ASTM A537 plate

astm a537 plate

The plates display high strength and excellent smooth surface finish. ASTM A537 plate is also regarded as pressure vessel plate which is highly strong and durable. The plates are commonly used in the operations of fusion welded structurers and pressure vessels. ASTM A537 Class 1 Steel Plate is a carbon-manganese -silicon steel material which exhibits excellent high tensile strength up to 450-620MPa. The plates are very versatile and are available in different shapes and sizes with high flexibility. SA 537 Class 1 Plate are widely utilized in the petrochemical, pressure vessel, heat exchanger, storage tanks, chemical processing and power generating industries.

Worried about spiking prices of ASTM A537 material? Here you will get more attention and better price from multiple suppliers of ASTM A537 plate in UAE.

Verified Supplier

Verified stockists and wholesalers

available 5 cars

Suppliers of ASTM a537 class 1 steel plates in UAE can be found here. Compare ASTM a537 class 1 vs 2

ASTM A537 Class 1 specification


ASTM A537 Plate Specification

Thickness availability of ASTM A537 plate Width of A537 class steel plate Length of A537 steel sheet
  • 3/16″ to 6 inch

For SA537 CL1 plate ex-stock you can call or chat to above genuine ASTM A537 plate suppliers in UAE

  • 48″ to 120 inch
  • 96″ to 480 inch
Available Class Of ASTM A537 Heat Treated Plates Modulus of Elasticity A537 plate heat treatment
  • A537 Class 1
  • A537 Class 2
  • Metric : 200 GPa
  • English : 29000 KSI
  • Normalised
  • Rolled
  • Stress relieved
  • Quenched & tempering
SA537CL1 carbon steel plate heads SA 537 cl 2 plate cones ASTM A537 class 1 pressure vessel shells
  • Welded head: custom sizes
  • Thickness: up to 170 (MM)
  • Diameter: up to 12,000 (MM)
  • Thickness : up to 2″
  • Diameter: up to 180″
  • Length : up to 192″
SA 537 CL 2 plate supply conditions SA537M Class 2 plate Mill certification ASTM A537 vessel steel plate Uses and Application
  • Weldable
  • HIC
  • Fine Grained
  • As-rolled
  • Normalized
  • EN10204 3.2
  • EN10204 3.1
  • Firewater
  • H2S environments
  • LPG tank truck
  • Storage Tanks (Acides/ Liquid/ Oil/ Gas)
  • Manufacturing Gas Cylinder
  • Chemicals tanks
  • Sour service
ASTM A537 class 1 plate meet standard European standard of ASTM A537 class 2 plate Inspection plan of ASTM A537 cl 1 plate
  • JIS G3103
  • NACE MR-0175
  • GB3531
  • A20M
  • A20-85
  • BS1501-224-490A/B
  • DIN 17155
  • USA -ASTM / ASME
  • GB713
  • JIS G3115
  • AS 1548 (weldable)
  • NACE MR-0103
  • BS 1501
  • EN10028-2
  • EN10028-6
  • EN 10028
  • EN10028-5
  • EN10028-3
  • RW (Rockwell Hardness)
  • BHN (Brinell Hardness)
  • CVN (Charpy V-Notch Testing)
  • HIC (Hydrogen Induced Cracking)
  • MTC EN 10204 3.1
  • UT (Ultrasonic Testing)
  • SPWHT (Simulated Post Weld Heat Treat)
  • MTC EN 10204 3.2
Manufacturing technique of SA537 PVQ Steel Plate Value added services of ASTM A537 class 2 carbon steel plates SA 537 HIC steel plate estimate delivery time
  • Hot rolling
  • Normalized
  • Stretcher Leveling
  • SA537 cl2 quenched tempered plate flattening
  • Plasma cutting
  • Miter cuts
  • Tapping
  • CNC machining
  • Stamping in ASTM A537 Heat-Treated PVQ steel plate
  • Beveling
  • Coating
  • Finishing
  • Drilling
  • Coping
  • Flame Cutting
  • SA537M Class 2 pressure vessel steel plate processing
  • Oxy-Fuel Cutting

Contact above ASTM A537 plate suppliers, stockholders & dealers for these services at best price in UAE

  • UAE : 8-10 days
  • Oman: 2-3 days
  • South Africa: 12- 14 days (Durban)
  • Saudi Arabia: 5-6 days
  • Egypt : 12-15 days

If ASTM A537 plate suppliers & stockholders have ex-stock then refer above shipping time for UAE, Egypt, South Africa, Oman & KSA



Are particular sizes of ASTM a537 class 2 steel plate required to be purchased from reputable Middle East stockists? Here, your search is over. Look sa537 cl 2 plate-cutting process

Temperature of ASTM A537 Heat-Treated PVQ steel plate

ASTM A537 CL 1 A537 CL 2 ASTM A537 Class 3
371°C [700°F] 1100°F [595°C] 1150°F [620°C]



ASTM A537 plate maximum thickness

ASTM A537 Class 1 ASTM A537 Class 2 ASTM A537 Class 3
100 MM [4 inch] 150 MM [6 inch] 150 MM [6 inch]



