Nickel 201 round bar

Nickel 201 Round Bar

Iron-nickel alloys used in manufacturing are sometimes referred to as nickel or stainless steel. These are typically strengthened with trace amounts of other metals, like Nickel 201 Round Bar, depending on the alloy’s intended use. Transformers, inductors, magnetic amplifiers, magnetic shields, and memory storage devices all use 72–83 percent nickel alloys. The reason is that they have the best soft magnetic properties. In addition to being used for various processing tools, Nickel 201 Hex Bars are crucial for maintaining product purity. This alloy, in particular, can resist hydroxides and modifies nickel alloys.

Verified Supplier

available 3 cars

Ni alloy 201 rod suppliers in UAE

Nickel 201 round bar specifications


Nickel 201 round bar specification

Above nickel 201 round bar suppliers offer custom sizes and finishes, get best price in Saudi Arabia, Azerbaijan, Syria, Oman & Mexico
Nickel 201 round bar size Alloy 201 flat bar size Nickel alloy 201 hex bar size
3-800mm
  • Thickness: 2 -100mm
  • Width: 10 to 500mm
2-100mm A/F
Werkstoff NR. 2.4068 shaft ASTM standard UNS N02201 square bar size DIN 2.4068 angle bar size
  • ASTM B160 UNS N02201
  • ASME SB 160 UNS N02201
4 to 100mm 3*20*20~12*100*100
Nickel 201 rectangular bar supply state ASME SB160 square bar AMS Nickel 201 bright bar finish
  • Annealed
  • Hardened strain
  • Solenoid quality
  • Smooth turned & polished
  • Turned & rough polished
  • The strain hardened
  • Peeled and polished
  • Trailed center less ground & polished
AMS 5553
  • Bright
  • Polishing
  • Mirror
  • Hairline
  • Pickled
  • Peeled
  • Black
Nickel alloy 201 rod rounds melting point Pure nickel 201 shaft density Ni 201 billet temperature range
1446 °C (2635 °F) 8.9 g/cm3 649°C (1200°F) and 1232°C (2250°F)
ASME SB 160 rod surface ASTM B160 bar stock value added services Supply WNR 2.4068 polished bar in following brand
  • Bright
  • Hot rolled pickled
  • Cold drawn
  • Sand blasting
  • Finished
  • Polished
  • Hairline
  • Testing and secondary heat-treating services
  • 24 hr call out service
  • NORSOK certified stock on select alloys
  • Special packaging
  • ASTM; ASME; ANSI; EN; DFAR compliant
  • Trepanning, grinding, PSQ, and turned, ground & polished bar
  • Same day cutting capability
  • Turnkey inventory stocking programs
  • ISO Certified
  • Custom cutting round bar to 16″

To speak with the nickel 201 round bar stockists, stockholders, and distributors of these services directly,
use chat or email.

  • Special Metals USA
  • BOHLER
  • Tubacex Tubos Inoxidables S.A., Spain
  • Sumitomo Metals, Japan
  • Schoeller Bleckmann, Austria
  • Nippon Steel Corporation, Japan
  • Seah Steel Corporation, Korea
  • Sanyo Special Steel, Japan
  • Kobe Special Tube, Japan
DIN 2.4068 cold drawn bar maximum operating temperature Nickel grade 201 bright drawn round bar common trade names Nickel 201 round bar standards
 600° F to 1400° F Nickel 201, LC Nickel 99.2
  • N02201
  • ASME SB-160
  • BS 3072
  • BS 3073
  • BS 3074
  • BS 3075
  • BS 3076
  • NA11 DIN 17740
  • DIN 17750
  • DIN 17751
  • DIN 17752
  • DIN 17753
  • DIN 17754
  • Werkstoff Nr. 2.4060, 2.4066
Most common types of ASME SB160 NW 2201 round bar Ni-201 hot rolled bars condition Manufacturing technique of ASTM B160 alloy 201 bar
  • Nickel 201 round bar
  • Nickel 2.4068 rod
  • Alloy 201 nickel flat bar
  • Nickel grade 201 hex bar
  • Pure nickel 201 square bar
  • Pure 201 nickel rectangular bar
  • Nickel 2.4068 bright bar
  • Ni 201 rounds
  • ASTM B160 UNS N02201 shaft
  • Werkstoff NR. 2.4068 billet
  • Nickel alloy 201 bloom
  • ASME SB160 NW 2201 bar stock
  • Ni 201 polished bar
  • DIN 2.4068 cold drawn bar
  • Nickel UNS N02201 bright drawn round bar
  • Alloy 201 cold finished round bar
  • ASTM B160 alloy 201 hot rolled bars
  • Ni-201 annealed bar
  • Nickel 201 UNS N02201 forged round bar

Compare our response time and price to those of other nickel 201 round bar stockists.

