Male Female Flange Product Overview

Size in Ready Stock:	1/2″ To 48″ \| DIN10 – DIN5000
Thread :	MPT/ BSPT (Female), BSPP (Male & female), NPT, FPT, BSP, MNPT (Male)
Approval :	Saudi Aramco, RINA, ADNOC, KPI, EIL, SABIC, KNPC, KOC, Q CHEM, MA’ADEN, BAPCO
Suited for:	Marine, High Temperature, Seawater
Standards:	ASME/ANSI B16.5/16.36/16.47A/16.47B, ISO70051, JISB2220, BS1560-3.1, API7S-43, API605, EN1092, MSS S44
Raw Material Origin:	USA, Canada, European, German, UK, Indian, Korean, Japanese, Russia
Pressure Class:	Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS
Types of Faces :	M/F (Male And Female),FF (Flat Face), T/G (Tongue And Groove ), RF (Raised Face), RTJ (Ring Type Joint)
Test Certificates :	EN 10204/3.1B Raw Materials Certificate Fumigation Certificates Third Party Inspection Report 100% Radiography Test Report
Brands :	Officine, Ringmill SpA, Viraj Forgings Ltd, Genoyer Group Companies, Forgerossi SAS, Hans Van Triel, Ulma Forja
Shipping Country :	Jordan : 21 Days Norway : 45 Days Bahrain : 7 to 10 Days
What’s New :	The management at Exploring Middle East FZE boasts 26 years of industry experience. They have leveraged this expertise in Gas, Oil & petrochemical plants materials to build a B2B platform.
MTC:	EN 10204/3.1B and 3.2
RFQ:	support@pipingmaterial.ae

Table of Content

Male Female Flange Specification
What Materials Are Male & Female Flanges Made From ?
Stainless Steel Male Female Flange Wall Thickness
How Carbon Steel Male Female Flange Are Installed ?
Male Female Flange Dimensions
ASME B16.5 Male and Female Pressure Rating
ASME B16.11 Male Female Flange Manufacturing Methods
Male and Female Flanges Equivalent Standards
Advantages Of Using ASTM A182 F304 Male Female Flange
Disadvantages Of Using SS Male Female Flange
Testing & Inspection of Male Female Flanges
Technical Details Of Male Female Flange
Documents Provided For MSS SP-44 Male Female Flange
Which Industries Get Benefit From Using Male & Female Flanges ?

Stainless Steel Male Female Flange Suppliers In The UAE

Male Female Flange Specification

Size In Ready Stock: 1/2″ to 48″ | 15 NB to 1200 NB | DN10 – DN5000

Maximum Size: NPS 26 to NPS 60 For Large Diameter

Coatings: Oil Black Paint, Zinc Plated, Yellow Transparent, Anti-rust Paint, Cold and Hot Dip Galvanized

Bolts Hole Number: 4 To 48

Flanges Types: Threaded, Blind, Slip On, Weld Neck, Long Weld Neck, Lap Joint

Surface Finish: Concentric Serrated, Stock Finish, Smooth Finish, Spiral Serrated Finish

Application: Heavy oil refineries, Nuclear power, Petrochemicals and acids, Offshore, Marine applications

Testing: Impact Testing, Tensile Test, Hardness Testing, PMI Test, Pressure Shell Test

Documentation: Certificate of Origin, Material Test Certificates (MTC), NABL Laboratory Reports

Packaging: Plastic Bag, Wooden Case, Carton Box, Custom

Value Added Services: Casting, Cutting, Polishing, Threading, Machining

Equipments: Pushing Machine, Electric Bevelling Machine, Sand-blasting Machine, Press Machine, Bending Machine

Get Quote Directly From MAle Female Flange Suppliers in UAE

100% Tested MSS SP-44 Male & Female Flanges With MTC EN 10204 3.1/3.2

Looking To Switch Suppliers? Obtain Quotes For Carbon Steel Male Female Flange And Compare Them It Your Current Supplier’s Revised Cost. Check All Materials

What Materials Are Male & Female Flanges Made From ?

