Inconel 600 plate

inconel 600 plate

Inconel 600 is a solid solution strengthened alloy grade. The Inconel 600 Plate has primary constituents of nickel, chromium, and iron alloys. These plates have excellent resistance to corrosive media across harsh environments. An Inconel Alloy 600 Plate is immune against chloride ion stress corrosion cracking in both high and cryogenic temperatures. The robust inconel 600 chequered Plate has an aesthetical outlook and outstanding strength. The plates showcase good weldability in wide temperature ranges.

The plates can be processed in either hot or cold rolling procedures. A DIN 17742 Hot Rolled Plate is produced at high temperatures till it reaches its recrystallization limit. These plates have excellent ductility and can be easily worked with. The AMS 5540 Cold Rolled Plate is further rolled after the hot rolling process. These plates can be strengthened or their surface finish enhanced to give desired specifications. Inconel 600 Plate Suppliers can also be solution annealed and later air cooled. These plates are available in a range of sizes and specifications as per project needs. The Inconel 600 Plate Hs Code is 7506.

The Inconel 600 plate price is $30 per kg. The price of these plates is based on their size, thickness, resistance, and other characteristics. The Inconel 600 Plate Weight is dependent on its nominal size, outer diameters, and wall thicknesses. The weight of the plates can be calculated using the Inconel 600 Plate Weight Calculator.

Verified Supplier

Verified Stockists (Contact directly for instant quote)

available 5 cars

Find alloy 600 sheet suppliers in the UAE and also check Inconel 600 strip price in Dubai

Complete information for Inconel 600 sheet grade

Note: Below information is taken from trusted resourse

Grade ASTM AMS WNR Temprature Strength Nickel content Lifespan
Inconel 600
  • ASTM B168
  • ASME SB168
AMS 5540 WNR 2.4816
  • 1900 – 2250°F
  • 1040 – 1230°C
  • Yeild: 172 to 345 MPa
  • Tensile: 655 MPa
72% 30 years

Locate reputable stockists and importers of Inconel 600 sheet in the Middle East and Asia and compare prices and view machinability rating

Inconel 600 plate specification gathered from various reliable suppliers


Inconel 600 Plate Specification

For larger sizes, please contact the Inconel 600 plate suppliers listed above in the United Arab Emirates
Manufacturing size range of alloy 600 plate/ sheet Nickel alloy 600 strip sizes Inconel alloy 600 shim sheet edges
  • Thickness: 0.3 – 120 mm
  • Width: 1000 – 3500 mm
  • Length: 2000 – 6000 mm
  • Gauge: 7 to 28
  • Length: 2000, 2500, 3000mm
  • Width: under 24″
  • Slit edge
  • Rolled edge
Alloy 600 foil AMS Cutting methods of werkstoff NR. 2.4816 rolling sheet Inconel 600 plate density
  • AMS 5540
  • Plasma cutting
  • Waterjet cutting
  • Laser cutting
  • Oxy-propane flame cutting

Direct contact with the above Inconel 600 plate distributors, dealers, and stockists specified for the above-mentioned cuts

  • 0.306 lb/in³
Inconel 600 sheet operating temperature AMS 5540 cold rolled plate melting point Temperature range of WNR 2.4816 plate
  • 1095°C
  • 1354-1413°C
  • 1093°C
Werkstoff NR. 2.4816 strip delivery time Hardness range of Inconel 600 sheet Nickel Alloy 600 coil Elongation
  • 15-20 days if its not in stock
  • 7-10 days if its in stock
  • Oman/ Qatar/ Saudi Arabia – 3-5 days (by Air / Ship)
  • 65B – 84B rockwell
  • 55 to 35%
Inconel alloy 600 plate surface finish classes Most common types of Inconel 600 plate Manufacturing technique of Inconel 2.4816 hot rolled plate
  • Class A : finest finish
  • Class B: slightly less fine finish
  • Class C : most basic finish
  • DIN 2.4816 Plate
  • Nickel Alloy 600 Clad plate
  • 2.4816 Inconel 600 annealed plate
  • Inconel 600 sheet
  • Nickel 600 Coil
  • WNR 2.4816 Strips
  • Inconel Foils
  • UNS 6600 Rolls
  • Inconel 600 Shim sheet

Compare our cost and turnaround time to those of comparable alloy 600 plate stockists.