  • Hardened & tempered
  • Annealed
  • Precipitation hardened
  • Forged
  • Grinding
  • Centerless grinding
  • Cold drawn
  • Hot rolled
Certification of ASME SB 160 annealed bar Origin standards of ASTM B160 forged bar WNR 2.4068 hexagonal bar features
  • DFARS compliant
  • EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 material test certificates (MTC)
  • Fumigation certificates
  • Raw materials certificate
  • Third party inspection report
  • Moisture testing report
  • Heat treatment charts
  • Surface roughness measurement
  • HS code commercial invoice
  • Laboratory test certificate from govt. approved lab
  • Form A for generalized system of preferences (GSP)
  • American Standard
  • Russia Standard
  • Janpanese Standard
  • European Standard
  • Highly resistant to various reducing chemicals
  • The toughness of nickel
Pure 201 nickel forged cold drawn bar benefits Werkstoff NR. 2.4068 precision bar stock marking ASME SB160 NW 2201 peeled round bars applications
  • Cold rolled under proper conditions
  • Outstanding resistance to caustic alkalis
  • Good electrical and magnetostrictive properties
  • Specification
  • Material grade
  • Nominal size
  • Schedule or wall thickness
  • Method of manufacturing
  • Heat number
  • Manufacturer’s name or custom logo – on request
  • Chemical processing
  • Aerospace

The nickel 201 round bar suppliers listed above have ex-stock and have supplied to several countries in the
past, including the Cyprus, Lebanon, Syria, Nigeria, South Africa and Ethiopia.

Ni-201 forged round bar documentation offered ASTM B160 alloy 201 rod shape Alloy 201 nickel flat bar tolerances
  • Manufacturer’s mill test certificate certifying, heat no, finish, chemical composition, grade etc.,
  • Country of origin certificate (Original)
  • Bill of lading
  • NACE 0175/ ISO 15156 rorrosion resistance test
  • Copy of invoice
  • Copy of packing List indicating details of sizes, quantity, weight, thickness etc.
  • Square
  • Rectangular
  • Hollow
  • Hexagonal
  • Round
  • H12
  • H13
  • K9
  • K10
  • K11
  • H8
  • H9
  • H10
  • H11
  • K12 or custom
Hardness range of WNR 2.4068 cold finished round bar Pure nickel 201 square bar length Alloy 201 nickel rectangular bar lifespan
55 (HRB)
  • 100 mm to 3000 mm
  • Over 50 years
Nickel 201 round bar testing requirements Alloy 201 bright bar packaging Ni 201 bloom delivery time
  • Third party inspection test
  • Nabl approved lab test
  • Flaring Test
  • Non destructive test
  • pmi test
  • Visual inspection test
  • Chemical test
  • Mechanical test
  • Destructive test

Effective and brief communication of the test with the above-specified distributors, dealers, and nickel 201
round bar stockists

  • Special crates for with each radius separated
  • Bundles (hexagonal)
  • Wooden boxes
  • PE fabric bundles
  • Crates (steel/wooden)
  • Custom
  • Wrapped in plastic or standard seaworthy export packing
  • Generally it is 7-10 days if its in stock
  • 15-20 days if its not in stock

Find reputable nickel 201 hex bar suppliers in UAE who can supply UNS N02201 flat bar as per your needs

Alloy 201 flat bar hs code

Product Description HS Code
Nickel 201 round bar 7506

Nickel alloy 201 rod weight calculation formula

Weight calculation formula
Alloy 201 hex bar: Size (mm) X Size (mm) X 0.00680 = Wt. per Mtr.
Ni 201 flat bar: Width (mm) X Thickness (mm) X 0.00798 = Weight per Mtr.
WNR 2.4068 round bar: Diameter (mm) X Diameter (mm) X 0.00623 = Wt. per Mtr.
ASTM B160 square bar: Size (mm) X Size (mm) X 0.00788 = Wt. per Mtr.

