SUS 439L stainless steel sheet

Home > SUS 439L stainless steel sheet

SUS 439L Stainless Steel Sheet Key Points

Standard	ASTM A240 ASME SA 240
Classified According to Group	Group 1 Group 2 Group 3 Group 4 Group 5
Contain	17 – 19% Chromium
Life Span	25 Years
Origin	American, Japanese, European, Russian, Korean
HSN Code	7219
Common Defects	Warping, Ridging, Orange Peel
Tolerance	Thickness Tolerance: ±0.08 to 0.10 mm Width Tolerance: ±3 to 5 mm
Sample	Yes

Table of Content

SUS 439L Stainless Steel Sheet Specification
AISI 439L Chequered Plate Physical Properties
Available Types of AISI 439L Plate
Testing Methods of Alloy 439L Rolling Plate
UNS S43035 Slitting Coil Chemical Composition
ASTM A240 TP439L Perforated Sheet Mechanical Properties
Size Chart of SUS 439L Coil
UNS S43035 Slitting Coil Technical Information
Flatness Tolerance of ASTM A240 Type 439L Sheet

Buy From A Trusted UNS S43035 Slitting Coil Suppliers

SUS 439L Stainless Steel Sheet Specification

Get SUS 439L Stainless Steel Sheet Suppliers in UAE offering detailed specifications

439L Stainless Steel Sheet Specification

ASTM A240 SS 439L Sheet Thickness: 0.4 to 6.0 mm or Custom

Alloy 439L Perforated Sheet Width : 914 mm to 1524 mm

INOX 439L Foil Length: 300 to 6000 mm or Custom

SA 240 TP 439L Sheets Flatness Tolerances: ±0.5 to 6.0 mm

Alloy 439L Rolling Plate Cutting: Laser Cutting, Shearing, Plasma

UNS S43035 Slitting Coil Annealing Temperature: 850 – 950℃

ASTM A240 Gr 439L Plate Welding: SMAW, MMA, GTAW, TIG, GMAW, MIG

Applications: Chemical Industry, Food and Beverage, Petroleum Industry

SS 439L Sheets Surface Roughness: 0.30 to 0.50 µm (2B)

Surface Finish: 2B, Mirror Finish, BA, No.4

Buy Directly From SUS 439L Stainless Steel Sheet Suppliers in UAE and Get
Datasheet

Form: Slit Coils, Plate, Coils, Sheet

INOX 439L Foil Are Can Be Supply in Full Hard Tempered Condition, Contact Directly to Verified Stockist of ASTM A240 TP439L Perforated Sheet

AISI 439L Chequered Plate Physical Properties

Young’s modulus (x10³MPa)	Thermal conductivity 100°(W/m・℃)	Density (g/cm³)	Thermal expansion coefficient 0 – 650°C (x10-6/℃)
203	24.5	7.73	11.3

Locate Available Material from Stock

Region	City	Country
Middle East	Dubai	United Arab Emirates
Africa	Johannesburg	South Africa
Middle East	Abu Dhabi	United Arab Emirates
Africa	Abuja	Nigeria
Middle East	Dammam	Saudi Arabia
MENA	Cairo	Egypt
Middle East	Riyadh	Saudi Arabia
Middle East	Jeddah	Saudi Arabia
Africa	Lagos	Nigeria
Middle East	Doha	Qatar
Middle East	Kuwait City	Kuwait
MENA	Casablanca	Morocco
Africa	Cape Town	South Africa

Available Types of AISI 439L Plate

Check SUS 439L Stainless Steel Sheet Suppliers in UAE providing variety of types

439L Stainless Steel Sheet

Steel 1.4510 Plate

Stainless Steel 439L Slitting Coil

Alloy 439L Perforated Sheet

439L Ferritic Stainless Steel Foils

AISI 439L Coils

SUS 439L Thin Strips

SA 240 Grade 439L Plain Sheet

INOX 439L Rolling Plate

ASTM XM-8 Strip

EN 1.4510 Shim Sheet

ASTM A240 Type 439L Chequered Plate

Various NDT Testing Are Performed on AISI 439L Chequered Plate Before Supplying, Buy from Verfied SA 240 Type 439L Thin Strips Distributors

Testing Methods of Alloy 439L Rolling Plate

Find SUS 439L Stainless Steel Sheet Suppliers in UAE offering verified testing methods

PMI Testing
Visual Inspection
UT Testing
Hardness Testing

UNS S43035 Slitting Coil Chemical Composition

C	Si	Mn	Cr	Cu	Mo	Ti	N
≦ 0.030	≦ 0.75	≦ 1.00	17.00 – 19.00	–	–	6x(C+N)-0.75	≦ 0.020
0.008	0.10	0.17	17.43	–	–	0.30	0.008

