Hastelloy B2 Plate

hastelloy b2 plate

Hastelloy B2 is a solution-strengthened solid alloy steel grade. The Hastelloy B2 Plate is designed with a chemical content of nickel, molybdenum, chromium, copper, and other alloys. This gives the DIN 2.4617 Hot Rolled Plate excellent resistance to stress and general corrosion. These plates are tolerant to pitting by chloride or phosphoric acids. The robust Hastelloy Alloy B2 Cold Rolled Plate is resistant to hydrochloric acids in different temperatures.

The plates can be solution treated and rapidly quenched in normal conditions, giving them superior hardness. The UNS N10665 Clad Plate can be welded easily as it resists the formation of grain-boundary in the heat-affected zone. The Nickel Alloy B2 Plate is seen in chemical process systems, pharmaceuticals, mechanical seals, fittings, vacuum furnaces, etc.

Verified Supplier

Verified Stockists (Contact directly for instant quote)

available 5 cars

Do you need alloy b2 sheet suppliers in UAE from certified mills? Compare Hastelloy b2 vs c276

Hastelloy B2 plate specification gathered from various genuine suppliers


hastelloy b2 Plate Specification

Get the fastest quote from UAE suppliers of Hastelloy B2 plate for any size.
Hastelloy B2 plate/sheet manufacturing sizes Hastelloy B2 strip sizes Alloy B2 sheet Edges
  • Thickness: 0.1 to 5 mm
  • Width: 0.5 to 1 m
  • Length: 0.7 to 6 m
  • Thickness: 0.05 to 3 mm
  • Width: 5 to 200 mm
  • Slit edge
  • Rolled edge
Nickel alloy B2 plate ASME standards ASTM standard Werkstoff NR. 2.4617 Coil Density
ASME SB 333
  • ASTM B333 UNS N10665
  • ASME SB 333 UNS N10665
9.22 g/cm3
Maximum operating temperature Haynes alloy B2 sheet melting point Temperature range
  • 1800°F
  • 982°C
  • 1370 °C
  • 2500 °F
  • 982°C – 1232°C
  • 1800°F – 2250°F
UNS N10665 plate grades Hardness range of ASME SB333 B2 shim sheet DIN 2.4617 hot rolled plate Elongation
  • Grade B2
  • Brinell hardness : 163
  • Rockwell hardness : 95
40 %
Hastelloy alloy B2 cold rolled plate surface finish classes Most demanded Alloy B2 sheet types Manufacturing methods of Haynes alloy B2 foil
  • Class A : finest finish
  • Class B: slightly less fine finish
  • Class C : most basic finish
  • Hastelloy B2 sheet
  • Alloy B2 plate
  • ASTM B333 UNS N10665 coil
  • Nickel alloy B2 strips
  • Werkstoff NR. 2.4617 rolls
  • Haynes alloy B2 clad plate
  • ASME SB333 B2 annealed plate
  • UNS N10665 foils
  • DIN 2.4617 shim sheet

Above Hastelloy B2 plate stockist produce corresponds with customer drawings, contrast our price & turnaround time with those of other Hastelloy B2 sheet stockists.

  • Cold Rolled
  • Hot Rolled
  • Forged
Werkstoff NR. 2.4617 plate features ASTM B333 UNS N10665 strip welding method Supply Alloy Hastelloy B2 sheet in following brand
  • corrosion resistance
  • strength
  • metallurgical stability
  • weldability
  • outstanding heat resistance
  • GTAW (TIG)
  • PLASMA
  • GMAW (MIG/MAG)
  • SAW
  • SMAW (MMA)
  • Valbruna Stainless Steel
  • Outokumpu
  • Columbus Stainless
  • Special Metals(SMC)
  • HAYNES International
  • Nippon Yakin
  • VDM
  • ATI
Hastelloy B2 sheet marking Nickel alloy B2 sheet finish Hastelloy B2 plate applications
  • Manufacturer logo / name
  • Manufacturing date
  • Material grade
  • Sizes
  • ASTM/ ASME standard
  • Origin of material
  • Brushed
  • Mirror
  • Sandblasted
  • Glossy
  • Matte
  • Electroless nickel plating
  • Construction
  • Petrochemical Industry
  • Engineering
  • Ship Building
  • Bridges