Technical information of nickel 201 round bar

Ni201 UNS N02201 ASTM B160 ASME SB160

Ni 201 square bar tolerances

Nickel 201 round bar Tolerance Rank
Group 1 Group 2 Group 3
>50 ~ ≤80 ±0.060 ±0.070 ±0.080
>7 ~ ≤20 ±0.025 ±0.035 ±0.040
>30 ~ ≤50 ±0.040 ±0.050 ±0.060
>80 ~ ≤110 ±0.090 ±1.000 ±1.010
>20 ~ ≤30 ±0.030 ±0.040 ±0.050
>110 ~ ≤150 ±1.020 ±1.030 ±1.040

DIN 2.4068 rectangular bar material equivalent

Standards Country Value
UNS North America N02201
WNR Russia 2.4068
ASTM America B160
ASME Australia SB160
JIS Japan NW 2201
BS United Kingdom NA 12
GOST Russia НП-2
AFNOR France
EN Europe LC-Ni 99
AMS United States 5553
ANSI America
SAE United States
AS Australia
DIN German 2.4068

Pure nickel 201 bright bar size chart

Type Size (mm) ISO Tolerance Size (Inches)
Peeled and Polished 40.00 to 150.00 h11-DIN 1013 1.50″ to 6.00″
Cold drawn and Polish 3.00 to 75.00 h9-h8-h11-h10 1/8″ to 3.00″
Cold drawn and Ground 10.00 to 75.00 h9-h8-h11-h10 5/6″ to 2.50″
Peeled and Ground 20.00 to 50.00 h10-h9-h11 3/4″ to 2.00″

SB 160 UNS N02201 rounds weight chart

Size Kgs / Foot Kgs / Mtr Size Kgs / Foot Kgs / Mtr
20mm 0.753 2.470 3mm 0.017 0.055
22mm 0.908 2.979 1/8″ 0.019 0.062
7/8″ 0.926 3.038 5/32″ 0.029 0.095
24mm 1.080 3.543 4mm 0.030 0.098
25mm 1.180 3.871 3/16″ 0.043 0.141
1″ 1.210 3.970 5mm 0.047 0.154
26mm 1.271 4.170 7/32″ 0.058 0.190
27mm 1.368 4.490 6mm 0.068 0.223
1-1/8″ 1.534 5.033 1/4″ 0.076 0.249
30mm 1.691 5.548 7mm 0.091 0.298
1-1/4″ 1.924 6.349 5/16″ 0.118 0.387
32mm 1.894 6.314 8mm 0.120 0.398
1-3/8″ 2.303 7.550 9mm 0.152 0.498
35mm 2.390 7.553 3/8″ 0.170 0.557
36mm 2.438 7.999 10mm 0.189 0.620
38mm 2.792 8.903 11mm 0.228 0.748
1-1/2″ 2.715 8.951 7/16″ 0.232 0.761
40mm 3.009 9.872 12mm 0.271 0.889
1-5/8″ 3.200 10.449 1/2″ 0.303 0.994
1-3/4″ 3.712 12.179 13mm 0.318 1.043
45mm 3.807 12.555 14mm 0.368 1.207
1-7/8″ 4.260 13.977 9/16″ 0.383 1.256
48mm 4.330 14.205 15mm 0.424 1.391
50mm 4.698 15.414 5/8″ 0.473 1.551
2″ 4.848 15.906 16mm 0.481 1.578
2-1/8″ 5.475 17.963 17mm 0.543 1.791
2-1/4″ 6.135 20.128 11/16″ 0.573 1.880
60mm 6.768 22.205 18mm 0.610 2.001
2-3/8″ 6.838 22.435 3/4″ 0.682 2.237
2-1/2″ 7.576 24.856
2-5/8″ 8.354 27.409
2-3/4″ 9.169 30.083

Mechanical properties of ASTM B160 UNS N02201 bar

Density Tensile Strength Elongation Melting Point Yield Strength (0.2%Offset)
8.9 g/cm3 Psi – 67000 , MPa – 462 45 % 1446 °C (2635 °F) Psi – 21500 , MPa – 148