  • Roll forming
  • Cold rolling
  • Hot rolling

Get best quote directly from above listed Inconel 600 plate manufacturers, best price & quick delivery in Dubai, Saudi Arabia, Oman & Qatar, Chat now for more details

AMS 5540 cold rolled plate features Werkstoff NR. 2.4816 strip welding method Supply alloy 600 sheet in following brand
  • Outstanding heat resistance
  • Metallurgical stability
  • Corrosion resistance
  • Weldability
  • Strength
  • GTAW (TIG)
  • SMAW (MMA)
  • GMAW (MIG/MAG)
  • PLASMA
  • SAW
  • ATI
  • Columbus Stainless
  • VDM
  • Special Metals(SMC)
  • Valbruna Stainless Steel
  • HAYNES International
  • Nippon Yakin
  • Outokumpu
Inconel alloy 600 shim sheet marking Nickel 600 plate finish Nickel alloy 600 coil applications
  • Origin of material
  • ASTM/ ASME standard
  • Sizes
  • Manufacturing date
  • Material grade
  • Manufacturer logo / name
  • Matte
  • Mirror
  • Brushed
  • Electroless nickel plating
  • Glossy
  • Sandblasted
  • Dairy and food processing
  • Power plants
  • Water waste projects
  • Synthetic fiber
  • Petrochemical industry
  • Fluid piping
  • Energy industries
  • Chemical Industry
  • Heat exchanger
  • Pharmaceutical processing industry
  • Marine & Power Transmission industry

Purchase from the largest Inconel 600 plate suppliers in Saudi Arabia, Swaziland, Morocco, Egypt, Tunisia

DIN 17742 hot rolled plate modulus of elasticity Inconel alloy 600 plate coefficient of thermal expansion Inconel 600 sheet velocity
  • 207 GPa
  • At  (1093°C) 16.7 µm/m°C
  • 35/45 sfm
Inconel 600 rolling plate common trade names Nickel alloy 600 foil welding electrode Other industry standards of alloy 600 strips
  • Inconel 600
  • Alloy 600
  • Nickel 600
  • Nickelvac 600
  • Ferrochronin 600
  • INCONEL welding Electrode 182
  • GE Aircraft Engine (GT193)
  • DFARS Compliant
  • GE Aviation S-SPEC-35 AeDMS S-400
  • PWA-LCS
Standard of alloy 600 shim sheet Certification of AMS 5540 cold rolled plate DIN 17742 hot rolled plate value added services
  • BS 3072-3076 (NA14)
  • DIN 17742
  • AMS 5540
  • DIN 17750
  • Certificate of Origin legalized
  • 100% Radiography Test Report
  • Third Party Inspection Report
  • EN 10204/3.1B
  • Raw Materials Certificate
  • Shearing
  • Welding
  • Edge preparation
  • Cutting to length
  • Polishing
  • Mechanical processing
  • Blanking
  • Sawing
  • Slitting
  • Bending

For these services, use chat or email to get in touch with listed Inconel 600 plate stockists, stocks, and distributors

Werkstoff NR. 2.4816 strip packaging 2.4816 Inconel 600 plate testing requirements Alloy 600 sheet hardness type
  • Bubble wraps
  • Customized Pallets
  • Wooden Pallets
  • Steel Strips Bundled
  • Mechanical test
  • Flaring Test
  • Third party inspection test
  • Destructive test
  • Non destructive test pmi test
  • Nabl approved lab test
  • Visual inspection test
  • Chemical test
  • Quarter Hard
  • Half Hard
  • Soft
  • Spring Hard
  • Hard
Inconel 600 strip processing Alloy 600 plate documentation offered Electrical conductivity of DIN 2.4816 coil
  • Grinding
  • Deburring
  • Edging
  • Boring
  • Heat Treating
  • Precision Rerolling
  • Leveling
  • Trepanning
  • Copy of Invoice
  • Mill Test Certificate
  • Country of Origin Certificate
  • Bill of Lading.
  • 14.8 – 20.9 W/m·K
Difference between Inconel 600 plate, sheet & Foil DIN 17742 hot rolled plate characteristics
  • Sheet: 0.5mm upto 600 thick
  • Foil: less than 0.2mm thick
  • Plate: 600 or thicker
  • Excellent resistance to corrosive media
  • Good oxidation resistance at high temperatures