Werkstoff NR. 2.4617 coil to Sudan, South Africa, Senegal, Mauritius, Swaziland, and Gambia have been supplied by the above  top ten genuine suppliers of Hastelloy B2 plate

ASME SB 333 alloy B2 plate modulus of elasticity Coefficient of thermal expansion ASME SB333 B2 shim sheet specific heat capacity
179 Gpa 11.7 µm/m/°C 0.373 J/g-°C
UNS N10665 sheet common trade names DIN 2.4617 hot rolled plate welding electrode Other industry standards
  • Hastelloy B2®
  • Nimofer® 6928
AWS A5.11 ENiMo-7
  • ASTM B333
  • ASTM B335
  • ASTM B366
  • ASME SB333
Standard of Nickel alloy B2 plate Certification of Haynes alloy B2 foil ASTM B333 UNS N10665 coil value added services
  • WERKSTOFF NR. 2.4617
  • UNS N10665
  • JIS NW 0276
  • GOST ХН65МВУ
  • EN NiMo16Cr15W
  • EN 10204/3.1B
  • Raw Materials Certificate
  • 100% Radiography Test Report
  • Third Party Inspection Report
  • Certificate of Origin legalized
  • cutting to length
  • shearing
  • sawing
  • welding
  • edge preparation
  • Bending
  • mechanical processing
  • Slitting
  • Blanking
  • Polishing

Use chat or email to get in direct contact with listed Hastelloy B2 plate stockists, stockholders, and distributors for these services in Saudi Arabia, Qatar & Oman



Nickel alloy B2 foil packaging Werkstoff NR. 2.4617 plate inspection methods Haynes alloy B2 plate hardness type
  • Wooden Pallets
  • Customized Pallets
  • Bubble wraps
  • Steel Strips Bundled
  • Chemical test
  • Mechanical test
  • Destructive test
  • Non destructive test pmi test
  • Visual inspection test
  • Third party inspection test
  • Nabl approved lab test
  • Flaring Test
  • Quarter Hard
  • Half Hard
  • Spring Hard
  • Soft
  • Hard
ASME SB333 B2 sheet processing UNS N10665 sheet permeability (200 Oersted) ASME SB 333 Alloy B2 sheet electrical resistivity (100°C)
  • Manufacturing
  • Packaging
  • Measuring
  • Cutting
  • Processing
≤1.001 0.000138 ohm-cm
Difference between plate, sheet & Foil DIN 2.4617 hot rolled plate characteristics ASME SB333 B2 plate delivery time
  • Sheet : 0.5 mm up to 6 mm
  • Plate : 6mm
  • Foil : less than 0.2 mm
  • Good corrosion resistant
  • Excellent resistance to SCC
  • Generally it is 7-10 days if its in stock
  • 15-20 days if its not in stock
WNR 2.4617 sheet method of cutting Alloy Hastelloy B2 plate documentation offered
  • Plasma cutting
  • Waterjet cutting
  • Laser cutting
  • Oxy-propane flame cutting

Direct contact with the above Hastelloy B2 plate distributors, dealers, and stockists specified for the above-mentioned cuts



  • Copy of Invoice
  • Copy of Packing List indicating details of Sizes, quantity, weight, thickness etc.
  • Manufacturer’s Mill Test Certificate certifying, Heat No, finish, Chemical Composition, Grade etc.,
  • Country of Origin Certificate (Original)
  • Bill of Lading.

Purchase ASTM B333 UNS n10665 strip from a Middle East stockist at a competitive price with excellent customer service and see Hastelloy b2 sheet price/ material properties

Thickness of Hastelloy B2 sheet

Alloy B2 plate Gauge Number Hastelloy B2 sheet in milimeter EN 2.4617 plate in inch
8 4.365 .17187
9 3.968 .15625
10 3.571 .14062
11 3.175 .125
12 2.778 .10937
14 1.984 .07812
16 1.587 .0625
18 1.270 .050
20 .9525 .0375
22 .7937 .03125
24 .635 .025
26 .476 .01875
28 .396 .01562
30 .3175 .0125