Nominal ASTM A537 grade A plate Thickness in MM  Lowest Exemption Temperature in °C
6.4MM -48.3
7.9MM -48.3
9.5MM -48.3
10.0MM -48.3
11.1MM -48.3
12.7MM -48.3
14.3MM -45.6
15.9MM -43.9
17.5MM -41.7
19.1MM -40.0
20.6MM -38.3
22.2MM -36.7



Mechanical properties of A537 plate

ASTM A537 cL 1 mechanical properties

Elongation A200MM Thickness Tensile Strength (MPA) Elongation A50MM
18% < 65 485-620 22%
18% > 65 < 100 450/585 22%



Mechanical properties of A537 Class 2

Elongation A200MM Thickness Tensile Strength (MPA) Elongation A50MM
< 65 550/690 22%
> 65 < 100 515/655 22%
> 100 < 150 485/620 20%



SA 537 CL 1 chemical composition

Mn> 40mm 1.00/1.60
P 0.035
Si 0.15/0.50
Ni 0.25
Cu 0.35
Mn <40mm 0.70/1.35
Mo 0.80
S 0.035
Cr 0.25
C 0.24



ASTM A537 Class 2 chemical composition

Cu 0.35
Mn < 40mm 0.70/1.35
Mn > 40mm 1.00/1.60
P 0.035
Mo 0.80
Ni 0.25
S 0.035
C 0.24
Si 0.15/0.50
Cr 0.25



Equivalent of SA 537 HIC steel plate

Italy Spain Finland USA Germany EU Japan France England
UNI UNE SFS ASTM DIN,WNr EN JIS AFNOR BS
A52CP 224Gr.490 Fe510-1KW A52RCI 2103 Fe52BP 19Mn6 P355GH SPV36

ASTM A537 Plate Properties

Allowable stress for SA537 CL1 plate

Temperature in °F Allowable stress
Minimum ~100 23.3
200 23.3
300 22.8
400 22.7
500 22.7
600 22.4
650 21.9
700 18.3



Types of ASTM A537 plate

  • ASTM A537 cl 1 saddle wear plate
  • ASTM A537 cl 2 plate
  • SA 537 cl 2 HIC plate
  • ASME SA537 Class 2 exchanger plate
  • ASTM A537 vessel steel base plate
  • SA 537 cl 2 rolled plate
  • ASTM A537 boiler plate
  • A537 steel lifting plate
  • ASTM A537M head
  • ASTM A537 class 1 baffle plate
  • ASTM A537 class 2 cones



Density of ASTM A537 class 2

  • Density in Metric : 7.80 g/cc
  • Density in English : 0.282 lb/in³



ASTM A537 yield strength

ASTM A537 Class 1 yield strength (MPA) ASTM A537 Class 2 yield strength (MPA)
345 415
310 380



In Dubai, many importers provide a selection of sa 537 cl 1 plates at reasonable prices. Verify ASTM a537 class 1 welding/application

Surface finish is very important method to provide various strong characteristics to the ASME SA537 Class 2 Steel plate which are listed down:

  • Provides smooth even surface
  • Eliminates surface residue or impurities
  • Improves mechanical properties of the material
  • Provide durability and high strength
  • Gives aesthetic appeal and hardness

The plates are very proficient and capable of handling heavy load and high pressure. For shipment and delivery transportation there are various safe and strong packaging options such as wooden pallets, standard sea packing, bundled with steel strip, brown paper and also available in customized packing as per your requirements. The plates are very versatile and available in different lengths in class 1 up to 240-600 inch and class 2 up to 240-588 inch.

SA 537 CL 1 Plate deliver high performance due to superior mechanical properties. The plates have strong oxidation resistance hence prevent the material form rusting and degradation. ASTM A537 Class 2 Steel Plate give excellent support, width, strength and anchoring to the system. The plates maintain their corrosion resistance and strong mechanical properties even at high temperatures. ASTM A537 Cl 1 Plates have excellent toughness with long life span.

To meet specific needs, get traders for ASTM a537 cl 1 plate. Time to request a cost estimate. Check Classes

Yes, ASTM A537 plate is inbuild with strong corrosion resistant properties. The plates display outstanding corrosion resistance against many aggressive chemicals, toxic acids, alkalis and salts. Are highly resistance against many aggressive corrosions such as chloride corrosion cracking. The plates also prevent erosion corrosion.

Get a large selection of discounted ASTM A537 class 2 boiler quality plates; contact us for a free sample and to learn more about uses, maximum thickness, price range, and hs code.

There are several industrial standard testing which are used to ensure the quality of ASTM A537 plate and make sure that the material is adhering to the industrial requirements which includes:

  • Destructive testing – this method involves hardening, fracture and fatigue resistance to detect flaws in the strength, mechanical properties and high-pressure applications
  • Non-destructive testing-this process involves radiography, ultrasonic and eddy currents to detect surface and internal flaws or damage present in the
  • Visual and dimension inspection testing is done to check visible flaws in the material.
