Stainless Steel Tongue And Groove Flange Suppliers In UAE
Tongue And Groove Flange Specification
Size In Ready Stock: 1/2″ to 48″ | 15 – 1200 NB | DN10 – DN5000
Maximum Size: NPS 26 to NPS 60 For Large Diameter
Manufacturing Way: Forged, Cast, Heat treated, And Machined
Bolts Hole Number: 4 To 48
Flanges Types: Socket Weld Flange, Threaded, Blind, Slip On, Weld Neck, Long Weld Neck, Lap Joint
Surface Finish: Stock Finish, Smooth Finish, Concentric Serrated
Application: Petrochemical Industries, Seawater, Offshore, Shipbuilding, Marine applications
Testing: Hardness Testing, PMI Test, Impact Testing, Tensile Test, Pressure Shell Test
Documentation: Material Test Certificates (MTC), Certificate of Origin, NABL Laboratory Reports
Packaging: Carton Box, Plastic Bag, Wooden Case, Custom
Value Added Services: Casting, Cutting, Polishing, Threading, Machining
Equipments: Press Machine, Pushing Machine, Sand-blasting Machine, Bending Machine, Electric Bevelling Machine
Get Quote Directly From Tongue And Groove Flange Suppliers in UAE
100% Tested ASME B16.5 Alloy Steel Tongue And Groove Flange With MTC EN 10204 3.1/3.2
Buy Carbon Steel Tongue And Groove Flange In Various Materials, Get A Fast Quote Now And Compare Prices Of Different Stockists In Dubai
Material & Grades Of Tongue And Groove Flange
Get SEBIC Approved Tongue And Groove Flange Suppliers in UAE Who Provides All Standard Materials
| Stainless Steel Tongue & Groove Flanges | ASTM/ASME A/SA182 F304, F304L, F316, F316L, ASTM/ASME A/SA351 CF8, CF3, CF8M, CF3M, DIN 1.4301, DIN 1.4306, DIN 1.4308, DIN 1.4408, DIN 1.4306, DIN 1.4409 |
|---|---|
| Titanium Tongue & Groove Flange | ASTM B381 / ASME SB381, Titanium Gr. 1, Titanium Gr. 2, Titanium Gr. 4, Titanium Gr. 5, Titanium Gr. 7 ASTM R50250/GR.1 | R50400/R50700/GR.4 | GR.6 |R52400/GR.7 | R53400/GR.12 | R56320/GR.9 |R56400/GR.5 |
| Carbon Steel large tongue and groove Flanges | ASTM/ASME A/SA105 A/SA105N & A/SA216-WCB, DIN 1.0402, DIN 1.0460, DIN 1.0619, Die Steel, ASTM A105 /ASME SA350, High Yield CS ASTM A694 / A694 (F52 F56 F60 F65 F70 F80) |
| Alloy Steel Tongue & Groove Flanges | ASTM A182 / ASME SA182 F5, F9, F11, F12, F22, F91 |
| Copper Nickel Tongue & Groove Flanges | ASTM / ASME SB 61 / 62 / 151 / 152, Copper Nickel 90/10 (C70600 ), Cupro Nickel 70/30 (C71500), UNS C71640 |
| Copper Tongue & Groove Flange | T1, T2, C10100, C10200, C10300,C10920, TP1, TP2, C10930, C11000, C11300, C11400, C11500, C11600, C12000,C12200, C12300, TU1, TU2, C12500, C14200, C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, etc |
| Duplex Steel tongue and groove pipe Flanges | S31803 / S32205 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61 |
| Brass Tongue & Groove Flange | 3602 / 2604 / H59 / H62 / etc. |
| Inconel Tongue & Groove Flanges | ASTM B564 / ASME SB564, Incoloy 800, 800H, 800HT (UNS N08800), 825 (UNS N08825), 925 Flange |
| Monel Tongue & Groove Flange | ASTM B564 / ASME SB564, Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500) |
| Hastelloy C22 Tongue & Groove Flange | ASTM B564 / ASME SB564, Hastelloy C276 (UNS N10276), C22 (UNS N06022), C4, C2000, B2, B3, X Flange |
| Aluminium Tongue & Groove Flange | 5052 /6061/ 6063 / 2017 / 7075 / etc. |
| Nickel Tongue & Groove Flange | ASTM B564 / ASME SB564, Nickel 200, Nickel 201, Nickel 205, Nickel 205LC |
| Super Duplex Steel tongue and groove pipe Flanges | S32750 / S32760 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61 |
Nickel Tongue & Groove Flanges Thread Types
- BSPT (BSPT/BSP Tapered)
- NPT/NPTF
- BSPP (BSP Parallel)
- Metric Parallel/Metric Tapered Thread
Explore Nearby Locations For The Quickest Delivery Options
| Region | City | Country |
|---|---|---|
| Middle East | Dubai | United Arab Emirates |
| Middle East | Riyadh | Saudi Arabia |
| Middle East | Abu Dhabi | United Arab Emirates |
| Middle East | Dammam | Saudi Arabia |
| Africa | Abuja | Nigeria |
| Middle East | Doha | Qatar |
| Middle East | Jeddah | Saudi Arabia |
| Middle East | Kuwait City | Kuwait |
| MENA | Casablanca | Morocco |
| MENA | Cairo | Egypt |
| Africa | Cape Town | South Africa |
| Africa | Johannesburg | South Africa |
| Africa | Lagos | Nigeria |
Have Direct Contact With The Verified Alloy Steel Tongue & Groove Flange Suppliers For Quality Material And Timely Delivery In The Middle East
Carbon Steel Tongue And Groove Flange Documents
- Certificate of Origin
- Material Test Certificates (MTC)
- NABL Laboratory Reports
- Test Certificates certifying NACE MR0175, NACE MR0103
- Raw Material Test Reports
- Material Traceability Records
- Commercial Invoice which includes HS Code
- Quality Assurance Plan (QAP)
ASME B16.5 Tongue and Groove Flanges Manufacturing Methods
How to Identify Tongue and Groove Flange ?