Alloy B2 sheet hs code

Description HS code
Alloy B2 sheet 75062000

Delivery location and schedule for SB 333 UNS N10665 shim sheet

Note: below table is published based on data collected by genuine suppliers

Export to Price variations and estimated delivery
UK 5 % extra | 30 days
France 5 % extra | 30 days
Oman 5 % extra | 3-5 days
Italy 5 % extra | 30 days
Qatar 5 % extra | 4-7 days
Malaysia 5 % extra | 10 days
Philippines 5 % extra | 14 days
Saudi Arabia 5 % extra | withing 7 days

UNS N10665 plate thickness tolerance

WNR 2.4617 plate width (milimeter) 2.5 < thickness< 4.5 4.5 < thickness< 6 6 < thickness< 8 8 < thickness< 10 10 < thickness< 12.5 12.5 < thickness< 16 16 < thickness< 20 20 < thickness< 25 25 < thickness< 30 30 < thickness< 40
W < 1200 0.2 0.23 0.3 0.32 0.35 0.8 0.8 0.8 1 1.4
1200 < W < 1500 0.2 0.25 0.3 0.35 0.38 0.8 0.8 0.9 1 1.4
1500 < W < 1800 0.2 0.28 0.32 0.38 0.4 0.8 0.8 0.9 1.1 1.5
1800 < W < 2100 0.2 0.3 0.36 0.4 0.45 0.8 0.8 0.9 1.1 1.5
2100 < W < 2400 0.8 0.8 0.8 0.8 0.8 0.9 1 1.1 1.5
2400 < W < 2700 0.8 0.8 0.8 0.8 0.9 1 1.1 1.3 1.7
2700 < W < 3000 0.8 0.9 1 1 1 1.1 1.3 1.4 1.8

Haynes alloy B2 foil welding procedure

Nickel B2 sheet welding procedure
Gas Metal Arc Welding – GMAW
Shielded Metal Arc Welding – SMAW
Gas Tungsten Arc Welding – GTAW

Alloy B2 sheet mechanical properties

Grade Elongation Density Tensile Strength Melting Point Yield Strength (0.2%Offset)
Hastelloy 2.4617 sheet 40 % 9.2 g/cm3 Psi – 1,10,000 , MPa – 760 1370 °C (2500 ºF ) Psi – 51000 , MPa – 350

Hastelloy B2 equivalent material

Standards Country Value
UNS North America N10665
WNR Russia 2.4617
ASTM America ASTM B333
ASME Australia ASME SB333
JIS Japan H4551
BS United Kingdom
GOST Russia ХН65МВУ
AFNOR France
EN Europe NiMo16Cr15W
AMS United States
ANSI America
SAE United States
AS Australia
DIN German 17750

Chemical composition of Hastelloy B2 sheet

Grade Si P C Fe Co Mn S Ni Cr Mo
B2 Hastelloy 0.1 max 0.04 max 0.02 max 2.0 max 1.0 max 1.0 max 0.03 max Bal 1.0 max 26 – 30

hastelloy b2 Plate Properties

DIN 2.4617 hot rolled plate gauge chart

Gauge Gauge UNS N10665 Plate
inch ASME SB333 NW 0665 plate gauge decimal in inches Haynes alloy B2 plate weight in lb/ft2
8 0.1719 0.1719 6.93
9 0.1563 0.1562
10 0.1406 0.1406 5.67
11 0.125 0.125 5.04
12 0.1094 0.1094 4.41
14 0.0781 0.0781 3.15
16 0.0625 0.0625 2.52
18 0.05 0.05 2.016
20 0.0375 0.0375 1.512
22 0.0313 0.0312 1.26
24 0.025 0.025 1.008
26 0.0188 0.0187 0.756
30 0.0125 0.0125

Nickel alloy B2 plate tolerances on length

DIN 2.4617 hot rolled plate nominal length (milimeter) Tolerance(milimeter)
+
L > 8,000 40 0
2,000  <  L < 8,000 0.005 times length 0
L < 2,000 10 0

Alloy B2 sheet tolerances on width

Nickel alloy B2 plate nominal W (mm) Tolerance (milimeter)
Trimmed edge Mill edge
+ +
Width > 1500 5 0 20 0
1200 < Width < 1500 5 0 20 0
Width < 1200 3 0 20 0