Call Now for a Free Sample, Which Can Be Arranged From the Cities Specified Below

Fujairah	Umm Al Quwain	Sharjah	Doha
Al Jubail	Abu Dhabi	Saudi Arabia	Ajman
Riyadh	Dubai	Muscat	Ras Al Khaimah

ASTM A240 TP439L Perforated Sheet Mechanical Properties

0.2% Yield strength (MPa)	Elongation (%)	Tensile strength (MPa)	n value	Hardness Hv	Average R Value
≧ 175	≧ 22	≧ 360	0.24	≦ 200	1.4
245	31	429	0.24	145	1.4

Upto 25mm Alloy 439L Rolling Plate Can Be Cut With Laser Cutting, Refer Size Chart of SUS 439L Coil

Size Chart of SUS 439L Coil

Coil Thck.	Width
	W＜320			320≤W＜600
	T4	T3	T2	T1
0.07≤T＜0.08	0.003	0.005	0.005	0.006
0.25≤T＜0.30	0.005	0.009	0.011	0.015
0.15≤T＜0.20	0.004	0.008	0.009	0.011
T＜0.05 mm	0.002	0.003	0.003	0.004
0.35≤T＜0.40	0.005	0.010	0.012	0.018
0.50≤T＜0.60	0.005	0.013	0.018	0.022
0.10≤T＜0.13	0.004	0.006	0.007	0.009
0.05≤T＜0.07	0.003	0.004	0.004	0.005
0.80≤T＜0.90	0.006	0.018	0.024	0.028
0.40≤T＜0.50	0.005	0.012	0.015	0.020
0.13≤T＜0.15	0.004	0.007	0.008	0.010
0.70≤T＜0.80	0.005	0.017	0.022	0.026
0.90≤T＜1.00	0.008	0.020	0.027	0.032
0.08≤T＜0.10	0.003	0.005	0.005	0.007
1.00≤T＜1.20	0.008	0.022	0.030	0.035
1.20≤T＜1.40	0.010	0.025	0.035	0.040
0.20≤T＜0.25	0.005	0.008	0.010	0.013
0.30≤T＜0.35	0.005	0.010	0.012	0.016
0.60≤T＜0.70	0.005	0.015	0.020	0.024
1.40≤T＜1.60	0.020	0.030	0.040	0.045

Material Inspection Facility in Following Locations

Africa	Nigeria, South Africa, Kenya, Morocco, Egypt, Tunisia, Algeria
Middle East Countries	UAE, Saudi, Qatar, Kuwait, Bahrain, Oman, Iraq, Iran, Jordan, Lebanon, Syria, Yemen
MENA	Egypt, Morocco, Algeria, Tunisia, Libya, Israel, Palestine

Stainless Steel 439L Strips Can Be Used in Intermittent Service Up To 920°C and to 870°C, ASTM A240 Type 439L Shims Has Good Weldability and Pitting Corrosion Resistance