- Made with two types of flanges
- tongue has a raised ring
- grooved part is machined into the face
- They are self-aligning
- Available in both large and small sizes
Alloy Steel Tongue And Groove Flange Pressure Ratings
| Temperature (F°) | 300 LB | 150 LB | 400 LB | 600 LB | 900 LB | 1500 LB | 2500 LB |
|---|---|---|---|---|---|---|---|
| -20 to 100 | 740 | 285 | 985 | 1480 | 2220 | 3705 | 6170 |
| 500 | 605 | 170 | 805 | 1205 | 1810 | 3015 | 5025 |
| 300 | 655 | 230 | 870 | 1310 | 1965 | 3270 | 5450 |
| 400 | 635 | 200 | 845 | 1265 | 1900 | 3170 | 5280 |
| 650 | 550 | 125 | 730 | 1100 | 1650 | 2745 | 4575 |
| 1000 | 85 | 20 | 115 | 170 | 255 | 430 | 715 |
| 900 | 230 | 50 | 305 | 460 | 690 | 1150 | 1915 |
| 200 | 680 | 260 | 905 | 1360 | 2035 | 3395 | 5655 |
| 700 | 530 | 110 | 710 | 1060 | 1590 | 2655 | 4425 |
| 750 | 505 | 95 | 675 | 1015 | 1520 | 2535 | 4230 |
| 600 | 570 | 140 | 755 | 1135 | 1705 | 2840 | 4730 |
| 800 | 410 | 80 | 550 | 825 | 1235 | 2055 | 3430 |
| 850 | 320 | 65 | 425 | 640 | 955 | 1595 | 2655 |
| 950 | 135 | 35 | 185 | 275 | 410 | 685 | 1145 |
Supporting Materials Of Tongue And Groove Flange
Get Tongue And Groove Flange Suppliers in UAE Who Also Supplied Supporting Material
- Ring-Joint
- Washer and Screw
- Gasket
- Bolts & Nust
Material Inspection Facility In Following Locations
| MENA | Libya, Morocco, Tunisia, Algeria, Israel, Egypt, Palestine |
|---|---|
| Africa | South Africa, Nigeria, Morocco, Kenya, Tunisia, Egypt, Algeria |
| Middle East Countries | Lebanon, Qatar, Saudi, Bahrain, UAE, Kuwait, Iraq, Jordan, Iran, Syria, Yemen |
Check The List Of Very Few But Verified Suppliers Of ASTM A312 F304 Tongue & Groove Flange At The Best Price In GCC Countries. View Applications
Where Are Tongue And Groove Flanges Used ?
- Chemical Processing
- Plumbing, Power Plants
- Food Processing
- Structural Applications.