Hastelloy B2 sheet size chart

Hastelloy B2 plate size (milimeter) Alloy B2 plate size (inches)
3.4 0.134
3.18 0.125
4.75 0.187
3.96 0.156
7.92 0.312
6.35 0.25
12.7 0.5
9.53 0.375
15.9 0.6
22.2 0.875
19.1 0.75
25.4 1
76.2 3
31.8 1.25
28.6 1.125
38.1 1.5
50.8 2
44.5 1.75
63.5 2.5

Weight chart of UNS N10665 sheet

Hastelloy B2 sheet gauge US standard gauge ASTM B333 UNS N10665 sheet gauge decimal Weight
inches inches lb/ft2
30 0.0125 0.0125
26 0.0188 0.0187 0.756
24 0.025 0.025 1.008
22 0.0313 0.0312 1.26
20 0.0375 0.0375 1.512
18 0.05 0.05 2.016
16 0.0625 0.0625 2.52
14 0.0781 0.0781 3.15
12 0.1094 0.1094 4.41
11 0.125 0.125 5.04
10 0.1406 0.1406 5.67
9 0.1563 0.1562
8 0.1719 0.1719 6.93

Werkstoff NR. 2.4617 strip dimensions

ASTM B333 UNS N10665 strip nominal width (mm) Tolerance (milimeter)
Trimmed edge Mill edge
+ +
W > 1500 5 0 20 0
1200 < W  < 1500 5 0 20 0
W < 1200 3 0 20 0

Corrosion rate of ASTM B333 UNS N10665 sheet

Content weight % Environment Mean corrosion rate
Mils per year-mpy Mm per year-mmy
10 Acetic acid .5 < .02
30 .4 .01
50 .4 .01
70 .3 < .01
99 glacial .3 < .01
10 Formic acid .3 < .01
20 .6 < .02
30 .7 < .02
40 .7 < .02
60 .5 < .02
89 .5 < .02
1 Hydrochloric acid .8 .02
2 3 .08
5 5 .13
10 7 .18
15 11 .28
20 15 .38
20 20 .51
10 Phosphoric acid 2 .05
30 3 .08
50 6 .15
85 25 .63
2 Sulfuric acid .5 < .02
5 3 .08
10 2 .05
20 .7 < .02
30 .7 < .02
40 .9 < .03
50 1 .03
50 2 .05
50 1 .03
60 2 .05
70 9 .23

Alloy B2 plate thermal and electrical properties

Parameter Value
Electric Resistivity 1410 nΩ.m
Elastic Modulus 179 Gpa
Thermal Condc. 17.3 W/m.K
Co-eff of Expansion 11.7 µm/m/°C
Note : at 500°C

Do you struggle to locate importers of custom nickel alloy b2 hot and cold rolled plate in GCC nations? Get here and read about Werkstoff nr. 2.4617 coil packaging

Packing is very essential in transporting the ASTM B333 UNS N10665 strips across various transportation channels. Generally, different packing materials can be used to pack the ISO 6208 Perforated Sheet. The material can be wrapped with protective material and placed in cardboard, boxes, and other material. The Haynes Alloy B2 Foil can be packed with additional material to hold the material in place as they are transported.
The Hastelloy B2 alloy is designed with a high content of nickel and molybdenum. The C276 grade has better content of chromium, nickel, and molybdenum. This gives the C276 grade an edge in the system. The B2 alloy resists grain boundary precipitates in the welded zone compared to the C276 grade.

The Hastelloy b2 is a superalloy wrought nickel and molybdenum grade. Hastelloy B2 Sheet has excellent physical and mechanical properties. These sheets have a density of 9.22 g/cm3 with a melting point of 1427 degrees C. The Alloy B2 Sheet has a minimum tensile strength of 914mpa with a minimum yield strength of 396mpa. The robust WERKSTOFF NR. 2.4617 Coil has an elastic modulus of 217Gpa with a hardness of 168 Brinell max.

Get in contact with the trader of Haynes alloy b2 perforated sheet who offers third-party inspection from companies like LLOYDS, BVIS, TUV NORD, Intertek, and many more, and see uses

The sheets tend to corrode when they are exposed to even small traces of oxidative media. This ASME SB333 B2 Shim Sheet don’t have any resistance in such environments.

In Dubai numerous distributors of ASME SB333 b2 chequered plate offer cut-to-length services so you don’t need to be paid for waste items, know about hardenability

The B2 plate doesn’t work harden and can be formed using proper applications. The plates can be heat treated followed by rapid quenching of the material.