UNS S43035 Slitting Coil Technical Information

Now You Can Purchase SUS 439L Stainless Steel Sheet From the Verified Suppliers in UAE
Manufacturing size range of AISI 439L plate and sheet	SA 240 Grade 439L sheet thickness	SS 439L plate thickness
Width: 914mm to 1524mm Length: 300mm to 6000mm	Thickness: 0.4mm to 6.0mm	Thickness: 3.0mm to 100mm
439L SS sheets surface treatment	AISI 439L stainless steel plates ASTM standard/American standards	INOX 439L plates bending method
Film Coated Coated PVC Coated Color Coated Galvanised	ASTM A240/ A240M Type 439L ASTM A412/ A412M Type 439L ASTM A480/ A480M – SS 439L flat rolled sheet ASTM A263/ A263M – SS 439L Clad Plate ASTM A666/ A666M – SS 439L Annealed/ cold worked sheet ASTM A177/ A177M – SS 439L high strength plate ASTM A895/ A895M – SS 439L free machining plate	Press braking Roll bending Rotary bending
European standard	Hardness range of SA 240 Type 439L plate	Stainless steel grade 439L plates and sheets lifespan
EN 10088 -2 (Technical delivery conditions)	57-60 HRC	Upto 25 years
ASTM A240 SS 439L sheet edges	Most popular 439L SS plates types	Manufacturing methods of SUS 439L plates
square broken corner v edge round slit custom rolled deburred	439L ferritic stainless steel Sheet INOX 439L Plate Alloy 439L Perforated Sheet SUS 439L Foils ASTM A240 Type 439L Coils AISI 439L Plain Sheet SA 240 Grade 439L Strip 439L SS Shim Sheet EN 1.4510 Chequered Plate In contrast to other SUS 439L stainless steel sheet suppliers, compare our price and response time.	Cold Rolled 439L stainless steel plate Hot Rolled SA 240 TP 439L sheet
SS 439L sheets processing	Alloy 439L plates and sheets origin	Supply ASTM A240 Type 439L sheet in following brand
Pickling outside with mill edge Temper pass with mill edge Pickling with mill edge Pickling outside with mill edge Pickling with cut edge Temper pass with cut edge	Thailand Taiwan Indian Japanese US Korea European	VDM Nippon Metal POSCO Aperam Arcelor Mittal Jindal Stainless DKC Korea TISCO Outokumpu Thyssenkrup Baosteel
SA 240 TP 439L sheets and plates marking	SUS 439L plates finish	Steel 1.4510 sheet applications
Material grade Manufacturer logo / name Manufacturing date Sizes ASTM/ ASME standard Origin of material	NO.4 NO.8 2B 2D Checkered BA NO.1 Brush embossed etching Brushed finish hair line sand blast 8K Mirror Finish	Chemical industry Food and beverage industry Petroleum Industry Buy from the top zero-rejection SUS 439L stainless steel sheet suppliers in South Africa, Middle East, Egypt, US, Oman, and Saudi Arabia.
ASTM A240 TP439L plates and sheet standard	INOX 439L sheets certification	Services of ASTM A240 Grade 439L plates
JIS4304-2005 EN10088-2-2005 ASTM A240 ASTM A167 GB/T3280-2007 ASME SA240	Raw Materials Certificate 100% Radiography Test Report Certificate of Origin legalized EN 10204/3.1B, Third Party Inspection Report	Pickling Heat Treatment Minor Fabrication Welding Rolling Forming Beveling Plate Leveling Polish Forging Machining grinding Cutting Bending Annealing Shearing Chat or email are the best ways to get in touch with mentioned SUS 439L stainless steel sheet stockists, stockholders, and distributors for these services.
Packaging of EN 1.4510 sheet	Stainless steel grade 439L strips inspection criteria	SA 240 Gr 439L sheets welding method
Industrial packing techniques Big rolls with spools Wooden boxes/ crates/ pallets Bundles with plastic wrapping	Dimension Verification UT testing Visual Inspection Hardness Testing Packing Condition Witnessed Chemical Analysis PMI testing	MIG welding TIG welding Resistance welding
Compare 439L ferritic stainless steel plate, sheet & coil	SUS 439L flat sheet surface	Benefits of SA 240 Grade 439L plates and sheets
Sheet thickness: from 0.5 mm up to 6 mm Plate thickness: at around 6 mm or thick Foil thickness:less than 0.2 mm	Grounded: Bright sheet but rough ; Not precision Turned/ Peeled material: Precision & bright; Little turning scar Black Surface Machining for plate: Precision & bright ; Little turning scar Polished SA 240 TP 439L sheet: Very Bright finish & precision size; No turning scar	Exhibit excellent resistance Excellent hardness
ASME SA 240 SS 439L material method of cutting	439L stainless steel sheet documentation provided	Delivery schedule of ASTM A240 Gr 439L plate
Plasma cutting Oxy-propane flame cutting Waterjet cutting Laser cutting Direct contact with the above-mentioned SUS 439L stainless steel sheet distributors, dealers, and stockists for those specific cuts	Copy of Packing List indicating details of Sizes, quantity, weight, thickness etc. Bill of Lading. Copy of Invoice Manufacturer’s Mill Test Certificate certifying, Heat No, finish, Chemical Composition, Grade etc., Country of Origin Certificate (Original)	Generally it is 7-10 days if its in stock 15-20 days if its not in stock
439L stainless steel coil smelting	Forming of AISI 439L rolling sheets	SA 240 Grade 439L perforated sheet heat treatment
EAF+ESR: Electro Slag Remelting EAF: Electric Arc Furnace EAF+PESR: protective atmosphere Electro Slag Remelting EAF+LF+VD: Refined-smelting and vacuum degassing VIM+PESR: Vacuum induction melting	Hot rolling process Hot Forging	+QT: Quenched and tempered (oil/ water) +A: Annealed (soft/ full/ spheroidizing) +N: Normalized +AT: Solution annealed +NT: Normalized and tempered +P: Precipitation hardened

Flatness Tolerance of ASTM A240 Type 439L Sheet

Width	Tolerances on Flatness for Category
Width	B	C	D
<1200	18	23	Shall be agreed at the time of the enquiry and order
> 1200 <1500	23	30
>1500	28	38