- Water Supply Systems
- Pulp And Paper Industries
- Fabrication Services
Associate Traders And Importers Available In Below Locations For Quick Deliveries
| Umm Al Quwain | Sharjah | Doha | Fujairah |
|---|---|---|---|
| Riyadh | Muscat | Dubai | Ras Al Khaimah |
| Al Jubail | Abu Dhabi | Ajman | Saudi Arabia |
Surface Finishes Available For The T&g Flange
- Stock Finish
- Concentric Serrated Finish
- Smooth Finish
Get The Lowest Price & Custom Sizes When Buying From Verified Duplex Steel Tongue Flange Manufacturers In Bahrain
ANSI B16.5 Tongue And Groove Flange Size Chart
| Nominal | Large Tongue | Large Tongue | Number | Size of | Gasket | Bolt Torque | Min. Rec’d | Preferred |
|---|---|---|---|---|---|---|---|---|
| Pipe Size | Contact O.D. | Contact I.D. | Of | Bolts | Contact Area | at 60ksi Stress | Torque/Bolt | Torque/Bolt |
| (in) | (in) | (in) | Bolts | (in) | (sq.in.) | (ft.lbs.) | (ft.lbs.) | (ft.lbs.) |
| 0.75 | 1.69 | 1.31 | 4 | 0.50 | 0.89 | 60 | 9 | 18 |
| 1 | 2.00 | 1.50 | 4 | 0.50 | 1.37 | 60 | 13 | 27 |
| 3 | 5.00 | 4.25 | 4 | 0.63 | 5.45 | 120 | 65 | 120 |
| 3.5 | 5.50 | 4.75 | 8 | 0.63 | 6.03 | 120 | 36 | 75 |
| 2 | 3.62 | 2.88 | 4 | 0.63 | 3.78 | 120 | 45 | 93 |
| 2.5 | 4.12 | 3.38 | 4 | 0.63 | 4.36 | 120 | 52 | 108 |
| 0.5 | 1.38 | 1.00 | 4 | 0.50 | 0.71 | 60 | 7 | 14 |
| 1.25 | 2.50 | 1.88 | 4 | 0.50 | 2.13 | 60 | 20 | 42 |
| 1.5 | 2.88 | 2.12 | 4 | 0.50 | 2.98 | 60 | 28 | 59 |
| 8 | 10.62 | 9.38 | 8 | 0.75 | 19.47 | 200 | 129 | 200 |
| 4 | 6.19 | 5.19 | 8 | 0.63 | 8.93 | 120 | 53 | 120 |
| 5 | 7.31 | 6.31 | 8 | 0.75 | 10.69 | 200 | 71 | 200 |
| 6 | 8.50 | 7.50 | 8 | 0.75 | 12.56 | 200 | 83 | 200 |
| 24 | 27.25 | 25.25 | 20 | 1.25 | 82.43 | 1000 | 355 | 1000 |
| 10 | 12.75 | 11.25 | 12 | 0.88 | 28.26 | 320 | 144 | 320 |
| 14 | 16.25 | 14.75 | 12 | 1.00 | 36.50 | 490 | 216 | 490 |
| 16 | 18.50 | 16.75 | 16 | 1.00 | 48.42 | 490 | 215 | 490 |
| 18 | 21.00 | 19.25 | 16 | 1.13 | 55.29 | 710 | 270 | 710 |
| 12 | 15.00 | 13.50 | 12 | 0.88 | 33.56 | 320 | 171 | 320 |
| 20 | 23.00 | 21.00 | 20 | 1.13 | 69.08 | 710 | 269 | 710 |
Alloy Steel Tongue And Groove Flange Dimensions
Stainless Steel Tongue And Groove Flange Weight Chart
| Nominal Pipe Size Inches |
Blind Flange Weight in KG | Slip On Flange Weight in KG | Weld Neck Flange Weight in KG |
|---|---|---|---|
| 1/ 2 | 0.4 | 0.4 | 0.5 |
| 1 | 0.9 | 0.8 | 1 |
| 1 1/ 4 | 1.2 | 1 | 1.3 |
| 1 1/ 2 | 1.5 | 1.3 | 1.7 |
| 3/ 4 | 0.6 | 0.6 | 0.7 |
| 2 1/ 2 | 3.9 | 3.3 | 4.1 |
| 2 | 2.4 | 2.1 | 2.6 |
| 4 | 7.0 | 5.3 | 6.8 |
| 5 | 8.6 | 6.1 | 8.6 |
| 3 1/ 2 | 6.2 | 4.8 | 6.1 |
| 3 | 4.9 | 3.9 | 4.9 |
| 6 | 11.3 | 7.5 | 10.6 |
| 8 | 19.6 | 12.1 | 17.6 |
| 12 | 43.2 | 26.2 | 36.5 |
| 14 | 58.1 | 34.6 | 48.4 |
| 16 | 76.1 | 44.8 | 60.6 |
| 10 | 28.6 | 16.5 | 24 |
| 18 | 93.7 | 48.9 | 68.3 |
| 20 | 122.0 | 61.9 | 84.5 |
| 24 | 185.0 | 86.9 | 115 |
What Factors Can Minimize The Risk In Quality Of Tongue And Groove Flange ?
- Hgh-quality forged steel
- Correct gasket
- CNC Machining for dimensional accuracy
- Proper heat treatment
- PMI testing
- Valid raw materials
- Hydrostatic Testing
- Maintenance
Call Now For Free Sample Which Can Be Arranged From Locations Mentioned Below
| Country | Cities |
|---|---|
| Netherlands | Amsterdam |
| Netherlands | The Hague |
| Belgium | Brussels |
| Netherlands | Haarlem |
| Belgium | Meeuwen-Gruitrode |
| Belgium | Seraing |
| Netherlands | Eindhoven |
| Belgium | Ghent |
| Netherlands | Rotterdam |
| Belgium | Leuven |
| Belgium | Westerlo |
| Belgium | Antwerp |