Chemical composition of nickel 201 round bar

Grade C,Carbon Si,Silicon Ni,Nickel Cu, Copper Mn,Manganese Mg,Magnesium S,Sulfur Fe,Iron Ti,Titanium
Nickel 201 0.02 max 0.2 max 99.0 min 0.25 max 0.35 max 0.15 max 0.01 max 0.4 max 0.1 max

Nickel 201 round bar properties

Physical properties of nickel alloy 201 rod

Properties Metric
Melting point 1435-1446°C
Curie temperature 360°C(68 °F)
Density 8.89 g/cm3
Saturation flux density 0,61 T

Delivery time and location for alloy 201 flat bar

Export to Approx shipping days
UAE 5 days
South Africa 25-30
Saudi Arabia 7
Qatar 7
USA 40-60
Mexico 25-30
France 30
Italy 30
Malaysia 10
Philippines 14

Alloy 201 bar in peeled / turned condition, view 201 alloy square bar price in Dubai

The weak metals also anneal out work-hardening at or below room temperature and have low crushing strengths. As a result, they produce larger junction areas that can withstand significant stress deformation without fracture. In other words, these materials can be easily magnetized and demagnetized. With a maximum carbon content of 0.02 percent, UNS N02201 Flat Bar is wrought commercially pure nickel. This alloy offers highly ductile mechanical properties for a wide range of temperatures. In neutral to slightly reducing environments, it offers corrosion resistance. It is also ferromagnetic, which makes it malleable and soft.

Alloy 201 Bars are made with 99.1 percent pure nickel. It also has high tensile strength, formability, and weldability. The same is applied to various processing devices to preserve product purity when working with synthetic fibers. In alkaline solutions, pure nickel exhibits excellent corrosion resistance. In particular, it exhibits exceptional resistance to non-oxidizing acids and highly pure halogen gas. There are wide popular varieties of bars made from pure nickel alloy, but one of them is the 201 Alloy Square Bar. Performing a precise dimethylglyoxime (dmg) spot test or using the Mond process approach is the first step in nickel testing.

  • Creating electricity
  • Baskets used for heat treatment
  • Oil and gas
  • Barreling
  • Aerospace
  • Pipes for waste treatment
  • Aircraft
  • Controlling pollution

Non-ferrous metals with high strength and toughness, outstanding corrosion resistance, and superior elevated temperature properties include nickel and nickel alloys. The iron group’s bright silver-white metallic element, pure nickel, is hard, malleable, and ductile. Ni Alloy 201 Rod has good mechanical properties and resistance to numerous corrosive environments. Other advantageous characteristics include its high thermal and electrical conductivities, low gas content, and magnetic and magneto strictive properties. 201 Nickel Alloy Bars are made using more than two-thirds of the world’s nickel production. As an alloying element, nickel improves important characteristics like formability, weldability, and magneticity.

Take a look at the widest selections of 201 nickel alloy bars and DIN 2.4068 round bar in the UAE

At room temperature, the ASTM B160 UNS N02201 Shaft is magnetic, rigid, but malleable. Being highly corrosion-resistant is nickel’s main advantage for industrial use. The ASTM B160 specification also covers the same and applies to round bars with the UNS numbers N02201 and N02200. These bars are available in annealed, cold-worked, and hot-worked forms. They have excellent heat resistance, high strength, and good corrosion resistance. Additionally, they are employed in a wide range of processes and jobs, such as:

201 nickel hexagon bar and ASTM B160 UNS N02201 shaft in annealed condition with mill test reports in the Middle East Countries

A DIN standard is a set of uniform specifications developed by the German Institute for Standardization (DIN) in Berlin. It regards products and processes, including quality, minimum performance, characteristics, dimensions, etc. The square section and good hardness of the DIN 2.4068 Round Bar make it a popular product. In factories and during the general assembly, these rods are commonly seen. These bars are used in structural applications that need to be specified by precise dimensions and tolerances. 201 Nickel Hexagon Bars provide stability and support for various applications. The price of the same item varies depending on the size and composition of the alloy. They range from $11.35 to $16.37 for this one.
