is the opposite of hardening.
While annealing Inconel 601, you have to heat it to 2100°F and then cool it down to 1400°F. Experts also recommend conducting pickling for nickel alloy 601 exhaust tube. It encompasses treating with an acid solution to keep the surface bright, especially on areas that underwent heating. It is vital since Inconel 601 tubing has high percentages of aluminium and chromium.

Inconel 601 tubing and alloy 601 welded tube with MTC EN 10204-3.1 at an actual price in Dubai

Inconel 601 is a superalloy that displays excellent resistance to heat and corrosion. It gets employed in condenser tube for its chemical and mechanical properties. EN 2.4851 condenser tube are responsible for the heat transfer to effect the condensation of vapour into a liquid. The tubing material must withstand high temperatures and exhibit stability in severe conditions. Inconel 601 also exhibits metallurgical superiority and high workability.
You can find this superalloy in condenser tube for petrochemicals. UNS N06601 tube are also customary in exhaust pipelines. It is a sturdy material that does not undergo corrosion even when faced with extreme conditions in other heat-related applications, like flame shields and burner nozzles.

Get a leading importer and stockists from the GCC countries who provide Inconel alloy 601 redrawn tube with mill tc at the lowest price

Ultrasonic testing gets performed for Inconel 601 tubing as it can detect any concerns in quality. This test can identify typical defects produced during the laser powder bed fusion (LPBF). Here, the laser gets reduced at set locations in the product to assess the shape of the flaw. You can conduct phased array ultrasonic testing (PAUT) for thick components like an Inconel alloy 601 redrawn tube and employ guided waves for thinner ones. Optical microscopy and X-ray computed tomography are also standard tests.
Many customers seek this testing before procuring the required components for their application. An ultrasonic test can detect defects in an alloy 601 welded tube, including its inner surface. It is a good idea to ask for this test from the supplier to get reassured about product quality, safety, and fitment for your installation.

Purchase cut-to-size UNS N06601 tubes and nickel alloy 601 exhaust tubing from the oldest traders in accordance with standards

Asking for the required test reports is imperative before procuring UNS N06601 tube. Fake products can pose security and credibility threats besides costing you time and money.
The first vital check is a material test which certifies the product quality. It will showcase the supplier information, the standard, the dimensions, mechanical properties, and chemical composition. A nickel 601 heat exchanger tube should also have a quality stamp from the supplier.
Another significant test is PMI, which ascertains the chemical composition. The grades should match your requirement, accounting for tolerances based on measurements by handheld spectrometers.
Some customers prefer to receive test reports from professional testing institutions or third-party testing for nicr23fe coiled tube. You can also ask for product samples before shipping.