Get ADNOC Approved Male Female Flange Suppliers in UAE With Various Materials

Material	Grades
Stainless Steel Male Female Flange	A182 F304/ 304L/ F316/ 316L/ F310/ F310S/ F316Ti/ F317L/ F321/ 321H/ F347/ F347H/ F904L
Nickel Alloy Large Male Female Flange	ASME SB564, Nickel Alloy 200, or 201
Monel Black Male And Female Pipe Flanges	404, R-405, 502, Alloy 400/401, K-500
Copper Nickel Small Male And Female Flange	CU-Ni 90/10, Copper nickel 70/30, C7060T, C70620, CW352H, EEMUA 234/3-6, WL 2.1972
Duplex & Super Duplex Male And Female Flanges	ASTM A240 F44 (UNS S31254), F60 (UNS S32205), F53 (UNS S32750), F51 (UNS S31803), F55 (UNS S32760), F61 (UNS S32550)
Copper Male Female Forged Flanges	ASTM SB61 UNS No. 10800, 12000, 12200, 10300, 10200, C10100
Carbon Steel Male Female Flange	ASTM A105, A694 Carbon Steel F42/ F46/ F52/ F56/ F60/ F65/ F70
Low Temp Carbon Steel Male And Female Flange	A350 Grade LF2, LF3 & LF6
Incoloy Male Flange	Alloy 800, 800H, 800HT, 803, 825, 832, 908, A-286, 27-7MO, 864, 890, 903, 907, 028, 020, 945, 925, 926, 330, 25-6HN, DS, 909, 945X, MA956
Alloy Steel Female Flanges	ASME SA182 Grade F1, F5, F9, (most selling F11, F12, F22, F91)
Inconel Male & Female Flange	600, 601, 601GC, 602CA, 603XL, 617, 625, 625LCF, 686, 690, 693, 706, 718, 718SPF, 725, 740H, X-750, 751, MA754, MA758, 783
Hastelloy Male And Female Face Flange	B-2, B, B-3, C-276, C-2000, C, C-4, C-22, C-22HS, G-35, G-30, G-3, N, S, W, X

Stainless Steel Male Female Flange Wall Thickness

NPS (Normal Pipe Sizes)	Outside Daimeter (O.D.)	Schedule 10	Schedule 20	Schedule 30	STD Wall	Schedule 40	Schedule 60	EXT Hvy	Schedule 80	Schedule 120	Schedule 140	Schedule 160	XX Hvy
1 ¼	1.66	0.109	–	–	0.14	0.14	–	0.191	0.191	–	–	0.25	0.382
½	0.84	0.083	–	–	0.109	0.109	–	0.147	0.147	–	–	0.188	0.294
¾	1.05	0.083	–	–	0.113	0.113	–	0.154	0.154	–	–	0.219	0.308
1	1.315	0.109	–	–	0.133	0.133	–	0.179	0.179	–	–	0.25	0.358
2 ½	2.875	0.12	–	–	0.203	0.203	–	0.276	0.276	–	–	0.375	0.552
1 ½	1.9	0.109	–	–	0.145	0.145	–	0.2	0.2	–	–	0.281	0.4
2	2.375	0.109	–	–	0.154	0.154	–	0.218	0.218	–	–	0.344	0.436
3	3.5	0.12	–	–	0.216	0.216	–	0.3	0.3	–	–	0.438	0.6
3 ½	4	0.12	–	–	0.226	0.226	–	0.318	0.318	–	–	–	0.636
4	4.5	0.12	–	–	0.237	0.237	–	0.337	0.337	0.438	–	0.531	0.674
14	14	0.25	0.312	0.375	0.375	0.438	0.594	0.5	0.75	1.094	1.25	1.406	–
16	16	0.25	0.312	0.375	0.375	0.5	0.656	0.5	0.844	1.219	1.438	1.594	–
18	18	0.25	0.312	0.438	0.375	0.562	0.75	0.5	0.938	1.375	1.562	1.781	–
5	5.563	0.134	–	–	0.258	0.258	–	0.375	0.375	0.5	–	0.625	0.75
6	6.625	0.134	–	–	0.28	0.28	–	0.432	0.432	0.562	–	0.719	0.864
8	8.625	0.148	0.25	0.277	0.322	0.322	0.406	0.5	0.5	0.719	0.812	0.906	0.875
10	10.75	0.165	0.25	0.307	0.365	0.365	0.5	0.5	0.594	0.844	1	1.125	1
12	12.75	0.18	0.25	0.33	0.375	0.406	0.562	0.5	0.688	1	1.125	1.312	1
20	20	0.25	0.375	0.5	0.375	0.594	0.812	0.5	1.031	1.5	1.75	1.969	–
22	22	0.25	–	–	0.375	–	–	0.5	–	–	–	–	–
26	26	–	–	–	0.375	–	–	0.5	–	–	–	–	–
30	30	0.312	0.5	0.625	0.375	–	–	0.5	–	–	–	–	–
24	24	0.25	0.375	0.562	0.375	0.688	0.969	0.5	1.219	1.812	2.062	2.344	–
36	36	0.312	0.5	0.625	0.375	0.75	–	0.5	–	–	–	–	–
40	40	–	–	–	0.375	–	–	0.5	–	–	–	–	–
42	42	–	–	–	0.375	–	–	0.5	–	–	–	–	–

How Carbon Steel Male Female Flange Are Installed ?

Clean flange faces
Align both flanges
Insert male portion of flange
In to female portion
Tighten bolts evenly
Place sealing gasket
Insert flange bolts
Check seal tightness