Thickness of nickel alloy 600 annealed plate

1 3/4″ 1″ 3/16″ 1/4″ 1/2″ 3/8″ 5/8″ 1 1/2″ 2 1/2″ 3/4″ 2″ 1 1/4″ 3″
44.5 25.4 4.8mm 6.3 12.7 9.5 15.9 38.1 63.5 19 50.8 31.8 76.2

Inconel 600 plate HS code

Material HS code
Inconel 600 plate 7506

Thickness tolerance of nickel alloy 600 sheet

Tolerance up to & under nominal thickness t (mm)
Width w (mm) 20.0<t <25.0 6.0<t <8.0 2.5<t <4.5 8.0<t <10.0 4.5<t <6.0 10.0<t <12.5 16.0<t <20.0 12.5<t <16.0 30<t <40.0 25.0<t <30.0
2400< w <2700 1.1 0.80 0.80 0.80 0.80 1.0 0.90 1.7 1.3
2700< w <3000 1.3 0.90 1.0 0.80 1.0 1.1 1.0 1.8 1.4
2100< w <2400 1.0 0.80 0.80 0.80 0.80 0.90 0.80 1.5 1.1
1200< w <1500 0.90 0.30 0.20 0.35 0.25 0.38 0.80 0.80 1.4 1.0
1500< w <1800 0.90 0.32 0.20 0.38 0.28 0.40 0.80 0.80 1.5 1.1
w < 1200 0.80 0.30 0.20 0.32 0.23 0.35 0.80 0.80 1.4 1.0
1800< w <2100 0.90 0.36 0.20 0.40 0.30 0.45 0.80 0.80 1.5 1.1

Inconel alloy 600 shim sheet mechanical properties

Tensile strength Yield strength Elongations
655 MPa 310 MPa 40%

DIN 17742 Grade 2.4816 coil equivalent material

Standards Country Value
UNS North America N06600
WNR Russia 2.4816
ASTM America ASTM B168
ASME Australia ASME SB168
JIS Japan NCF 600
BS United Kingdom NA 13
GOST Russia МНЖМц 28-2,5-1,5
AFNOR France NC15FE11M
EN Europe NiCr15Fe
AMS United States AMS5540

Inconel 600 material composition

Cr Ni Cu S Fe Mn C Si
14.00-17.00% 72.00% min 0.50% max 0.01% max 6.00-10.00% 1.00% max 0.15% max 0.50% max

Inconel 600 Plate Properties

Types of alloy 600 sheet

Inconel 600 plate

Inconel 600 plate

Werkstoff NR. 2.4816 coil

Werkstoff NR. 2.4816 coil

Inconel alloy 600 strip

Inconel alloy 600 strip

Nickel alloy 600 foil

Nickel alloy 600 foil

AMS 5540 rolling plate

AMS 5540 rolling plate

EN 2.4816 annealed plate

EN 2.4816 annealed plate

alloy 600 hot-rolled plate

Alloy 600 hot-rolled plate

nickel 600 cold-rolled plate

Nickel 600 cold-rolled plate

DIN 2.4816 shim stock

DIN 2.4816 shim stock

Gauge chart of AMS 5540 cold rolled plate

Gauge 9 8 24 30 18 11 22 20 16 14 12 26 10
Gauge Decimal (inches) 0.1562 0.1719 0.0250 0.0125 0.0500 0.1250 0.0312 0.0375 0.0625 0.0781 0.1094 0.0187 0.1406

Inconel 600 plate price

Grade Thickness in mm Price in USD Price in UAE Driham Price in Pound
Inconel 625 Plate 0.4mm thick x 250mmx250mm US $ 108.68 AED 399.16 £86.00
0.5mm thick x 250mmx250mm US $ 118.79 AED 436.29 £94.00
0.7mm thick x 250mmx250mm US $ 184.50 AED 677.64 £146.00
0.8mm thick x 250mmx250mm US $ 157.97 AED 580.17 £125.00
1.0mm thick x 250mmx250mm US $ 174.39 AED 640.51 £138.00
2.0mm thick x 100mmx100mm US $ 72.03 AED 264.56 £57.00

Delivery location and schedule for werkstoff NR. 2.4816 Strip

Note: below table is published based on data collected by genuine suppliers

Export to Price variations and estimated delivery
Argentina  5 % extra | 45 days
Bolivia  5 % extra | 45 days
Brazil  5 % extra | 45 to 60 days
Chile  5 % extra | 45 days
Venezuela  5 % extra | 45 days
Colombia  5 % extra | 45 days
Ecuador  5 % extra | 60 days
Guyana  5 % extra | 60 days

Size chart of alloy 600 plate

Ni alloy 600 plate stocked sizes
Size (in mm) Size (in inches)
50.8 2
3.96 0.156
7.92 0.312
12.7 0.500
28.6 1.125
6.35 0.250
22.2 0.875
3.40 0.134
25.4 1
19.1 0.750
9.53 0.375
15.9 0.600
76.2 3
4.75 0.187
31.8 1.250
3.18 0.125
38.1 1.500
63.5 2.500
44.5 1.750

Looking for certified Inconel 600 material stock in Saudi Arabia? Get it within 5 days in KSA, also you may ask for cut to size sheets & plates at no extra cost from above listed alloy 600 plate stockists & suppliers

Inconel alloy 600 hot rolled plate flatness tolerance

Alloy(s) Permissible Variations from Flat, in. Specified Thickness, in.
600 0.3125″ 2 to 4, excl.
600 0.75″ 1/4 to 3/8, excl.
600 0.5625″ 1 to 2, excl.
600 1.0625″ 3/16 to 1/4, excl.
600 0.5625″ 1/2 to 3/4, excl.
600 0.5625″ 3/8 to 1/2, excl.
600 0.5625″ 3/4 to 1, excl.

EN 2.4816 plate tolerances on length

Nominal length (mm) L < 2,000 2,000 < L < 8,000 L > 8,000
Tolerance(mm) Plus 10 0.005 times L 40
Minus 0 0 0

Alloy 600 sheet tolerances on width

Tolerance (mm)
Nominal length (mm) w > 1500 1200 < w < 1500 w < 1200
Mill edge Plus 20 20 20
Minus 0 0 0
Trimmed edge Plus 5 5 3
Minus 0 0 0

2.4816 Inconel 600 hot rolled plate weight chart

Gauge Inconel 600 sheet
Weight (lb/ft2)
8 6.93
26 0.756
22 1.26
16 2.52
24 1.008
20 1.512
11 5.04
14 3.15
18 2.016
12 4.41
10 5.67

Inconel 600 strip dimension

KG P/M2 8.1 14.4 28.0 27.0 6.3 10.8 18.0 4.5
Dimension (mm) 0.9 X 1219 X 3048 1.6 X 1200 X 3048 3.18 X VARIOUS ANN 3 X 1200 X 3000 0.7 X 1219 X 3048 1.2 X 1219 X 3048 2.0 X 1219 X 3048 0.5 X 1000 X 2000

Discover the leading traders of UNS N06600 plate & Inconel 600 coil in Dubai who provides MTC and check the laser cutting process


During the laser cutting process, a laser beam is melted in a localized area. The Nickel Alloy 600 Coil is cut with motion control to follow a CNC pattern that can be cut onto the material.
The allowable stress of the Inconel 600 plate is 88 kNm.
The Inconel 600 sheets requires heavy-duty equipment, sharp tools, and proper fluid cutting material. The Inconel 600 sheet has a relative speed based on the B-112 of 22%. Furthermore, the Inconel 600 sheet is extremely hard to machine as it doesn’t soften at any temperatures.

Receive a variety of Werkstoff nr. 2.4816 plate & alloy 600 plate stock with no minimum order quantity at a lower price. Check AMS 5540 plates operating temperature

The Inconel Alloy 600 sheet is designed to work in cryogenic temperatures up to 2000 degrees F.

Are you dissatisfied with the cost of your existing supplier of nickel alloy 600 rolling sheet or Inconel 600 foil ? Review the solution and the application

The Inconel 600 plates are used across several industries. These ASME SB168 UNS N06600 Clad Plate is seen in chemical processing, aerospace, food, nuclear engineering, and the heat-treating industry. The superior Inconel 600 Spec Sheet allows them to be used in gas turbine components, the pulp and paper sector, vacuum furnaces, etc.
Carburizing atmosphere is an empirical based process wherein carbon is diffused in the surface of low-carbon steel. These atmospheres form oxides with particular chemicals that decarburize their microstructures of the WERKSTOFF NR. 2.4816 Strip.
